Audio Connections

The NetStream 2000 has a standard 1/8-inch (3.5mm) Stereo Output
Port. The Stereo Output Port outputs a standard analog stereo signal
that can be used by virtually any stereo receiver or amplified speak-
ers. It also contains the Pro Logic Surround Sound encoding that
allows you to achieve surround sound by attaching a Pro Logic
receiver.
If your system has a sound card, we recommend attaching the Stereo
Output signal to the LINE-IN port on your sound card, and then
attach your receiver or amplified speakers to the LINE-OUT or
SPEAKER port on your sound card. This will allow you to use one
set of speakers to listen to both MPEG-2 audio as well as other types
of audio from your sound card. It will also allow you to control the
volume by using the mixer program provided with your sound card.
Otherwise, attach this signal directly to your receiver or amplified
speakers.
6/6/00 2:47 PM Page 12
1/8" (3.5mm)
Stereo Output
(Connect to your
sound card or
amplified speakers
Figure 3. Audio Connection
Chapter 2: Hardware Installation 7
