Interlogix TruPortal TP-ADD-2D Series Quick Reference page 5

Terminal Block Pin Label
TB4 AUX
GND
RTE
TB5 NO1
COM1
NC2
COM2
NO2
TB6 +12V
A
B
0V
TB8 NO1
COM1
NC2
COM2
NO2
TB9 AUX
GND
RTE
TB10 DCNT
GND
RTMP
BUZ
TB11 5/12
GRN
RED/RXD
R1D1
R1D0
GND
R2D1
R2D0
TruPortal Dual Door Interface Quick Reference
Description
Aux Input
COM/Shared
Request to Exit
Normally Open
Aux Relay
Normally Closed
Common
Normally Open
(+) 12V - Red
Data A - Green
Data B - Yellow
(-) 0V - Black
Normally Open
Aux Relay
Normally Closed
Common
Normally Open
Aux Input
COM/Shared
Request to Exit
Door Contact Input
COM/Shared
Reader Tamper
BUZ Out (-)
(+) 5/12 VDC
Green LED
Red LED
R1 Data 1
R1 Data 0
(-) 0V Signal Ground
R2 Data 1
R2 Data 0
5 P/N 460802991B 26JAN12 en-US
