BorderAdjustment and Color Calibration

You must set the Border Adjustment and Color Calibration to final-
ize the installation. You need to set the Border Adjustment and Color
Calibration only once for each display setting (resolution, number of
colors, and refresh rate). Follow the steps below to complete the
Border Adjustment and Color Calibration.
1. After rebooting, start the Border Adjust Utility as follows: at the
Start button, click Programs, REALmagic, and BorderAdjust.
You will see the REALmagic Configuration... dialog
(Figure 5).
Figure 5. REALmagic Configuration
12 Chapter 3: Software Installation
6/6/00 2:47 PM Page 17
2. At the REALMagic Configuration... dialog (Figure 5), click
Adjust border...
3. You will see the BorderAdjust dialog (Figure 6). Use the arrow
keys in the dialog or on the keyboard to align the four corners of
the colored window within the gray outlined pink window. Click
or press the plus (+) key on the keyboard to widen the
colored window. Click or press the minus (-) key on the key
board to make the colored window narrower. When aligned,
click OK.
Figure 6. Border Adjust
