BorderAdjustments
Follow the steps below to fine-tune the position and size of the
MPEG video within its display window.
1. From the REALmagic Configuration... dialog (refer to Figure 5)
click Advanced >>> and then BorderAdjust. In the resulting
dialog box, click the Expert button.
2. In the Expert Settings dialog (Figure 27, the four Cropping
region values crop the MPEG video image from the Left, Right,
Top, and Bottom. This allows you to position the video with
greater precision. The In delay value delays the display of the
video pixel on the left-hand side of the MPEG video. The Out
delay value delays the display of the video pixel on the right-
hand side of the MPEG video. Adjusting these values can reduce
flutter and jitter which may appear with rare display adapter and
resolution combinations.
6/6/00 2:47 PM Page 42
Figure 27. Expert Settings
