- Page 1 Oil mist filter Filter för oljedimma miSt wiz ard User manual Bruksanvisning www.plymovent.com...
- Page 2 ENgliSh Page MistWizard MW-2 • Spare parts SvENSka MistWizard MW-2 • Reservdelar 0000117115/180618/A MistWizard...
-
Page 3: Technical Description
To AChiEvE oPTiMUM fUNCTioN AND SAfETy, PlEASE rEAD ThiS MANUAl BEforE USiNG yoUr filTEr. Plymovent MW-filter is specially designed to handle oilmist from both emulsions and straight cutting fluids. The filter has a unique combination of different filtration methods. The captured oilmist passes a rotation-filter stage where most of the mist condenses and is collected in the filter's separation chamber. -
Page 4: Safety Information
5. All electrical maintenance must be carried out by an authorized electrician. Design and function Plymovent Mist Wizard filter is a highly effective mechanical filter for filtration of oil mist. The unique design removes the oil mist in two stages. These are incorporated in order to maximize their effectiveness. -
Page 5: Options And Accessories
FUA-1300 (215) 230V/1ph/50Hz 0000100300 Speed of revolutions: 2800 rpm. FUA-1300 (435) 230-400V/3ph/50Hz 0000100302 Outlet: Ø 160 mm. Mounting bracket Wall mouting bracket for MistWizard. MB-MW/W 0000100777 Fan kit Fan mounting kit. To be used with FUA- MW-FAN-KIT 0000100778 1300. Stand Stand for elevated machine mounting. -
Page 6: Mounting Instruction
Wizard handed over, copied, xeroxed or translated into another language in any form or means without written permission from Plymovent AB. Plymovent AB reserves the right to make design changes. Direct mounting to machine: To enter the machine (1.) a Ø165 opening is needed. filter stand MW-STA (2.) can be used (accessory). - Page 7 To applicate inlet with drain: MW-iNl MW-INLET Applicate inlet with drain (1) using supplied detailes. To applicate adjustable fan outlet: MW-oUT MW-OUTLET Applicate adjustable outlet (1.) using supplied detailes. 0000117115/180618/A MistWizard EN - 6...
- Page 8 Note! Bracket (1) universal for iEC and NEMA motors. Note! When connected to an external ductwork, always use a hose connection or other quick coupling between fan outlet and ducting to allow easy filter access. MistWizard/ENG/USA/CAN/7/11 0000117115/180618/A MistWizard EN - 7...
- Page 9 1. MW-fAN-KiT location for plastic spigot 2. fAN: fUA-1300, 1301 when using fan. 3. CArT olE: Cartridge, oleofob. 4. Manometer. 5. MW-W: Wall mounting bracket. MB-MW/S1: wall mounting bracket location for plastic spigot without fan. MistWizard/ENG/USA/CAN/8/11 0000117115/180618/A MistWizard EN - 8...
- Page 10 Wizard handed over, copied, xeroxed or translated into another language in any form or means without written permission from Plymovent AB. Plymovent AB reserves the right to make design changes. Pressure drop check Bad filtration or low airflow, check differential pressure manometer.
-
Page 11: Spare Part Drawing
Ser. No: MW / RR handed over, copied, xeroxed or translated into another language, in any form or any means without Date: FEB-11 written permission from PlymoVent AB. PlymoVent AB reserves the right to make design changes. Replace: Dec-01 Produkt No: Decription ©... -
Page 12: Teknisk Beskrivning
Filtret har en unik kombination av filtrering i olika steg. Den uppsamlade oljedimman passerar rotations filtreringen där det mesta av oljedimman kondenseras och avskiljs. nästa steg är huvudfil- tret där de minsta partiklarna av oljedimman och stoft avskiljs. MistWizard Filtret finns i två olika storlekar vilket innebär stor flexibilitet av luftflöden. -
Page 13: Uppbyggnad Och Funktion
5. all elektrisk service skall göras av behörig elektriker. Uppbyggnad och funktion: Plymovent MistWizard Filter är ett högeffektivt mekaniskt oljedimfilter. en unik konstuktion renar oljedimma i två steg. Filtreringen sker i sådan ordning att effektiviteten i oljedimavskiljningen maximeras. Den uppsamlade oljedimman dräneras direkt ned i maskinen eller samlas upp. - Page 14 FUA-1300 (215) 230V/1ph/50Hz 0000100300 Speed of revolutions: 2800 rpm. FUA-1300 (435) 230-400V/3ph/50Hz 0000100302 Outlet: Ø 160 mm. Mounting bracket Wall mouting bracket for MistWizard. MB-MW/W 0000100777 Fan kit Fan mounting kit. To be used with FUA- MW-FAN-KIT 0000100778 1300. Stand Stand for elevated machine mounting.
- Page 15 Mist Wizard handed over, copied, xeroxed or translated into another language in any form or means without written permission from Plymovent ab. Plymovent ab reserves the right to make design changes. Direktmontera på maskin Markera hål och hålbild för montage på maskin (1) och genomför håltagning, Ø165mm är lämpligt.
- Page 16 Montering av inlopp med dränering: MW-InL MW-INLET Montera inloppet (1) med medlevererade detaljer. Montering av justerbart utlopp: MW-oUT MW-OUTLET Montera justerbara utloppet (1.) med medlevererade detaljer. 0000117115/180618/A MistWizard SE - 15 MistWizard/eng/USa/can/6/11...
- Page 17 (3) och fäste (1). obS! Fäste (1) passar flera typer av motorer. obS! när utloppet skall anslutas till extern kanal måste slang eller annan typ av snabbkoppling monteras mellan kanal och fläktens utlopp. MistWizard/eng/USa/can/7/11 0000117115/180618/A MistWizard SE - 16...
- Page 18 1. MW-Fan: Fläkt kit. Placering av plaststos när FUa-1300, 1301 2. FLäKT: fläkt skall monteras. 3. caRT oLe: Filterpatron oleofob. 4. Manometer. MB-MW/S1: väggmonteringsdetaljer 5. MW-W: väggmonteringsdetaljer. Placering av plaststos när fläkt ej används. MistWizard/eng/USa/can/8/11 0000117115/180618/A MistWizard SE - 17...
- Page 19 Mist Wizard handed over, copied, xeroxed or translated into another language in any form or means without written permission from Plymovent ab. Plymovent ab reserves the right to make design changes. Differenstryck kontroll Lågt flöde eller försämrad filtrering, kontrollera tryck- mätaren.
- Page 20 0000117115/180618/A MistWizard www.plymovent.com...
