Termi- Name Descrip-
nal tion
73 FAULT 1 Super-
visory
circuit
for SAFE
1
74 SAFE 2 Safety
input
#2
75 FAULT 2 Super-
visory
circuit
for SAFE
2
76 COM Safety
positive
com-
mon
77 SAFE 3 Safety
input
#3
78 FAULT 3 Safety
input
#3
SAFE 2 and SAFE 3 can be programmed to perform
any of the following instructions under the "LOGIC"
sub-menu:
Programming Features
Default Notes
FAULT Re-
quires
oppo-
site re-
lay state
from
SAFE 1
006-BAR Pro-
gram-
mable
input
FAULT Re-
quires
oppo-
site re-
lay state
from
SAFE 2
Common
015-SHAD- Pro-
OW gram-
mable
input
FAULT Re-
quires
oppo-
site re-
lay state
from
SAFE 3
Specifications
Range Value Function
000 PHOT
001 PHOT TEST
002 PHOT OP
003 PHOT OP TEST
004 PHOT CL
005 PHOTO CL
TEST
006 BAR
Description
System reacts
to the input in
both opening
(stops) and
closing (revers-
es) cycles
Same as
above. Re-
quires the de-
vice to super-
vised (FAULT
active)
System reacts
to the input
only during
the opening
cycle (stops)
Same as
above. Re-
quires the
device to be
supervised
(FAULT active)
System reacts
to the input
only during the
closing cycle
(reverses)
Same as
above. Re-
quires the
device to be
supervised
(FAULT active)
Safety edge in-
put. It reacts in
both opening
and closing. It
stops and par-
tially reverses
