User Manual
BR200
PROGRAMMING
INSTRUCTIONS
MIDLAND ON-SITE BUSINESS RADIO PROGRAMMING INSTRUCTIONS
INTRODUCTION
The BR200 comes with 16 of the most common frequencies and privacy codes pre-programmed in the radio.
You can use the FREE programming software to select from a list of 56 other Business Band frequencies and
142 Privacy codes as well as other settings to customize your radio.
The available frequencies and codes are listed in your owner's manual.
You will need the BA1 Programming cable and programming software that are available on the Midland website at
www.midlandusa.com.
TIP: If at any time during programming you are unsure of what value to use for a setting, use the
default value. You can return the radio to all of its default values by using the "Default Setting"
command under Settings.
QUICK LINKS
Minimum Operating System Requirements
Installing the Programming Software
Program a BR200 Radio
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Read a Programmed BR200 Radio
Program Using a Saved File
Reset a BR200 Radio to its Factory Default Settings
Troubleshooting, Tips and Tricks
MINIMUM OPERATING SYSTEM REQUIREMENTS
1. Operating System: Windows XP or higher.
Note: The software will not run on Apple iOS.
2. Processor Speed: Pentium 4 or higher.
3. Available RAM: 256MB or higher.
4. Internal Storage Memory: 2MB.
5. USB Type A 2.0 port or higher.
||
1
®
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1
1
3
6
7
7
8
midlandusa.com
Advertisement
Related Manuals for Midland BIZTALK BR200
Summary of Contents for Midland BIZTALK BR200
- Page 1 142 Privacy codes as well as other settings to customize your radio. The available frequencies and codes are listed in your owner’s manual. You will need the BA1 Programming cable and programming software that are available on the Midland website at www.midlandusa.com.
-
Page 2: Installing The Programming Software
INSTALLING THE PROGRAMMING SOFTWARE NOTE: The following is using Microsoft Edge and the Winzip application to unzip the programming software. Illustrations may vary with other browsers or applications but the steps will be very similar. The most important step is to save the programming software to your desktop, or create a shortcut on your desktop so that you can return to it easily. - Page 3 Midland website." 3. The program is an “auto – run” installation and will automatically open/run upon double clicking the icon or the software program for installation. PROGRAM A BR200 RADIO 1.
- Page 4 TIP: The window will automatically populate with the factory default values. You may either leave them and change only the values you need to, or click the “New” icon to clear all the frequency and privacy code settings and program only the channels you need to. The Advanced settings will remain at their default values.
- Page 5 7. Click on the Gear icon to program the “Advanced” settings of the radio Advance Settings Icon Drop down Menu a. Use the drop-down menu for each setting and select the value that will give you the desired performance. If you are not sure what value to use, use the default value. Default Value Advance Settings Settings Range...
- Page 6 a. Click on the green “W” icon. b. The programming data will automatically be sent to the radio. c. Click “OK” to confirm and complete the programming. 10. Turn the radio off and disconnect the programming cable. 11. Turn the radio on, and test it with other radios to make sure it is working correctly. 12.
- Page 7 6. The programming data will be displayed on their respective program window. 7. Turn off the radio and disconnect the programming cable. 8. With the programming software still open, connect another BR200 radio follow step 9 above to write the same data to additional radios.
-
Page 8: Troubleshooting, Tips And Tricks
TROUBLESHOOTING, TIPS AND TRICKS Most problems can be resolved by following these simple steps. However, if you need additional help, call our Customer Service team at 816-241-8500. Symptom Solution The programming data will not transfer to - Make sure the radio has a fully charged battery and is turned on. (Do not program a radio while in the charger.) the radio from the computer. - Page 9 We’d love to hear from you! Let us know what you think of your new Midland product at or by visiting us at midlandusa.com Note: Features & Specifications are subject to change without notice. MIDLAND is not responsible for unintentional errors or omissions on its packaging.
