Page 1: Instruction Manual
AOYUE ® 8800 Portable Compact Desoldering Tool Instruction Manual Thank you for purchasing the Aoyue 8800 portable compact desoldering tool. Please read the manual before using the unit. Keep manual in accessible place for future reference. - Page 3 This manual is designed to familiarize and in- struct the technician with the proper operation and maintenance of the equipment. The “Care and Safety Precautions” section explains the hazards of using any type of soldering or rework- ing device. Please read carefully and observe the guidelines in order to maximize usage and minimize the risk of injury or accidents .
-
Page 4: Table Of Contents
TABLE OF CONTENTS Product Description …………………… 4 Specifications …………………………... 5 Package Inclusion ………………… …. 6 Safety Precautions ……………………. 7-8 Control Panel Guide …………………... 9-12 Holder Assembly Guide …………………. 12 Operating Guidelines ……………..….. 13-15 Care and Maintenance …………...…. 16-18 Basic Troubleshooting Guide ……... -
Page 5: Product Description
PRODUCT DESCRIPTION The Aoyue 8800 is a compact desoldering gun design which houses a powerful vacuum pump, PTC ceramic heater and variable temperature control circuit in a portable handheld unit. Portable desoldering tool for onsite servicing and ● repair. High suction power in a compact system. -
Page 6: Specifications
SPECIFICATION DESOLDERING GUN* Power Input : available in 110V / 220V Dimensions: 225(w) x 170h) x 73(d) mm Weight: 0.7 Kg Power Consumption: 100 W Temperature Range: 200°C - 460°C / 392°F - 860°F Heating Element: PTC Ceramic Heater Output Voltage: 110V / 220V Motor Type: AC motor... -
Page 7: Package Inclusion
PACKAGE INCLUSION 1 unit 8800 Desoldering Gun with DT-1.8(1.8mm ) 1 pc. 2668 Desoldering Gun Stand Desoldering Gun Stand Parts 1 pack (Sponge Tray, Sponge, Securing Screw) 1 pc. DT-1.5 Desoldering Tip (1.5mm) 1 pc. DT-1.0 Desoldering Tip (1.0 mm)* 1 pc. -
Page 8: Safety Precautions
CONTROL PANEL GUIDE SAFETY PRECAUTIONS SAFETY PRECAUTIONS CAUTION: Improper usage can cause serious injury to per- sonnel and/or damage to equipment. For your own safety, please observe the ff. precautions. Check each component after opening the package to ● make sure everything is in good condition. If there are any suspected damage, do not use the item and report the issue to your vendor. -
Page 9: Control Panel Guide
CONTROL PANEL GUIDE - Do not touch heated parts, which can cause se- vere burns. - Do not touch metallic parts near the tip. Disconnect the plug from the power source if the ● unit will not be used for a long period. - Turn off power during breaks, if possible. - Page 10 CONTROL PANEL GUIDE LEGEND: 1 — Desoldering Gun Temperature Adjustment 2 — Temperature Regulation LED indicator 3 — Desoldering Gun Trigger. 4 — Internal Vacuum Pump. 5 — Waste Solder Cylinder. 6 — Desoldering Tip. 7 — Desoldering Tip Locking Nut.
-
Page 11: Holder Assembly Guide
CONTROL PANEL GUIDE LEGEND cont.: 8 — Main Power Switch. 9 — AC Power Cord Connector HOLDER ASSEMBL Y GUIDE Note: Ample force must be used for initial attachment of the tray. Tray can be attached and detached easily after initial use. -
Page 12: Operating Guidelines
OPERATING GUIDELINES IMPORTANT : Please refer to the CONTROL GUIDE page for controls and parts directory. A. INITIAL PROCEDURES 1. Plug the device to the main power source using the power cord provided in the package. 2. With all power switches in the OFF position and all terminal connections properly secured, The system can be switched ON by activating the main power switch located at the back of the power block. - Page 13 OPERATING GUIDELINES C. DESOLDERING Adjust the desoldering gun temperature using the DESOLDERING GUN TEMPERATURE AD- JUSTMENT Knob (1). Allow the desoldering gun's tip and its barrel to heat up. The temperature regulation LED indi- cator (2) will light up indicating that the sys- tems is heating up.
- Page 14 OPERATING GUIDELINES 4. If solder gets stuck at the end of the barrel, clean the barrel and wait a few more minutes for the barrel to heat up. 5. Upon pressing the desoldering gun trigger (3), hold the trigger for 1 to 2 seconds longer, as lar- ger lumps of solder may need a longer suction time to clear the barrel and go into the waste solder cylinder(5).
-
Page 15: Care And Maintenance
CARE AND MAINTENANCE A. DE-CLOGGING The solder pathway can be cleaned using the provided Nozzle cleaning pin, use the cleaning pin when pathway seems clogged. Turn on the desoldering gun and wait for the nozzle to heat up. The cleaning pin passes completely through the hole. - Page 16 CARE AND MAINTENANCE Caution: If the cleaning drill is forced into the nozzle, the drill could break. Please use the proper sized cleaning drill for the nozzle diameter. If the cleaning pin cannot pass through the hole, replace the Tip. B.
- Page 17 CARE AND MAINTENANCE Insert filter barrel assembly by pulling on the spring loaded stopper then sliding the filter bar- rel assembly into position.
-
Page 18: Basic Troubleshooting Guide
The tip might have some oxidation . Or the set temperature might be too low. SOLUTION: Clean the desoldering tip with our tip cleaner TY-98 or Aoyue 128 tip cleaning system. Set temperature a little higher until solder melts. - Page 19 This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 20 AOYUE INTERNATIONAL LIMITED Jishui Industrial Zone, Nantou, Zhongshan City, Guangdong Province, P.R.China http://www.aoyue3d.com...
