Lumascape Quadralux Q2 LS9140 Installation Instructions

Q2
Quadralux
Q4
Quadralux
READ ALL SAFETY INSTRUCTIONS FIRST
› Follow instructions carefully, failure to do so will void
warranty.
› Ensure installation complies with local law and
applicable standards.
› Input voltage is 120-277 V AC, 50/60 Hz
› Only use Lumascape power supply, control equipment
and leader cables.
› Ensure mains input power is surge protected.
LUMASCAPE ASIA PACIFIC Brisbane Technology Park, 18 Brandl Street, Eight Mile Plains, QLD 4113, Australia
Phone +61 7 3854 5000 | Fax +61 7 3854 5001 | Email: sales@lumascape.com.au |
LUMASCAPE NORTH AMERICA 1300 Industrial Road, Unit #19, San Carlos, CA 94070, USA
Phone +1 650 595 5862 | Fax +1 650 595 5820 | Email: info@lumascape.com |
Products and specifications are subject to change without notice.
LS9120
INSTALLATION INSTRUCTIONS
ARCHITECTURAL SPOTLIGHT
LS9140
FACADE LUMINAIRE
LS9140
Quadralux
National Electric Code, ANSI/NFPA 70 or
› Never make connections whilst the power is connected.
› Do not make modifications or alter the product.
› Keep luminaire and connections clean and free of debris
and moisture.
› It is the installers responsibility that the installation is
adequately sealed to avoid moisture ingress.
