- Page 1 www.silentcall.com Sidekick II Sidekick II ™ ™ Receiver Receiver Model # SK2-SS Model # SK2-SS 418MHz Signature Series Signature Series...
- Page 2 FROM FACTORY. The Receiver will need to be programmed to Silent Call transmitters at this time. Make sure that the transmitters to be programmed are near the Sidekick II Signature Series Receiver. Perform All Erase to ensure SK2-SS receiver is cleared. Turn Unit OFF, Press and Hold Minute Button, Turn Unit ON.
- Page 3 NOTE: Any time you unplug your Sidekick II Signature Series receiver from the wall outlet or turn the power off, without the battery back-up switch on, the receiver will reset the clock to 11:59AM. The receiver will keep all programmed transmitters in memory when power is cycled.
-
Page 4: Lcd Display
LED STROBE: The Sidekick II Signature Series has a solid state LED strobe board for visual alerting. The SK2-SS LED Strobe Intensity can be controlled by a switch located on the right side of the Unit. Select High,... - Page 5 Next, take the telephone wire that came with your Sidekick II Signature Series Receiver and plug it into the other side of the dual connector. Reference FIGURE 1. Plug the other end of that cable into the back of the Sidekick II Signature Series Receiver. Reference FIGURE FIGURE 1...
- Page 6 Signature Series Sidekick II Receiver Model: SK2-SS 418MHz DISPLAY AND LED DESCRIPTION: When the Sidekick II Signature Series Receiver detects an incoming signal from any of the Signature Series transmitters it will notify you by displaying the appropriate ICON and illuminating the appropriate LED.
- Page 7 Signature Series Sidekick II Receiver Model: SK2-SS 418MHz VIBRATOR DESCRIPTION: If you are using the optional Bed Vibrator and your Sidekick II Signature Series Receiver detects an incoming signal from any of the Signature Series transmitters, along with the above Notifications, the bed vibrator will also pulse in a specific pattern for each transmitter.
- Page 8 Supervision Mode with your smoke detectors. Make sure that all Silent Call transmitters in the area are turned off. Select the transmitter you wish to program with the Sidekick II Signature Series Receiver. IT IS IMPORTANT TO PROGRAM THE SMOKE DETECTORS FIRST THEN ANY FIRE TRANSMITTERS BECAUSE OF THE SUPERVISION CAPABILITY.
- Page 9 Signature Series Sidekick II Receiver Model: SK2-SS 418MHz PROGRAMMING SK2-SS RECEIVERS: Make sure that the transmitter to be programmed is near the Sidekick II Signature Series Receiver. Perform All Erase to ensure SK2-SS receiver is cleared. Reference All Erase Section.
-
Page 10: Supervisor Mode
The transmitters will send out a special low battery signal whenever the low battery condition exists. When the Sidekick II Signature Series Receiver detects the signal it will display the condition. For example, a smoke detector battery is low. The smoke detector or fire alarm transmitter sends a signal to the Sidekick II Signature Series Receiver about its battery condition. - Page 11 Your Sidekick II Signature Series Receiver comes with the battery pre-installed at the factory. The back-up battery is a NiMH, Model # BU-10, with a 1500maH rating. The Sidekick II Signature Series receiver Model #BU-10 has been tested to provide back-up for 24 hours in Stand By mode and 15 minutes in full operational mode, (with both the strobe and vibrator operating).
- Page 12 During that time, the unit will be repaired or replaced free of charge when shipped prepaid to Silent Call Communications. This warranty is void if the defect is caused by customer abuse or neglect. We honor the smoke detector manufacturer’s warranty for their smoke detector. Only Silent Call products are warranted for 5 years.
