- Page 1 EN Instructions for use / assembly instructions Crometta S240 Showerpipe 26186000 Crometta E240 Showerpipe 26185000...
-
Page 2: Installation Instructions
English Safety Notes Connections G 1/2: cold right - hot left Thermal disinfection: max. 70°C / 4 min Gloves should be worn during installation to prevent crushing and cutting • The product is exclusively designed for drinking water! injuries. • Safety against backflow The arm of the shower head is intended only to hold the shower head. Do not load it down with other objects! Children as well as adults with physical, mental and/or sensoric impairments must not use this product without proper supervision. Persons under the influence of alcohol or drugs are prohibited from using this product. Symbol description Do not allow the streams of the shower touch sensitive body parts (such as your eyes). An adequate distance must be kept between the shower and you. Do not use silicone containing acetic acid! The product may not be used as a holding handle. A separate handle must be installed. Adjustment (see page 6) The product may only be used for bathing, hygienic and body cleaning After the installation, the output temperature of the thermostat must be purposes. checked. A correction is necessary if the temperature measured at the The hot and cold supplies must be of equal pressures. output differs from the temperature set on the thermostat. Safety Function (see page 6) Installation Instructions The desired maximum temperature for example max. 42º C can be • Prior to installation, inspect the product for transport damages. After it has been pre-set thanks to the safety function. installed, no transport or surface damage will be honoured. • The pipes and the fixture must be installed, flushed and tested as per the Dimensions (see page 8) applicable standards. - Page 3 Silicone X + 36 mm 36 mm max. 39 mm max. 5 mm SW 24 mm...
- Page 4 SW 30 mm (17 Nm)
- Page 5 SW 3 mm (4 Nm) SW 17 mm (10 Nm)
- Page 6 SW 3 mm SW 3 mm (2 Nm) SW 3 mm z. B. 42° C for example 42° C SW 3 mm (2 Nm)
- Page 7 热 / hot 冷 / cold Crometta Vario 开 / open 26332407 Rain IntenseRain 关 / close...
- Page 8 Crometta S240 Showerpipe 26186000 4 6 8 3 51 2 4 0 15 3 ± 12 19 7 15 0 2 8 6 m a x . 10 0 Crometta S240 Showerpipe 26186000 0,60 0,55 0,50 0,45 0,40 0,35 0,30 0,25 0,20 0,15...
- Page 9 Crometta E240 Showerpipe 26185000 4 6 8 3 51 2 4 0 15 3 ± 12 19 7 15 0 2 8 6 m a x . 10 0 Crometta E240 Showerpipe 26185000 0,60 0,55 0,50 0,45 0,40 0,35 0,30 0,25 0,20 0,15...
- Page 10 Cleaning Recommendation for Hansgrohe Products Today, modern sanitary and kitchen tapware, showers, accessories, washstands, tubs and radiators consist of very different materials to comply with the needs of the market with regard to design and functionality. To avoid damage and reclamations, it is necessary to consider certain criteria when cleaning. With regard to caring for the Hansgrohe products, the following must in principle be heeded: • Only use cleaning material which is explicitly provided for this type of application. • Never use cleaning materials, which contain hydrochloric acid, formic acid, chlorine pale lye or acetic acid, as they cause considerable damage. • Phosphorus acidic cleaners are only conditionally applicable. • Mixing cleaning agents is not permitted, generally. • Never use cleaning materials or appliances with an abrasive effect, such as unsuitable cleaning powders, sponge pads or micro fibre cloths. • The instructions of the cleaning agent manufacturers have to be followed absolutely. • Cleaning has to be carried out with a specified cleaner dosage, contact time, object-related and adapted to the needs. • The building up of calcifications has to be removed by cleaning regulary. • When using spray cleaners, spray the cleaning solution onto a soft cloth or sponge, never directly onto the Hansgrohe products, as the atomised spray could enter openings and gaps in the Hansgrohe products and cause damage.
- Page 11 SW 17 mm SW 17 mm (10 Nm) > 1 min 94246000 93339000 > 1 min...
- Page 12 SW 3 mm SW 30 mm SW 10 mm 红色 ⁄ red SW 10 mm (20 Nm) SW 3 mm (4 Nm) SW 30 mm (17 Nm)
- Page 13 Crometta E240 Showerpipe 26185000 Crometta S240 Showerpipe 26186000 95688000 94246000 98165000 (20x2) 98447000 (M6x5) 26727007 98187000 (50x2) 95692000 96179000 94246000 92137000 95239000 98131000 (15x2,5) 26724007 96743000 95160000 26332407 98218000 93339000 (15x3) 94246000 96737000 98214000 (M4x14) (12x2) 94140000 97738000 96467000 96922000 98915000 98916000...
