TECHNICAL SPECIFICATIONS

Model Number
Type
Input Voltage Range
Input Frequency
Output
Start Voltage
Charge Voltage
Equalizing Voltage
Float voltage
Rejuvenation voltage
Rejuvenation current
Size (L*W*H) in mm
Weight
Approvals

CHARGING INSTRUCTIONS

STEP 1 - PRE CHARGE CHECK & ELECTROLYTE LEVEL CHECK
• Check the Battery Electrolyte level (Not required on sealed & Maintenance Free Batteries).
If necessary, remove the vent caps and add distilled water so the levels are halfway between the upper and lower fill lines.
• Check the Voltage Output Switch on the charger and make sure it's on the correct voltage
STEP 2 - CONNECTING THE BATTERY CHARGER TO YOUR BATTERY
• If the Battery is out of the vehicle:
- Connect the Red lead from the charger to the positive (+) battery terminal.
- Connect the Black lead from the charger to the negative (-) battery terminal.
• If Battery is still in the vehicle, determine if the vehicle is positively or negatively grounded.
- If Negatively grounded (Most Common) – FIRST Connect the Red (+) battery charger lead to the positive (+) Battery post
and then connect the Black (-) battery charger lead to the vehicle's chassis and away from the fuel line.
- If Positively grounded – FIRST Connect the Black (-) battery charger lead to the Negative (-) battery post and then connect
the Red (+) battery charger lead to the Vehicle's chassis and far away from the fuel line.
STEP 3 - CONNECT THE BATTERY CHARGER TO MAINS POWER
• Connect the battery charger to the Mains Powered socket.
• The Charger will automatically start when AC power is connected and switched on.
(Note: If the Fault Indicator LED illuminates Red, please check your connections as it's likely that the Positive
and Negative Leads are reversed. Refer to Trouble Shooting Page for further information)
EWC12-148
Smart
100-120Vac
50/60Hz
8A @ 12V
2V
GEL-14.1V
AGM&WET-14.4V
Pure Lead - 14,7 V
N/A
AGM&WET-15.5V
Pure Lead -16.2V
13.2V
16.0V
0.5~1.0A
217*104*58
1.1Kg
CE, UL/cUL, FCC, AS, NZS, DOE
MODEL: EWC12-148
USER'S MANUAL
