  • Page 1 VRS 40 - 450 Oil-/Gas- Universal Heating Systems Edition GB - H01 (S) Operating Technology Original REMKO Spare Parts REMKO - alles bärenstark.
  • Page 3: Table Of Contents

    Our guarantee will become void when the unit supplied by us is used and installed for inadequate purposes, or maintained incorrectly, etc., or if it is changed without our prior consent. standing device lying device VRS 40 – VRS 450 Contents Contents Page Page...
  • Page 4: Safety Instructions

    Safety Instructions Description of Device Always observe the local building and fire The heaters are directly fired with heating oil or natu- ral gas resp. liquefied petroleum gas. prevention regulations. The heaters are designed for fully-automated, univer- The heaters may only be operated by persons who sal, problem-free operation.
  • Page 5: Safety Facility

    Safety Facility Note! Quadruple combination control according to DIN 3440 This device is equipped with a sensor monitoring fea- ture and is cold-resistant down to -20°C; below -20°C the device switches off; when the temperature rises This device has 4 functions: above this temperature, it switches on again.
  • Page 6: Installation Requirements

    Installation Requirements quantities that their ignition causes hazards, exceptions The heaters may only be installed in compliance with the relevant regulations, especially regulations go- may be allowed when appropriate measures have been taken to ensure that the fireplace cannot ignite the sub- verning the installation and operation of fireplaces and stances or mixtures.
  • Page 7 Mark this protection zone with a label bearing the in- Supply of Combustion Air scription: A sufficient supply of combustion air is ensured when this combustion air is drawn from the "Protection zone - keep 1 m clear of the heater" −...
  • Page 8: Chimneys

    (ascending slope of 2% = 2 cm/m) ers of the same type. The double-wall REMKO high-grade steel chimney systems are approved by the German "Institut für These heaters are exclusively for industrial Bautechnik"...
  • Page 9: Installation And Assembly

    Installation Application examples: and Assembly Double-wall high-grade steel chimney, externally installed Device Installation Heater installed upright The device installation procedure must always conform to the national/regional regulations and ordinances. The heaters are suitable for the use of accessories on the air outlet and inlet sides. Ensure that the fan output WS-ME-D (nominal pressure) is adapted to conditions interfering with the air current (measure the nominal current).
  • Page 10 Installation of the Room Thermostat Installation of Burner Install the room thermostat (accessory) at a location The supplied burner is mounted with 4 flange screws to which is well situated for temperature control. the front side of the device. Always follow the supplied operating instructions for the burner! The thermostat sensor must not be immediately ex- posed to a particularly cold or warm air current.
  • Page 11: Start-Up

    Start-up Initial Start-up Start-up of the Fan Motor The initial start-up of the air heater and of its forced-air 1. Drive Check burner must be carried out by the supplier or by a a) Check the fan’s sense of rotation qualified person appointed by the supplier.
  • Page 12: Shut-Down

    Maintenance Heating Switch on the main switch/fuse of electrical system. The user has to have the equipment checked at least Open the fuel supply. once every year by an authorized qualified person to ensure that it is in good working order, in a safe condi- tion, works economically and within the legal emission Set the operating switch on limits.
  • Page 13 5) Using a vacuum cleaner, remove combustion residue from the front and rear collecting box (5). A special cleaning set for the REMKO-industrial vacuum cleaner is available as accessory. 6) Reinstall all parts in reverse order.
  • Page 14: Technical Data I

    Technical Data REMKO VRS nominal heat power nominal heat output 3.400 4.650 6.800 9.750 11.700 15.700 19.300 23.600 29.500 35.200 m³/h nominal air output nominal pressure extern fuel h e a t i n g o i l n a t u r a l / p r o p a n e g a s...
  • Page 15 Technical Data electric-motor(s) fan(s) V-belt pulley sound nom. REMKO pressure nominal press. electr. rated nominal nom. level power version type motor ∆ ext. connection current speed speed consump. pA 1m Type V / Hz ø mm ø mm dB(A) 230 / 50...
  • Page 16 VRS 40 - 450 shown VRS 80 standing version 25 a/b We reserve the right to make modifications in dimensions and construction in the interests of technical progress...
  • Page 17: List Of Spare Parts

    List of Spare Parts VRS Pos. description EDV-Nr. EDV-Nr. EDV-Nr. EDV-Nr. EDV-Nr. EDV-Nr. EDV-Nr. EDV-Nr. EDV-Nr. EDV-Nr. trim panel, top 1104201 1104202 1104202 1104203 1104204 1104205 1104205 1104206 1104207 1104208 unit frame, cpl. 1104209 1104210 1104211 1104212 1104213 1104214 1104214 1104215 1104216 1104217 insulation f.
  • Page 18: Block Diagram 230 V

    Block Diagram 230 V switch box version: 230 V fan motor: 230 V / 1~ burner motor: 230 V / 1~ 2 3 0 V / 5 0 H z Note: Temperature monitor TW1 is exclusively used for 2-stage STB TW2 operation (special version).
  • Page 19: Circuit Diagram 400 V /Up To 3.3 Kw

    Circuit Diagram 400 V switch box version: 1,1 kW (up to 3,0 kW) fan motor: 400 V / 3~ (up to 3,0 kW) burner motor: 230 V / 1~ Note: Temperature monitor TW1 is exclusively used for 2-stage operation (special version). operating switch terminal strip 1 in switch box fan relay...
  • Page 20: Circuit Diagram 400 V /Up From 4.0 Kw

    Circuit Diagram 400 V switch box version: up from 4,0 kW fan motor: 400 V / 3~ (up from 4,0 kW) burnermotor: 230 V / 1~ Note: Temperature monitor TW1 is exclusively used for 2-stage operation (special version). We reserve the right to make modifications in dimensions and construction in the interests of technical progress.
  • Page 21 Circuit Diagram 400 V connection fan motor 400 V / 3~ (up from 4,0 kW) connection burner motor ( 3~ ) lines to thermal overcur- rent relay of burner motor thermal overcurrent relay, fan motor fan motor fuse block, Ventilatormotor room thermostat (accessories) operating switch control fuse...
  • Page 22: Troubleshooting Instructions

    A prerequisite for any material guarantee claims is that the orderer or the orderer’s customer filled out a „guarantee certification” at the time of the purchase and start-up and returned it to REMKO GmbH & Co KG. Guarantee certificates are enclosed with every REMKO heater.
  • Page 24 REMKO GmbH & Co. KG Klima- und Wärmetechnik D-32791 Lage · Im Seelenkamp 12 D-32777 Lage · Postfach 1827 Telefon (0 52 32) 6 06 - 0 Telefax (0 52 32) 6 06 - 2 60...
