1235-7223-07
11/3/05
230V Interconnectable Mains Operated Alarms For models:
123I, 123/9HI, 123/9HILL, 223I, 223/9I, 223/9ILL, 223/9HI,
Thank you for purchasing a Kidde Fyrnetics alarm.
Please read through our guide in full. It should be retained for future reference.
Kidde Fyrnetics recommends for maximum protection that both ionisation and
photo-electric (optical) smoke alarms be installed. Ionisation technology is faster at
detecting fast flaming fires that give off little smoke. Photo-electric (optical) technol-
ogy is faster at responding to slow, smouldering smoky fires.
Heat alarms should be installed in environments where excessive steam, dust etc.
make smoke alarms impractical e.g. kitchens/boiler rooms/lofts.
Electrical rating 230V AC,
50Hz 80mA max per alarm
(maximum 80mA for originating unit
with 24 alarms interconnected).
*Kite mark is not applicable to 300 series models.
Kidde Safety Europe, Mathisen Way, Colnbrook, SL3 0HB, UK.
The additional Owner's Manual should be left in a safe place
Contents
Section 1.
Section 2.
Section 3.
Installing Alarm
Section 4.
Section 5.
Interconnecting
Section 6.
Section 7.
Section 8.
L.E.D. Status
Section 9.
Ongoing Maintenance
Section 10.
Battery Replacement
Section 11.
Repair/Servicing
Section 12.
Troubleshooting
Section 13.
Section 14.
Service and Guarantee
Section 15.
15:39
Page 1
www.kiddefyrnetics.co.uk
© Kidde Fyrnetics 2000
for the property owner. e.g. near Consumer Unit.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Smoke and Heat alarm
Installer's Guide
223/9HILL, 323/9HI, 323/9HILL
*
Lic No: 7861
BS 5446: Pt. 1: 2000
. . . . . . . . . . . . . . . . . . . . . . . . .2
. . . . . . . . . . . . . . . . . . . . . . . .3
. . . . . . . . . . . . . . . . . . . . . . . . . . .5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
1
. . . . . . . . . . . . . . . .2
1235-7223-07
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kidde 123I
Summary of Contents for Kidde 123I
- Page 1 Thank you for purchasing a Kidde Fyrnetics alarm. Please read through our guide in full. It should be retained for future reference. Kidde Fyrnetics recommends for maximum protection that both ionisation and photo-electric (optical) smoke alarms be installed. Ionisation technology is faster at detecting fast flaming fires that give off little smoke.
- Page 2 1235-7223-07 11/3/05 15:39 Page 2 1. Installation Instructions – Introduction This alarm is designed for installation by a qualified electrician, in accordance with the latest I.E.E. Regulations and in regard to relevant Building Regulations. • Read these instructions thoroughly before proceeding. Peoples lives depend on it.
- Page 3 1235-7223-07 11/3/05 15:39 Page 3 • On peaked ceilings install within 900mm (36") of highest point. Sloped/Peaked Ceilings 102 mm Not in this area (4 in) Anywhere in this area 900 mm 900mm (36 in) (36 in) 300mm (12") Flat Ceilings Dead •...
-
Page 4: Kidde Fyrnetics
I.E.E. regulations. • Select suitable location having regard to earlier advice. • Bring house wiring through a dry lining box or Kidde Fyrnetics Surface Pattress, into terminal block. • If alarm is not being interconnected, the white interconnect cable from the alarm is unused. -
Page 5: Section 5. Initial Testing And Checking Of Alarm
New harmonised colours; if interconnecting using old & new cable take great care / follow IEE Reqs. • You may interconnect up to 23 Kidde Fyrnetics AC smoke, heat or CO alarms to this unit. i.e. 24 in total. •... -
Page 6: Section 8. Decorating
1235-7223-07 11/3/05 15:39 Page 6 • All interconnected alarms must be powered off the same fuse/circuit breaker. • Total cable length between alarms must not exceed 250m (273yds) and be 1.0mm in diameter, 3 core and earth (BS6243Y). These smoke/heat alarms are Interconnectable with Kidde Rechargeable CO Alakms models 423D/9hir &... -
Page 7: Section 11. Battery Replacement
1235-7223-07 11/3/05 15:39 Page 7 11. Battery Replacement (AC models with loose battery only) • If the alarm type has replaceable battery cells, they should be replaced annually. (If using alkaline, this can be extended to 2 years). • A chirp once every 40 seconds indicates the battery needs replacement. -
Page 8: Section 14. Limitations Of Smoke/Heat Alarms
AC or DC electrical power. The liability of Kidde Fyrnetics, arising from the sale of this alarm or under the terms of this guarantee shall not in any case exceed the cost of replacement of the alarm, in no case,...
