1. Introduction

CONTIS basic chargers are intended for industrial applications, mainly for charging and main-taining of station batteries in a charged
state, DC power supply and back-up of technology systems, etc. With regard to the perfect electric parameters, they are suitable even
for different types of batteries (e.g. maintenance-free batteries, gel batteries, AGM etc.).

2. Operational safety

• charger is intended for usage in well-ventilated interiors
• the charger can be connected only to the standard electric power mains
• it is necessary to avoid sparking and making a fire near the battery; explosion hazard during the process of charging
• the charger must not be operated without a cover, an electric shock hazard
• only batteries intended for charging with the parameters (voltage, capacity ranges) suitable for the specified type of charger
can be charged
• during charging, it is dangerous to touch the supply leads to the battery poles
• the transport of the charger during the charging process is prohibited
• the supply leads to the battery must not be disconnected during the process of charging
• the charger can be operated only by a respectively qualified person

3. Characteristics of the equipment

The chargers are designed to be used in interiors with standard conditions (humidity, temperature, dustiness). When operated
in a place with a higher level of dustiness, the interval of service inspections must be shortened. They should be connected to
one-phase or three-phase power mains with a standard power supply cord with a three-pole or a four-pole connector. The suitable
protection must be carried out in the installation of the charging station.
They are intended for permanent charging of station batteries and supplying power to the connected appliances, they can be operated
continuously. Cooling is provided by fans placed inside the charger. The rated (maximum) power is according to the type from 1,8kW
to 39kW. The standard output voltage is 12 – 600V. The respective types enable to set the output parameters in absoulte values.
Chargers use the principles of high-frequency technology. They are based on power units operating in high switching frequency.
The charging process is controlled by a microprocessor control system. Important statuses are indicated on display.
Specifications
Starting current
Efficiency
Output voltage stability
Protection
Protection class
Cooling
Working environment
Standards EMC, LVD
4 7390 00 0
BATTERY CHARGERS
<Inom
Up to 95%
± 1%
IP20, optionally IP54
I
Forced ventilation
-10 to +40 °C, max. rel. humidity 80%, non-condensing
EN 61000-6-4, EN 61000-6-2, EN 60950-1
and POWER SUPPLIES for INDUSTRIAL APPLICATIONS
