GPIO
GPIO5 43
GPIO6 44
NETLIGHT 50
STATUS 49
Serial port
DTR 9
RI 10
DCD 11
CTS 12
RTS 13
TXD 14
RXD 15
USB interface
VBUS 25
USB_DP 26
USB_DM 27
ADC
ADC1 23
ADC2 24
PWM
PWM1 42
PWM2 41
I2C
SDA 38
SCL 39
SIM interface
SIM_VDD 29
SIM_DATA 30
SIM_CLK 31
SIM_RST 32
SIM_PRESENCE 33
Antenna
GSM_RF_IN 66
ANT_BT 53
GPS_RF_IN 35
RF synchronization
RF_SYNC 63
SIM808_Hardware Design_V1.00
I/O Programmable general purpose input and
output.
I/O
O Network status
O Power on status
I Data terminal ready
O Ring indicator
O Data carrier detect
O Clear to send
I Request to send
O Transmit data
I Receive data
I
Debug and firmware upgrading
I/O
I/O
I 10 bit general analog to digital converter
O Pulse-width modulation, multiplex with GPIO4.
O Pulse-width modulation, multiplex with GPIO3.
I/O I2C serial bus data
O I2C serial bus clock
Voltage supply for SIM card. Support 1.8V or
O
3V for SIM card
I/O SIM data input/output
O SIM clock
O SIM reset
I SIM card detection
I/O Connect GSM antenna
I/O Connect Bluetooth antenna
I Connect GPS antenna
O RF burst synchronous signal
