Types of chargers
Battery voltage Charger current
Unom (VDC) Imax (A)
60
100
12, 24
100
200
50
50
48 100
150
200
25
25
50
75
100
60 110 125
150
175
200
225
250
22
44
66
88
220
110
132
154
176
12
24
36
400
48
60
72
* Recommended external circuit - breaker of the C or D characteristics
** Mains voltage tolerance +15%/-10%, 1f chargers +/- 15%
Version up to 600VDC on request
Dimension (mm)
Case
H W
FF170 477 302
FF250 477 302
FF330 477 302
FF550 477 547
FF720 477 717
4 7390 00 0
BATTERY CHARGERS
Typ Case
24E60 FF170
24E100 FF170
24D100 FF170
24D200 FF250
48E50 FF170
48D50 FF170
48D100 FF170
48D150 FF250
48D200 FF250
24 80E25 FF170
24 80D25 FF170
40 80D50 FF170
65 80D75 FF250
80 80D100 FF250
100 80D125 FF330
120 80D150 FF330
140 80D175 FF550
160 80D200 FF550
180 80D225 FF720
200 80D250 FF720
220D24 FF170
220D48 FF250
220D72 FF330
220D96 FF550
220D120 FF720
220D144 FF720
220D168 ATYP
220D192 ATYP
400D12 FF170
400D24 FF250
400D36 FF330
400D48 FF550
400D60 FF720
400D72 FF720
Fastening holes
spacing (mm)
D x y
169 230 515
254 230 515
339 230 515
339 499 515
339 669 515
and POWER SUPPLIES
STATION BATTERY CHARGER
Charger voltage Input voltage
Umax (VDC) (VAC)
230
35
3x400
230
70
3x400
230
140
3x400
300 3x400
600 3x400
Box colour is black as standard or arbitrary
at customer's request.
Other tpes (voltage, current) on request.
