BodyCraft MB1602 Owner's Manual

Cable pull station
Hide thumbs

Advertisement

Quick Links

Download this manual
Serial Number Location
Record your Serial number
and purchase date here:
S/N __________________
PURCH.DATE:_________
DEALER:______________
______________________
______________________
Model No. CABLE PULL STATION
MB1602
BODYCRAFT
is a division of Recreation Supply
CABLE PULL STATION
S E R I A L
1 2 3 4 5 6 7 8
OWNER'S MANUAL
Recreation Supply Inc.
7699 Green Meadows Drive
Lewis Center, OH 43035

Advertisement

loading
Need help?

Need help?

Do you have a question about the MB1602 and is the answer not in the manual?

Questions and answers

Emily Ashley
May 5, 2025

Hi, I have the Bodycraft cps MB1602. When I bought it, it mentioned being able to combine the two cables together but I can’t find instructions for this or why this means in the owners manual? Many thanks

0

Subscribe to Our Youtube Channel

Related Manuals for BodyCraft MB1602

Summary of Contents for BodyCraft MB1602

  • Page 1 1 2 3 4 5 6 7 8 Record your Serial number and purchase date here: S/N __________________ PURCH.DATE:_________ DEALER:______________ ______________________ ______________________ Model No. CABLE PULL STATION Recreation Supply Inc. MB1602 7699 Green Meadows Drive BODYCRAFT Lewis Center, OH 43035 is a division of Recreation Supply...
  • Page 2 8. Make certain all cables are seated within the pulleys before every use. 9. Exercise with care to avoid injury. 10. If you are unsure about the proper use of the BODYCRAFT Cable Pull Station call your local BODYCRAFT dealer or our customer service department.

  • Page 3: Recommended Tools

    Gym Placement Planner WALL 23.9" HEIGHT 79.8" 21.1" Important Notes and Tips: Recommended Tools for Assembly 1. Do not tighten any bolts until instructed. 2. Two people are reguired for the safe assembly of the gym. Ratchet 3. Use silicone lubricant on guide rods prior to weight 9/16"...
  • Page 4 CPS Parts List 1 NOTE: IF A PART IS MISSING, IT LIKELY HAS BEEN PRE-INSTALLED FOR QUALITY CONTROL PURPOSES. PLEASE PROCEED WITH ASSEMBLY. *Parts images are not to scale. (1) BASE (2) TOP FRAME FRAME (6) WEIGHT SHROUD (9) DOUBLE (10) BRACKET (8) SWIVEL PULLEY...
  • Page 5 CPS Parts List 2 NOTE: IF YOU SEEM TO BE MISSING A PART, DO NOT WORRY, IT LIKELY HAS BEEN PRE-INSTALLED FOR QUALITY CONTROL PURPOSES. NO. DESCRIPTION QTY. 1/2" X 4-1/4" HEX BOLT 3/8" X 3" HEX BOLT 3/8" X 2-3/4" HEX BOLT 3/8"...
  • Page 6 STEP 1 Install Onto The Wall NOTE: WALL MOUNT TOOLS ARE REQUIRED. DO NOT TIGHTEN BOLTS UNLESS INSTRUCTED. 1. Cap four Oval End Caps (20) to the Base Frame (1). Cap two Round Caps (22) to the Rear Upright Frame (4). 2.
  • Page 7 STEP 2 Assemble Base Frame 1. Please drill the hole on the wall using the Electric Hand Drill Machine as show in below.
  • Page 8 STEP 3 Assemble Base Frame 1. Attach Front Upright Frame (3) to the Base Frame (1) using two 3/8" X 1" Hex Threaded Bolts (33) and two 3/8" Spring Washers (37). 2. Attach two Swivel Pulley Housings (8) to the Cable Height Adjuster (7) using two 1/2"...
  • Page 9 STEP 3 Assemble Base Frame...
  • Page 10 STEP 4 Assemble Top Frame 1. Cap two Oval Caps (21) to the Top Frame (2). Insert Plastic Guide Rod Holders (15) into Top Frame (2). 2. Attach Top Frame (2) to the Front Uptight Frame (3) using two 3/8" X 1"...

  • Page 11: Step 5 Install Cable

    STEP 5 Install Cable (25) CABLE 1. Screw the Double Pulley Bracket (9) into the Top Plate (12) with Selector Rod (11) 10 threads (2cm). As Show in C4,C6. 2. Insert the ball end of the Cable (25) into the front of the right side Swivel Pulley Housing (8) and come out from top.
  • Page 12 STEP 6 Assemble Weight Shroud 1. Attach Weight Shrouds (6) to Top Frame (2) and Base Frame (1) using eight 5/16" Washers (38) and eight 5/16" X 1/2" Screws (34). Remember to keep all bolts loose in frame to ensure holes line up easily. Tighten all bolts.
  • Page 13 OVERVIEW 38 34...
  • Page 14 COMPLETE PARTS CHART NO. DESCRIPTION QTY. BASE FRAME TOP FRAME FRONT UPRIGHT FRAME REAR UPRIGHT FRAME GUIDE ROD WEIGHT SHROUD CABLE HEIGHT ADJUSTER SWIVEL PULLEY HOUSING DOUBLE PULLEY BRACKET BRACKET FRAME SELECTOR ROD TOP PLATE WEIGHT PLATE RUBBER DONUT PLASIC GUIDE ROD HOLDER PULLEY CLIP SINGLE HANDLE...
  • Page 15 Guide Rods (5). Enjoy many years of a Fit Lifestyle. Thank you for purchasing the BodyCraft Cable Pull Station. If you have any questions, please call your local BodyCraft dealer, call our customer service department at 800-990-5556 or at http://www.bodycraft.com.
