Kidde SLICK RF-SFTP Installation Instructions Manual

Wireless alarm base
Hide thumbs

Advertisement

Table of Contents

1209-7201-02(21008418)_V2:_
2011.4.19
9:13 AM
Page 1
®
Wireless Alarm Base
RF-SFTP 230V Mains Operated Wireless Interconnectable
Alarm Base with Rechargeable Battery Backup
For use with the following models with the
designator:
1SFW, 1SFWR, 2SFW, 2SFWR, 3SFW and 3SFWR
Thank you for purchasing a Kidde Fyrnetics alarm accessory.
Please read through our manual in full. Important information
included and the manual must be left with the householder.
Electrical rating 230V AC,
50Hz 100mA max per (maximum 35mA for originating unit
with 16 Devices interconnected).
Kidde Safety Europe, Mathisen Way, Colnbrook, SL3 0HB, UK.
www.kiddefyrnetics.co.uk
© Kidde Fyrnetics 2010
21008418 REV. B
1
1
1209-7201-02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SLICK RF-SFTP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kidde SLICK RF-SFTP

Summary of Contents for Kidde SLICK RF-SFTP

  • Page 1 For use with the following models with the designator: 1SFW, 1SFWR, 2SFW, 2SFWR, 3SFW and 3SFWR Thank you for purchasing a Kidde Fyrnetics alarm accessory. Please read through our manual in full. Important information included and the manual must be left with the householder.

  • Page 2: Installation Instructions - Introduction

    2011.4.19 9:13 AM Page 2 Introduction The RF-SFTP wireless base can be fitted with Kidde Heat and Smoke Alarm models that have the designation following the model number. Up to 15 wireless bases can be fitted in a system due to con- straints of the supervised system (see installers guide of alarm for limits of alarms).
  • Page 3 If installing using old cabling (different colors), take great care / follow IEE Reqs. A maximum of 24 Kidde devices may be interconnected in a multiple station arrangement the interconnect system should not exceed 12 Smoke Alarms and/or 18 alarms total (Smoke, Heat, CO and etc).
  • Page 4 1209-7201-02(21008418)_V2:_ 2011.4.19 9:13 AM Page 4 RF-SFTP Wireless Base Set – Up 1. The smoke alarms and wireless base should be positioned as rec- ommended in the installation guides supplied with the alarms with special care to avoid possible causes of interference with the RF signal(such other wireless products, electronic devices and large metal objects).
  • Page 5 1209-7201-02(21008418)_V2:_ 2011.4.19 9:13 AM Page 5 7. Go to the nearest unit (this will be a remote unit) and press and release the enrol button. The amber LED will flash - 2 seconds on and 2 seconds off (it may immediately start flashing 1-6 times if it catches a message from the master).When it has received an invitation from the master unit the amber LED will flash 1-6 times every 4 seconds to indicate the signal strength;...

  • Page 6: Fault Finding Chart

    1209-7201-02(21008418)_V2:_ 2011.4.19 9:13 AM Page 6 LED Settings Chart Green Amber Comment Factory Not enrolled in setting system Blinking every 4 2 seconds on every Master unit enrolling sec. 4 seconds remotes. 2 seconds on every Remote waiting Enrol 4 seconds mode 1-6 flashes every 4 Remote...
  • Page 7 1209-7201-02(21008418)_V2:_ 2011.4.19 9:13 AM Page 7 Adding an additional wireless unit This process is to enrol additional wireless bases to an existing system. 1. Install and power up the new unit. The Amber and the Green LED of the new wireless base will both be on. 2.
  • Page 8 1209-7201-02(21008418)_V2:_ 2011.4.19 9:13 AM Page 8 Monitoring the Wireless link. • The system is designed to automatically and continuously monitor the wireless link between the alarm. when powered by AC mains (230Volts) • The master alarm broadcasts every 10 seconds; the green LED will flash to indicate this.

  • Page 9: Technical Specification

    1209-7201-02(21008418)_V2:_ 2011.4.19 9:13 AM Page 9 Technical Specification Mains power: 230VAC / 50Hz. Backup Power: Lithium secondary battery with up to 3 month capacity Temperature (operating): 0 – 40°C Humidity: 0-95% (non-condensing) Radio Frequency: 868MHz Wireless range: Greater than 150m in free space. Mechanical: 12.7cm dia x 3.5cm 150 g.
  • Page 10 9:13 AM Page 10 Guarantee Kidde Fyrnetics guarantees to you as a purchaser that the alarm accessory will be free of defects in material, workmanship or design under normal use and service for a period of ten (10) years, from the date of purchase.
