Installation
4.
Centralise the extrusion, aligning the marker with the centre of the
camera lens.
5.
Turn the telescopic rods to tighten the clamps onto the rear of the
extrusion. The clamps can be tightened securely by using an Allen
key as a lever through the holes in the rods.
12
Mounting the Prompter Monitor
WARNING! Before attempting to install or adjust the
prompter monitor assembly, the tilt axis of the head support
must remain securely locked horizontally.
WARNING! The prompter monitor must be isolated from the
AC power supply during installation or adjustment.
When the extrusion is fitted and correctly secured to the camera mount
the prompter monitor can be fitted.
1.
Unscrew the end caps from the two prompter monitor support
rods.
