DISPLAYPORT OUTPUT FORMATS
WatCHpaX 40 complies with displayport version 1.4.

ADAPTERS

the usage of passive adapters is not recommended as it may result in a lower maximum resolution.

HDCP

High-bandwidth digital content protection (HdCp) is not supported by WatCHout.

PLAYBACK FORMATS

SUPPORTED PLAYBACK FORMATS
mpeG-2/H.262
aVC/H.264
Hap
Hap Q
Hap alpha
prores 422 proxy
prores 422 Lt
prores 422
prores 422 HQ
tGa
tGa + alpha
tIff
tIff + alpha

HARDWARE ACCELERATED VIDEO FORMATS

WatCHpaX 40 supports Gpu-accelerated video decoding. Hardware acceleration is enabled by
default in WatCHout and this property can be changed by the user per media item. the codecs
supported are listed below.
CODEC MAX COLOR
aVC/H.264 8-bit
mpeG-2/H.262 8-bit

supported formats

5. SUPPORTED FORMATS
MAX RESOLUTION MAX LEVEL
4096 × 4096 5.2
4080 × 4080 n/a
MAX PROFILE FORMAT
High 4:2:0
n/a 4:2:0
