Control Inputs and Outputs
Port Pin
+ 5 VDC 25
EXT
+ 24 VDC 26
EXT
Port 1 to Port 16 = Assignment for I/O Profile StdFileSelDirect
Port Pin
11 (Input)
10
12 (Input)
11
13 (Input)*
11
14 (Input)*
12
15 (Input)*
12
16 (Input)*
13
17 (Input)*
13
18 (Input)*
14
19 (Output)
15
10 (Output)
16
11 (Output)
16
12 (Output)
17
13 (Output)
17
14 (Output)
18
15 (Output)
18
16 (Output)
19
* The files must be saved onto the CF card in the user directory.
The files must start with one or two digits (1_Etikett.prn, 02_Etikett.prn).
The files can be saved with a file extension.
In the printer status 'ready', 'waiting' or 'stop', a new file can be loaded. The printer order will
be started after charging and an already existing printer order will be deleted.
The input signal 000000 does not charge a file and does not delete an already existing print
order.
54
Description / Function
5 Volt DC output for external use. Max. 1 A.
This voltage is provided from direct print module and can be used e.g. as
control voltage. Never apply any external voltage to this output.
24 Volt DC output for external use. Max. 1 A.
This voltage is provided from direct print module and can be used e.g. as
control voltage. Never apply any external voltage to this output.
Description / Function
Print start
Error reset
Number of the file to load Bit 0 (Input)
Number of the file to load Bit 1 (Input)
Number of the file to load Bit 2 (Input)
Number of the file to load Bit 3 (Input)
Number of the file to load Bit 4 (Input)
Number of the file to load Bit 5 (Input)
Error
No function
No function
No function
Ready
No function
Return printing carriage
Transfer ribbon prior warning
