5.5 IU0U Charging Characteristics

Two modes (phases) are considered here – charging and maintaining. After the charger is switched on, the voltage will increase
at a constant current up to the maximum of set voltage. Then the current decreases by constant voltage. If the output current comes
to the set value I2, the charger proceeds to the stage Um (maintaining charging - 2.23-2.3V/cell. according to the battery type). If the
load consumption in the Um stage causes decrease of the voltage to the value U2, the charger proceeds to the stage U1 with the I1
charging current.
Signal column and relay indication:
• LED 2 blinking + Relay 2 ON + Relay 1 OFF – phases I1+U1
• LED 2 lighting + Relay 2 OFF + Relay 1 ON – phase Um
• LED 3 lighting – failure
• Relay 3 ON – operation
• Relay 3 OFF – failure
• LED 1 lighting – end of desulphation

5.6 IU Charging Characteristics

The charger supplies the constant current I1 (maximum) up to the set voltage U1 (2,23V/cell – 2,3V/cell – according to the battery type).
This characteristic is suitable for common applications of the backed-up power supply of the load (there is no danger of damaging the
power-supplied appliances by a higher level of voltage).
Signal column and relay indication:
• LED 2 blinking + Relay 2 ON + Relay 1 OFF – phase I1
• LED 2 lighting + Relay 2 OFF + Relay 1 ON – phase U1
• LED 3 lighting – failure
• Relay 3 ON – operation
• Relay 3 OFF – failure
• LED 1 lighting – end of desulphation

5.7 Battery desulphation

• open the menu
• choose Desulphation
• set values and press START (recommended values: respect the instructions of the battery producer)
Manufacturer of the battery chargers AXIMA cannot be held responsible for damages or issues caused by
incorrect charger setting. In the event of uncertainty over user settings, please contact your supplier.

6. Storage and delivery

The charger is provided in a pre-assembled state and comes with an Instruction Manual. Each charger is pre-tested for operability.
Items are shipped wrapped in cardboard packaging. During transportation and storage it is crucial to heed information contained in
appended labels: protection against extreme weather conditions (rain, snow); protection against knocks and falls; which way up the
package must face.
During any kind of additional handling, the charger must be transported in appropriate packaging. The charger must be stored in a dry
interior environment with temperatures ranging from -25°C to +80°C with relative humidity not in excess of 80% (non-condensing).
