Summary of Contents for dirna Bergstrom Bycool FLAT

  • Page 1: Troubleshooting

    Air conditioning for vehicles FLAT Diagnosis de averías Spanish Troubleshooting English Diagnostic de pannes French Diagnose bei ausfällen German Diagnosi dei guasti Italian Wykrywanie usterek Polish Diagnóza poruch Czech Storingsdiagnose Dutch 220AA70030...
  • Page 2 FLAT Air conditioning for vehicles Síntoma Causa El equipo no funciona, no sale aire por El soplador centrífugo no funciona. las lumbreras. El equipo no enfría ó enfría poco. No llega agua, ó muy poca, al filtro húmedo. • Desagüe defectuoso. El agua no retorna al depósito blanco.
  • Page 3 FLAT Air conditioning for vehicles Solución • Fusible fundido. Antes de reponer el fusible, investigar las causas (cortocircuito, fallo de algún componente eléctrico, etc.) • Revisar las conexiones de entrada de corriente y conexión a masa. • El motor del soplador centrífugo está averiado. Sustituirlo. •...
  • Page 4 FLAT Air conditioning for vehicles Problem Cause The device does not work, no air comes The centrifugal blower does not work. out of the ports. The device does not cool or cools very No water, or very little water, reaches the wet little.
  • Page 5 FLAT Air conditioning for vehicles Solution • Fuse blown. Before replacing the fuse, investigate the causes (short circuit, failure of an elec- trical component, etc.) • Check the current input connections and earthing. • The centrifugal blower’s motor is faulty. Replace it. •...
  • Page 6 FLAT Air conditioning for vehicles Problème Cause L’équipement ne fonctionne pas. L’air Le souffleur centrifuge ne fonctionne pas. ne sort pas par les ouvertures. L’équipement refroidit L’eau n’arrive pas (ou pas assez) au filtre refroidit très peu. humide. • Écoulement défaillant. L’eau ne retourne pas au réservoir blanc.
  • Page 7 FLAT Air conditioning for vehicles Solution • Fusible grillé. Avant de changer le fusible, il faut connaître les causes (court-circuit, défaut d’un composant électrique, etc.). • Réviser les connexions d’entrée de courant et de connexion à la masse. • Le moteur du souffleur centrifuge est en panne. Le remplacer. •...
  • Page 8 FLAT Air conditioning for vehicles Problem Ursache Die Anlage funktioniert nicht, es kommt keine Das Zentrifugalgebläse funktioniert nicht. Luft durch die Durchlassgitter. Es kommt kein oder nur wenig Wasser zum Nass- Die Anlage kühlt nicht oder nur wenig. filter. • Entwässerung defekt. Das Wasser läuft nicht in den weißen Behälter zurück.
  • Page 9 FLAT Air conditioning for vehicles Lösung • Sicherung geschmolzen. Vor dem Ersetzen der Sicherung die Ursache (Kurzschluss, Ausfall eines elektris- chen Bauteils usw.) feststellen. • Stromzufuhr- und Masseanschlüsse überprüfen. • Der Motor des Zentrifugalgebläses ist defekt. Ersetzen. • Überprüfen, ob sich Wasser im Behälter befindet. Ist der Füllstand sehr niedrig, müsste die rote Led der Füllstandsanzeige auf dem Bedienfeld angehen.
  • Page 10 FLAT Air conditioning for vehicles Síntoma Causa L’impianto non funziona, non esce aria Il ventilatore centrifugo non funziona. dalle bocchette. L’impianto non raffredda o raffredda L’acqua non arriva al filtro umido o è molto poco. scarsa. • Scarico difettoso. L’acqua non ritorna al serbatoio bianco.
  • Page 11 FLAT Air conditioning for vehicles Soluzione • Fusibile fuso. Prima di sostituire il fusibile, indagarne le cause (cortocircuito, guasto a qualche componente elettrico, ecc.). • Controllare le connessioni di entrata della corrente e a massa. • Il motore del ventilatore centrifugo è guasto. Sostituirlo. •...
  • Page 12 FLAT Air conditioning for vehicles Problem Przyczyna Urządzenie nie działa, z otworów nie Nie działa dmuchawa odśrodkowa. wydobywa się powietrze. Urządzenie nie chłodzi lub chłodzi bardzo Nie dochodzi woda, lub dostarczana jest jej słabo. mała ilość do mokrego filtra. • Zepsuty system odpływowy. Woda nie wraca do białego zbiornika.
  • Page 13 FLAT Air conditioning for vehicles Rozwiązanie • Spalony bezpiecznik. Przed wymianą spalonego bezpiecznika należy zbadać przyczynę jego awarii (zwarcie, awaria któregoś z elementów elektr., itp.) • Sprawdzić złącza wejściowe prądu oraz uziemienie. • Awaria silnika dmuchawy odśrodkowej. Wymienić silnik. • Sprawdzić, czy w zbiorniku znajduje się woda. Jeśli poziom wody jest bardzo niski na panelu sterowa- nia, przy wskaźniku poziomu wody, powinna zapalić...
  • Page 14 FLAT Air conditioning for vehicles Problém Příčina Zařízení nefunguje, průduchů Odstředivé dmychadlo nefunguje. nevychází vzduch. K filtru se nedostává voda, anebo jen velmi Zařízení nechladí, nebo chladí málo. málo. • Defektní odtoková hadice. Voda se nevrací do bílé nádrže. Voda přetéká a vytéká z průduchů v rozvodovém panelu.
  • Page 15 FLAT Air conditioning for vehicles Řešení • Spálená pojistka. Před výměnou pojistky, zjistěte příčinu spálení (zkrat, selhání některého z elektrických komponentů apod.). • Prověřte připojení ke zdroji elektrické energie a uzemnění. • Motor dmychadla je porouchaný. Vyměňte ho. • Prověřte, je-li v nádrži voda. V případě, že je hladina vody příliš nízká by se měla rozsvítit červená...
  • Page 16 FLAT Air conditioning for vehicles Probleem Oorzaak Het apparaat werkt niet, er komt geen lucht uit De centrifugaalblazer werkt niet. de roosters. Het apparaat koelt weinig of niet. Er komt weinig of geen water in het waterfilter. • Waterafvoer defect. Het water keert niet terug naar het witte reservoir.
  • Page 17 FLAT Air conditioning for vehicles Oplossing • Zekering doorgebrand. Voordat u de zekering vervangt de oorzaak onderzoeken (kortsluiting, storing van een elektrische component, enz.) • Fase en massa-aansluitingen controleren. • De motor van de centrifugaalpomp is kapot. Vervangen. • Controleren of er water in het reservoir zit. Indien het peil erg laag is, moet de rode led van de peilindicator in het besturingspaneel gaan branden.
  • Page 18 FLAT Air conditioning for vehicles...
