10-Key Keypad

If DVD Station detects that a DVD movie disc is in the DVD-ROM
drive, it will display the 10-Key Key Pad button in place of the
Mode button. Clicking on this button will bring up a floating 10-key
keypad that will allow you to interact with some DVD movie titles
that have menu selections and other options. Figure 22 shows the
two 10-key keypads available.
Figure 22. 10-key Keypads
6/6/00 2:47 PM Page 32
Click on this button to toggle between the two 10-key keypads.
Use this button to make corrections.
This button returns to the previous menu.
Click on this button will execute whatever option you have
chosen.
If the 10-key keypad is hidden by another window, clicking on
the button again will bring it back to the foreground.
During full-screen video playback, use the right mouse button to
hide and unhide the 10-key keypad.
Chapter 4: Using the DVD Station 27
