       User Manual









VATAR

®
III




Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVATAR III and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Robotex AVATAR III

  • Page 1 2014 Edition                      ® VATAR                                                    User Manual                   www.robotex.com                      ...
  • Page 2: Table Of Contents

    Table of Contents  Safety Information  3  4  Avatar ®  III Overview  Basic Setup  5‐8        Pre‐use Setup   5‐7  5               Setting up the Flippers  Installing the Battery  5  6  Attaching the Antennas  7  Powering On the Robot and Controller  8       Post‐Use Maintenance                Charging the Robot Battery  8  8  Charging the Controller Battery  8  Folding in the Flippers  Handheld Controller Overview  9‐19  10   Basic Avatar® Controls               Controller Touchscreen Functions and Display   12‐19  16  Video Recording  PTZ Controls ...
  • Page 3: Safety Information

          Safety Information      Read this manual carefully before operating the Avatar® III.    Carefully inspect the Avatar III before each use.  ®    Ensure that all parts are secured in place and properly installed. Do not try to make repairs  yourself. Parts may not work properly if they have been repaired by a party other than  RoboteX, Inc.     Do not modify any components on the robot yourself. Doing so may cause permanent  damage not covered by your warranty.     Do not place fingers in between the tracks or flippers when the unit is powered on. Keep  fingers and other body parts away from moving parts at all times.    Care should be taken when running the Avatar® III near pedestrians, small children, or  objects that can be harmed. Be aware of your and the robot’s surroundings at all times.    AC Adapter Handling:   Use only the supplied AC adapter. Do not use any other unauthorized AC adapters.  Damage to robot and battery may occur from use of alternate AC adapters.      FCC Caution: This equipment generates and uses radio frequency energy and may cause  interference to external reception if not installed and used properly in strict accordance  with the manufacturer’s instructions.    Before switching payloads/accessories on the robot, make sure the battery is unplugged  and the unit is powered down.    ...
  • Page 4: Avatar® Iii Overview

    Avatar® III Overview  The Avatar® III is a compact, lightweight robotic platform that is part of  the RoboteX Avatar® Series.  Designed from the ground up for  portability, expandability, and ease‐of‐use, the Avatar® III serves as a  useful tool for a variety of users.    The Avatar® III can be customized with a variety of plug‐and‐play  accessories. These accessories facilitate use of the robot in a variety of  scenarios, including Tactical, CBRNE, EOD, K9, and personal security  settings. Visit www.robotex.com or contact your Account Manager for  more information.  4  Avatar® III User Manual                                                          Rev D 12/2015      ...
  • Page 5: Basic Setup

    Basic Setup and Maintenance    1) Pre‐Use Setup  A) Setting up the Flippers  Before driving the robot, please make sure that both sets of flippers are unfolded and  locked in place. If the robot is being taken out of a case, it is likely that both sets of flippers  will be folded in.  Straighten out the front set and back set of flippers separately. When unfolding a set of  flippers (front or back), make sure to grip both flippers and move the two flippers in each  pair (front pair or back pair) at the same time. Push outward (away from payload ports ‐  it’s OK to apply some force) to straighten out the flippers.  Both sets of flippers should lock into place.  When in use the back flippers should be flat  against the ground and remain stationary.  The front flippers can be moved up and down  with the controller.    B)  Installing the Battery    1) The battery bay is located on the side of the robot. To open the battery bay, grip the  “Closing Knob” and push in, turning the knob in counter‐clockwise direction. You  should feel a slight “pop” or “click,” indicating the door is open. Pull the latch outward  and pull out the battery ejector bar to open the battery bay.    2) To install the robot battery, line up the connectors on the battery with the slots inside  the battery bay. Next, gently slide the battery into the bay. A properly installed battery  will slide entirely into the robot – if any part of the battery is sticking out, remove  battery, check alignment of connector with battery bay, and reinsert.   5  Avatar® III User Manual                                                          Rev D 12/2015      ...
  • Page 6: Attaching The Antennas

    3) Close the battery bay door by returning the  door to its closed position, making sure the  folding bar is folded over the battery and the  upper lip of the battery door tucks underneath  the top strip of the battery bay. Shut the latch  and turn the “Closing Knob” clockwise. You  should feel a “pop” or click” when the battery  door has closed.   When closing the battery door,  IF FLIPPERS ARE BLOCKING THE BATTERY   make sure the lip at the top strip  DOOR, MOVE FRONT FLIPPERS AND BACK   of the battery door tucks  FLIPPERS.  FRONT AND BACK FLIPPERS MUST   underneath the top of the battery  BE MOVED IN PAIRS. DO NOT MOVE ONE   bay.  FLIPPER AT A TIME.    C) Attaching the Antennas  Make sure that the controller antenna is attached before powering the unit on.  (Also  make sure you don’t power on the robot without the robot radio installed)  The controller antenna attaches to the  silver port on the top left of the controller.  DO NOT plug it into the covered black port  on the top right side of the controller.  If  you have more than one radio, make sure  you are attaching the appropriate antenna  for the radio you have installed. The  controller antenna will be color  coordinated with the robot radio antenna.      DO NOT PUT ANTENNA ON RIGHT    PORT (COVERED BY BLACK CASING).  DOING SO WILL PERMANENTLY DAMAGE  YOUR CONTROLLER.  ...
  • Page 7: Powering On The Robot And Controller

    D) Powering On the Robot and Controller   Robot  There is no on/off switch on the robot itself. The robot is powered on and off by inserting  and removing the battery.    Power On: The robot is powered on whenever the battery is installed.  Power Off: The robot is powered off whenever the battery is removed.      There is a third option where the battery may be stored in the robot and the robot remains  powered off.  To do this, press the red button on the opposite side of the robot from the  battery bay and hold until the battery door is closed.  If the fans didn’t turn on, the robot is  powered off.  If you press the button when the robot is already on with the battery  installed, it does nothing.      If you’ve used the red button, simply remove the battery and put it back in to power on the  robot.                  Controller   The Controller has a small black power button located in the top right corner of the  controller (just above the screen).    Power On: The Controller is powered on by pressing the black round power button.  Power Off: The Controller is powered off by pressing and holding the black round power  button down until the LED light turns off.        7  Avatar® III User Manual                                                          Rev D 12/2015    ...
  • Page 8: Post-Use Maintenance

    2) Post‐Use Maintenance  A) Charging the Robot Battery   After removing the battery from the Avatar® III, align the charger and battery  connectors and plug the adapter into an AC wall outlet.   Battery is fully charged when the indicator on the top of the battery shows 5 full  black bars, or when the indicator light on the top of the charger turns green (if you  choose to, it is alright to leave the battery on the charger).   To check charge levels, you can refer to the charge indicator on the battery itself,  which will tell you how much charge is left. You can also look at the on‐screen  controller indicators (see page 12).    These are the indicator bars.  The dark    bars reflect the amount of charge in  the battery.  Five black bars mean the  battery is fully charged.  When no    black bars are present, the battery is  empty.  The battery in this picture    shows a battery with just under a full    charge.   B) Charging the Controller Battery   Plug the adapter into an AC wall outlet.   Plug the round adapter plug into the round charging port on the bottom of the  controller.    The controller is fully charged when the LED light on the controller turns off or  flashes red. If the LED light is solid red, the controller is charging.  You should leave  the controller on the charger when not in use. ...
  • Page 9: Handheld Controller Overview

      Handheld Controller Overview The RoboteX Avatar® III comes with a portable handheld controller for  straightforward, easy operation.  The controller is equipped with a  simple button layout and a touchscreen for enhanced functionality and  ease‐of‐use with all robot accessories. The image below displays basic  robot and PTZ camera controls.     9  Avatar® III User Manual                                                          Rev D 12/2015      ...
  • Page 10: Basic Avatar® Controls

    1) Basic Avatar® III Controls  Please refer to Figure 1 on page 11 for controller button diagram and labels.   A) Powering On/Off, Audio Volume, and Robot Movement  Power On/Off Button:   Powers the controller on and off.  Incoming Volume Control Knob:   Push up = incoming audio volume increases   Push down =  incoming audio volume decreases   Robot Control Joystick (Left Joystick):   The left joystick controls robot movement (left/right and forward/reverse).   The robot responds to a range of input – the further you push the stick, the faster  the robot will move. For slow movement, push lightly on the joystick.  There are  two speed modes, high and low that will be discussed on page 14.    B) Flipper Control, IR/LED Light, and Push‐to‐Talk Audio  Flipper Control Knob (Right Knob):   Push up = flippers go up   Push down = flippers go down  Note: When pushing the flipper control knob down, the flippers themselves will  stop automatically once they are flat on the ground. To position the flippers below  this position, release the flipper control knob and then push down again.  LED Light Switch (Yellow Button):   Switches the robot’s front LED Light ON/OFF.  Two‐Way Audio “Push to Talk” Button (Blue Button):   Hold down for outgoing audio – to project your voice from the robot.   Release to hear incoming audio – to hear what the robot hears.   Note: Unless the blue button is pressed, incoming audio is on by default. There is ...
  • Page 11 Figure 1  Controller Diagram for Avatar® III with PTZ Camera Payload            11  Avatar® III User Manual                                                          Rev D 12/2015      ...
  • Page 12: Controller Touchscreen Functions And Display

    2) Controller Touchscreen Functions and Display   A) Touchscreen Display  The following icons will be displayed on the Avatar® III’s controller screen (in drive camera  view):    Display  Description Location: Top right of the screen    Indicates charge level of the robot battery.  Location: Top right of the screen     Indicates charge level of the controller battery. (Note:  The yellow electric bolt icon will appear if the  Controller is plugged into an external power source).             12  Avatar® III User Manual                                                          Rev D 12/2015      ...
  • Page 13 Location: Top left of the screen   Indicates the wireless signal strength between the  controller and robot.  This will show a red X mark  when there is no connection.  If this symbol shows for    longer than 1 minute see troubleshooting page 22.  Location: Top left of the screen Replaces normal signal strength icon and indicates  that the controller is having radio problems. See  troubleshooting page 22 if you are having connectivity  issues.    Location: Lower left of the screen  Indicator showing the relative flipper positions.    Location: Top left of the screen   Indicates the robot and controller are connected  under point‐to‐point mode (direct wireless  connection).  The only other mode would be repeater  mode (for customers who have repeaters).                      13  Avatar® III User Manual                                                          Rev D 12/2015      ...
  • Page 14 B) Touchscreen Controls  RoboteX Avatar® III’s on‐screen display also features a touchscreen.  The following  touchscreen buttons can be used to control the Avatar® III:  Menu Buttons ON/OFF –  Located on the bottom left of the screen.  Press to show / hide the menu:   Menu On  Menu Off                                                                                                       IR Light ON/OFF ‐  Located on the right of the screen.  This button is only visible if menu  buttons are turned on.  Press to turn on and off the IR Light:    IR Light Off  IR Light On                                                                                                   High Speed/Low Speed Mode ‐  Located on the right of the screen.  This button is only  visible if menu buttons are turned on.  High speed is the robot’s default speed.  The  optional Low Speed is recommended for climbing stairs.  Press to switch between robot High Speed and Low Speed mode:  High Speed  Low Speed  Mode  Mode                                                                                                   14  Avatar® III User Manual                                                          Rev D 12/2015      ...
  • Page 15 Position Indicator Mode –  Located on the right of the screen.  This button is only    visible if menu buttons are turned on. Press to show / hide the position indicators (flippers and PTZ or Arm if they are on the  robot).   Position  Position  Indicator(s)  Indicator(s)  OFF                                                                                                     Digital Zoom‐  Located on the right of the screen.  This button is only visible if menu  buttons are turned on.      Pressing this button pops up a window to choose 1x, 2x, or 4x zoom.  1x is normal view.      Screen Brightness –  Located on the bottom middle of the screen.  Tap ‘+’ or ‘‐‘ to adjust the brightness of the handheld controller screen:         15  Avatar® III User Manual                                                          Rev D 12/2015      ...
  • Page 16: Video Recording

    Channel Selection  – Located at the top left of the screen.  To activate the Channel Selection capability, press   and it will prompt the  following box:        First select the channel to be set to, and then press the ‘Set Channel’ button.  Changing  channels can take up to 1 minute depending on the signal strength and surrounding  condition.  If the channel is not switched successfully, it will automatically return to the  default channel which can take up to 2 minutes.  The number next to the signal strength bars indicates the current channel.  NOTE:  IF YOU HAVE A 900 MHZ RADIO, IT WILL ONLY WORK ON CHANNELS 3, 5,     AND 7 (5 USUALLY WORKS THE BEST).  DO NOT SELECT THE OTHER CHANNELS AS THE  PERFORMANCE WILL BE POOR ON THESE CHANNELS.  Video Recording  To activate the Avatar® III’s audio and video recording capability, press   and it  will prompt the following box:  Showing amount of time  remaining for recording Press to start recording    The dot flashing dark and light red       indicating recording in progress     Press ‘REC’ again to prompt the box for stopping the recording:  Press to stop recording    16  Avatar® III User Manual                                                          Rev D 12/2015      ...
  • Page 17 Note: Audio level in the recording is controlled by the level of audio on the controllers.   Also, if the audio level is turned on, the video will record the audio from robot to  controller by default.  If the Push‐to‐Talk button is pressed, all audio in range of the  controller will be recorded.   Video Retrieving  1) Insert a USB flash drive into controller’s USB port (USB 2.0 formatted in FAT32). Note:  16GB size recommended.  2) Follow prompts on screen. You will see two prompts, one after the other.  a. “Copy Video to USB?” – Prompts you to transfer the video files from the  controller’s internal memory to the USB stick. Hit “yes” to transfer or “no”  to save transfer for later date.    b. “Delete local backup?” – Asks if you want to clear the controller’s internal  memory. Hit “yes” to clear and “no” to keep video stored internally for  transfer at a later date.  NOTE: It is recommended you delete local backup  after each time you transfer video to a USB stick.      3) Follow the onscreen prompts and wait for video transfer to complete. Remove the  USB flash drive when prompted.  4) Video files are now on the USB flash drive. Plug the USB flash drive into a computer  to view or download the video files.  5) Any recorded video less than 6 minutes long will have an individual file. If the video is  longer than 6 minutes, it will be divided into 6‐minute segments and stored as  multiple files. There may be a minimal (up to one second) loss as it changes from one  segment to the next.  The video files will have a name format such as ‘vid‐00010‐002’,  where 00010 indicates this is the 10  video recording, and 002 means it is the second  section of the 10  video recording.   17  Avatar® III User Manual                                                          Rev D 12/2015    ...
  • Page 18: Ptz Controls

    6) NOTE: Depending on the setup of your video player program, you may need to  download VLC Media Player to play the video files. VLC Media Player is a free  download from many sources.  Visit www.videolan.org or contact your RoboteX  Account Manager for help downloading and installing VLC media player.         3) PTZ Controls  A) Pan‐Tilt‐Zoom (PTZ) Camera Controls  Please refer to Figure 1 on page 11 for controller button diagram and labels for PTZ use.   Camera View Switch (Green Button):   Switches between the drive camera view, the PTZ Camera view, and the split screen  view (displays both drive camera and PTZ Camera views).  PTZ Camera Control Joystick (Right Joystick):   The right joystick maneuvers the 360° PTZ Camera’s movement (both side‐to‐side  and up‐and‐down). See below for more details.  PTZ Camera Zoom Knob:   Push up = camera zooms in   Push down = camera zooms out    C) Pan‐Tilt‐Zoom (PTZ) Camera Touchscreen Display and Controls    18  Avatar® III User Manual                                                          Rev D 12/2015      ...
  • Page 19 Location: Top left side of the screen    PTZ pan position indicator: a viewer showing the  relative pan position of the PTZ      PTZ Automatic Home Position ‐ Located on the right of the  screen.  This button is only visible if menu buttons are   turned on.    PTZ Menu ‐ Located on the left of the screen.    Brings up the below PTZ Options.   PTZ Options:   Press to prompt three options: Reset, Manual Focus, and Defrost Fan On/Off     Reset ‐ resets the PTZ camera auto focus.    Manual Focus – press to bring up the following box.  Tapping ‘+’ and ‘‐‘ adjusts the focus of the camera   (this helps when the PTZ camera automatically  focuses on dome instead of the distance)   Pressing ‘auto focus’ allows the PTZ camera to  optimize its focus automatically.   Defrost Fan On/Off – pressing this will turn on a defrost fan inside the PTZ. It will  help clear the view when PTZ dome starts to get fogged.  To turn off the defrost fan, press ‘Defrost Fan Off’ icon.  19  Avatar® III User Manual                                                          Rev D 12/2015      ...
  • Page 20   20  Avatar® III User Manual                                                          Rev D 12/2015      ...
  • Page 21: Maintenance Checklist

    Maintenance Checklist    A) Pre‐use Checklist:  Ensure that all components are attached properly.  Ensure that the controller antenna is tightly attached to the correct port.  Ensure that the robot battery is firmly secured and the battery door completely closed.   Ensure that the tracks are not damaged and are free of debris.  Ensure that the robot camera lenses are properly cleaned.  If the Avatar® III has been out of use for a long period of time, ensure that the  Controller and Robot batteries are fully charged.  Do a pre‐run test drive in a safe area to ensure the signal does not have interference  that may compromise robot functionality during a mission.  B) Post‐use Checklist:  Turn off the controller when the Avatar® III is not in use.  Take the battery out of the robot when the robot is not in use and store in a cool, dry  place.  After using the Avatar® III, it is necessary to perform routine basic maintenance.  Failure to perform maintenance may damage parts and increase wear.  o Ensure that all components are dry and properly wiped clean.  o Ensure that the side cooling fan is not obstructed with debris and spins freely.    o If the robot is particularly dirty, spray the robot with garden hose.  If you are using a  hose with a nozzle maintain a distance of 3 feet from the robot. You can also use  canned compressed air to blow dust and debris off the robot. Use hand soap to  remove additional grime. Do not use a pressure washer, abrasive cleaners, or an air  compressor on the robot, as this may damage the robot’s water sealing gaskets.  o Check for any damaged or worn‐out parts that need to be replaced or repaired  before the robot’s next use.                                  21  Avatar® III User Manual                                                          Rev D 12/2015      ...
  • Page 22: Troubleshooting

     Battery (door is closed)    If the Avatar® III is still not functioning properly, try the following:   Turn off the controller.    Power the controller back on.   Remove and reinsert the robot battery, ensuring that the connectors align.     If the reboot still does not solve the problem, please refer to the following list of  common problems and solutions. If problems persist, please contact Customer  Support or your Account Manager.      A.  The robot has range or signal strength problems (ex. less than 50 yards line of  sight) or will not connect to the controller.    1:  Strong radio devices in the area may be running at the same frequencies that  the robot uses. Some houses with stucco and wire mesh are difficult to penetrate  with radio signals. Try moving closer to the robot or moving away from possible  sources of radio interference.      2:  Try to keep the robot with its antenna right side up.  If the robot has tipped  over it will lose a significant amount of range.  In some cases, the range can be cut  to 10‐15% of normal.  It can usually be righted by manipulating the flippers.    3: Hold the controller as upright as possible. The controller antenna should be kept  perpendicular to the ground for maximum range and signal strength.    4:  Other non‐RoboteX robots may cause interference. Try moving the Avatar® III  away from the other robot.      22  Avatar® III User Manual                                                          Rev D 12/2015      ...
  • Page 23 5: If a red “X” is displayed over the signal strength indicator on the controller  screen, the robot radio may be having a problem. First try turning the robot off  and on by removing and reinstalling the battery. If this does not solve the problem  try removing the robot radio. To remove the robot radio, first be sure that a  battery is not installed in the robot. Remove the robot radio by loosening the two  large flat head screws on either side of the handle at the back of the robot. Once  the screws are loose, pull the handle and the entire robot radio with the antenna  will come out of the robot. Be sure that the electrical connectors on the robot  radio and the corresponding connectors on the robot are clean. Reinstall the robot  radio by hand, being sure that the robot radio is fully seated, then tighten the two  flat head screws firmly and test to see if the problem is resolved. If the problem  persists call our Customer Support line.    6: If a yellow triangle is displayed over the signal strength indicator on the  controller screen, the controller radio may be having a problem. First try turning  the controller on and off several times. If this does not fix the problem, try  removing and then reinstalling the controller radio. First, be sure that the  controller is off. To remove the controller radio, loosen the two flat head screws  on the back side of the controller. Once the screws are completely loose gently  pull/pry the controller radio off of the controller. Be sure that he electrical  connectors on the controller radio and the corresponding connectors on the  controller are clean. Reinstall the controller radio by seating the radio by hand  then tighten the two flat head screws firmly and test to see if the problem is  resolved. If the problem persists call our Customer Support line.      B. The Pan Tilt Zoom camera does not work.    1: Try using the PTZ camera reset feature on the controller.    2: Remove the battery then remove and reinstall the PTZ camera. To remove the  PTZ camera, loosen the 4 flat head screws at each corner of the PTZ camera. When  all 4 screws are loose, pull up on the camera and remove it from the robot. Be sure  that the electrical connector on the PTZ camera and the corresponding connector  on the robot are clean. Reinstall the PTZ camera by making sure that it is fully  seated by hand, then tighten down the 4 mounting screws and test to see if the  problem is resolved. If the problem persists call our Customer Support line.   ...
  • Page 24     D. The robot has trouble climbing stairs.    1:  The robot is not meant to climb stairs at full speed.  Switch to Low Speed Mode  (See page 14) while climbing stairs.    2:  After climbing the first step, make sure the front flippers are positioned as  though flat against the ground. Hold down the flipper control knob until flippers  are flat.    3:  The robot may have difficulty climbing certain kinds of stairs (slippery metal  stairs and those with slick edges when wet). Dry off the robot and attempt again.    4:  The robot will not be able to climb up the first step if the flippers are not  manipulated correctly.  To climb stairs, put the robot in low gear.  Position the  front flippers so that the tip of the flippers will be above the leading edge of the  first stair. Slowly approach the first stair until the front flippers are touching the  leading edge of the first step, and then lower the front flippers, lifting the front of  the robot, until the flippers are in a "flat" position. Now slowly drive the robot up  the stairs.     5: Some stairs are too steep for the robot to climb. A set of High Angle Stabilizers  came with your robot.  They can also be purchased separately.  They are to help  climb especially steep sets of stairs and taller objects.  Contact RoboteX for more  information.      E. After removing the robot from the case, the Controller does not turn on.    1: The Controller loses charge when left sitting unused for a long period of time; it  may have fully discharged in shipment or after sitting unused in the case. Try  recharging the Controller for 2 or 3 hours before using it again. The controller is  fully charged when the red LED light turns off or flashes red.  You can also use the  24  Avatar® III User Manual                                                          Rev D 12/2015      ...
  • Page 25 robot while it is plugged into an external power source.  If the problem persists,  call our Customer Support line.      F. The robot does not power on when a battery is installed.    1: Check to see that the battery is not completely discharged.    2: Be sure that the connections on the battery are clean and that the  corresponding connections on the robot are clean.     3: If the robot or battery is wet when the battery is inserted, water may get into  the battery connector and prevent the robot from powering up. Use canned  compressed air or a hair dryer to dry the connectors on the battery and the  corresponding connector on the robot. It may be necessary to let the robot dry for  24‐48 hours before attempting to use the robot again.    4: Check the red power button on the left side of the robot. It should move freely.  If it does not move or it is jammed, try moving the metal shroud that covers the  cooling fan by hand. It may be necessary to remove the metal shroud and clean  any dirt or debris from around the red button. If the problem persists, call our  Customer Support line.  25  Avatar® III User Manual                                                          Rev D 12/2015      ...
  • Page 26: Customer Care

    Customer Care    RoboteX, Inc. is committed to providing excellent customer support. As an Avatar®  II  owner, you will have a dedicated Account Manager that can provide support and  troubleshooting assistance.   If you have questions or comments about the Avatar® III, contact your Account Manager  directly. If you do not have an Account Manager or do not know if you have one, contact us  directly at our Customer Support line.  Customer Support Contact:  Telephone: 650‐251‐4958  Email: support@robotex.com  Website: www.robotex.com  Customer Support Hours:    Monday through Friday 9am to 7pm – Pacific Standard Time    Saturday 10am to 6pm – Pacific Standard Time    For after‐hours calls, please contact your Account Manager directly.        For downloadable user  manuals for the AVATAR III  and accessories, please visit:    http://robotex.com/user‐manuals  Password: RobotexCustomer         26  Avatar® III User Manual                                                          Rev D 12/2015      ...
  • Page 27: Warranty And Maintenance

    Warranty and Maintenance    The Avatar® III is covered by a three‐year warranty on parts failures. This does not cover  damage caused by user error or mishandling of product.  Contact your Account Manager  for warranty claims and questions.    Warranty Contact Attention – Warranty Support  RoboteX, Inc.   433 Lakeside Dr.  Sunnyvale, CA 94085  650‐251‐4958  support@robotex.com     Maintenance Options   Complete maintenance service is available.  Avatar® III‐certified repair technicians  perform module replacement and rebuilding at our maintenance facility in Silicon  Valley.  Labor is charged at an hourly rate depending on the required service.      Contact the RoboteX Service Department for more information:    Attention – Service Department  RoboteX, Inc.   433 Lakeside Dr.  Sunnyvale, CA 94085  650‐251‐4958  service@robotex.com            27  Avatar® III User Manual                                                          Rev D 12/2015      ...
  • Page 28: Protect Your Robot

    Protect Your Robot  There are a few important practices you should follow when using        the Avatar® III on a regular basis. Failure to do so may damage your robot.  Before switching/removing payloads on the robot, make sure the robot battery is  unplugged.    Please make sure the battery ejector bar is  fully folded (over the top of the battery)  before locking the battery door of robot.            Please use RoboteX‐certified batteries ONLY. Other types of batteries might permanently  damage the robot, even though they have a similar form factor that will fit inside the unit.  There is ONLY ONE removable antenna on the controller. Please don’t put it on the wrong  port (the correct antenna port is UNCOVERED).  Please make sure that the front flippers are flat when operating the arm. The easiest way  to flatten the flippers is to hold down the flipper control knob until the flippers stop  moving and are positioned flat against the ground.  While transferring recorded videos to USB, please don’t unplug the USB stick before the  system finishes downloading files to it.  Please make sure that the 5 metal pads on the battery (shown below) are exposed and  clear of dust or dirt. If there is a label covering these pads, please remove it before use.  Failure to do so might cause the robot not to power on reliably.      28  Avatar® III User Manual                                                          Rev D 12/2015      ...
