Silent Call Communications GV 1097-2 Installation And Operation Manual

Installation and operations manual

General

The new Silent Call Good Vibrations
visual alerts. It is used in conjunction with any Silent Call transmitter such as the telephone, doorbell,
smoke detector and/or sound monitor. When this receiver detects a signal from a Silent Call transmitter, it
activates its vibrator with a predetermined output pulses for each type signal and illuminates the associated
top panel LED.

Operation

Switch the Good Vibrations receiver on by moving the power switch to the ON position. Notice that the
Phone (green LED) will blink 3 times and go out indicating that power has been applied. The unit will
then turn on the Fire LED and the vibrator pulse continuous short pulses signaling the last alarm
that was received as this is the factory default test used. These are a couple of the distinguishing features
of the new revised Good Vibration. Another is the pushbutton used for programming that replaced the dip
switch. Each time the Good Vibration receives a signal from a Silent Call transmitter with a matching code;
the Good Vibrations receiver will vibrate a particular type pulse and illuminate the associated LED. The
LED indication will remain on until the vibrator pulse pattern has been completed. Switching the On / Off
switch from off to on activates the recall function which will turn on the LED and send the vibrator pulses
of the last transmitter alert the receiver received. The Good Vibrations receiver battery may be tested by
moving the power switch momentarily to the TEST position.
The Good Vibrations receiver is supplied with a rechargeable Nickel Metal Hydride 9V battery. In normal
operation, the unit will function for approximately two to three days per charge. However, for the most
reliable operation, recharge the battery each night when you go to bed. Also, do not leave the unit on when
you are not using it as the battery can be damaged by running it completely down. Not all "9V"
rechargeable batteries are the same, and we recommend you purchase replacement batteries from Silent
Call. Although it is not recommended, the Good Vibrations receiver may be operated with a standard
alkaline battery. However, if you use an alkaline battery YOU MUST NEVER ATTEMPT TO
RECHARGE THE BATTERY. Doing so will cause the battery to burst and destroy the Good Vibrations
circuitry, voiding the warranty.
Good Vibration receiver front panel LED indications
5095 Williams Lake Road, Waterford Michigan 48329
Good Vibrations Receiver
Model # GV 1097-2
TM , receiver is a body worn portable alerting device with vibrating and
Transmitter
Sound
Telephone
Doorbell
Fire
Smoke sensor
Weather
CO
(800) 572-5227
http://www.silentcall.com
Indication
Orange Sound light on
Green Phone light on
Yellow Door light on
RED Fire light on
RED Fire light on
Orange, Green, Yellow,
All Lights on
Orange, Green, Yellow,
Sound, Phone , Door Lights on
Red
