Field engineering change order
Field engineering change order, number 15122017:
PRODUCT
Type/model:
Description:
Serial number:
Date introduced
CHANGES
Problem:
Typical fault signs:
Solution:
Terms:
ENCLOSED
Document:
Components:
APPROVAL
Date:
Approved by:
MAC Encore Performance - How to replace the animation wheel, number 15122017,
date 15-12-2017, revision A
MAC Encore Performance
Moving head
All units before serial number 15029579147
15 December 2017
Field reports indicate that the animation wheel can warp under special usage patterns. The warping
can potentially cause an animation error that will turn the light off as a safety precaution.
There is no risk of personal injury.
The animation wheel moves in and out of focus when it is rotated. An animation and gobo error may
appear.
Replace the animation wheel with the new type. Follow the instructions in
animation wheel" on page 4 on how to remove the multimodule and replace the animation wheel.
This document only applies to the MAC Encore Performance fixtures that were delivered with the first
type of animation wheel that does not have the positioning notch.
See the procedure in "Procedure on replacing the animation wheel" on page 4.
-
15 December 2017
Senior Manager, Global Product Support, Henrik Christensen
"Procedure on replacing the
