SLIM COOL
Manual del Usuario
User's handbook
Manuel de l'utilisateur
Benutzerhandbuch
Manuale Per l'utente
Instrukcja montażu
Návod k montáži
Handleiding
Air conditioning for vehicles
ES
EN
FR
GE
IT
PL
CZ
NL
220AA65012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bycool Slim Cool and is the answer not in the manual?

Questions and answers

Summary of Contents for dirna Bergstrom Bycool Slim Cool

  • Page 1 Air conditioning for vehicles SLIM COOL Manual del Usuario User’s handbook Manuel de l’utilisateur Benutzerhandbuch Manuale Per l’utente Instrukcja montażu Návod k montáži Handleiding 220AA65012...
  • Page 2 Gracias por su adquisición y por confiar en nuestra gama de productos. Slim Cool es un equipo de Aire Acondicionado diseñado y fabricado por Dirna Bergstrom para ser utilizado a motor del vehículo parado durante los períodos de descanso a la sombra y/o por la noche.
  • Page 3: Panel De Control

    SLIM COOL Air conditioning for vehicles Panel de control ºC ºF ON/OFF TEMP 1.- On/off: encendido y apagado del equipo y selección de modos de funcionamiento. 2.- Indica el funcionamiento de los compresores. 3.- Display: Pantalla donde se indica la función seleccionada y el estado del equipo. 4.- Selectores de temperatura: Selección de la temperatura deseada y la velocidad del soplador (esta sólo en modo manual), programación del mando y grados Fahrenheit.
  • Page 4: Encendido Del Equipo

    SLIM COOL Air conditioning for vehicles Dar de baja el mando a distancia: Para dar de baja el mando a distancia se debe mantener pulsada la tecla del panel de control hasta que aparezca en el display ,parpadeando, cuando quede fijo pulsar la tecla del panel antes de 30 seg.
  • Page 5 SLIM COOL Air conditioning for vehicles Función F1 - Función termómetro digital Slim Cool Seleccionando esta función indica en su display la temperatura interior de la cabina. Función F2 - Función Programadora de tiempo programa al equipo para su desconexión automática en un período de entre 1 y 9 horas. F2 , Para programar mantener pulsada la tecla On/off hasta visualizar en el display...
  • Page 6: Esquema Eléctrico

    SLIM COOL Air conditioning for vehicles Esquema eléctrico AVISO IMPORTANTE! ¡ Precaución de no invertir las polaridades al conectar el equipo. Si esto sucediera, la placa de mandos no se enciende y el equipo no funciona. Sensor aire de retorno Soplador NTC 15KΩ...
  • Page 7 SLIM COOL Air conditioning for vehicles...
  • Page 8 Thank you for acquiring and trusting our products range. Slim Cool is an Air Conditioning equipment designed and made by Dirna Bergstrom to be used with vehicle´s engine off, during resting periods under the shade and/or at night. The only maintenance that is required is a periodical cleaning of the condenser, at least once a year (1).
  • Page 9: Control Panel

    SLIM COOL Air conditioning for vehicles Control panel ºC ºF ON/OFF TEMP 1.- On/off switch on /off the unit and functioning selection mode. 2.- Indicate the compressors functioning. 3.- Display: Screen where it shows the slected functioning and condition of the unit. 4.- Temperature selectors : To select the surrounding temperature and the blower speed (this only in manual mode) , remote control programmation and Fahrenheit degrees.
  • Page 10 SLIM COOL Air conditioning for vehicles How to deactivate remote control: In order to deactivate remote control, push key of control panel until , flashes on dis- play. Once it stops flashing, push key on panel. You will have to do it within 30 seconds or else you will have to repeat the whole operation.
  • Page 11 SLIM COOL Air conditioning for vehicles Function F1 - Digital thermometer function By selecting this function, Slim Cool displays temperature inside cabin. Function F2 - Time programming function programs the equipment so that it is automatically disconnected during a 1-9 hour period. In order to program, push the On/off key until is shown on display, select functioning...
  • Page 12: Electrical Diagram

    SLIM COOL Air conditioning for vehicles Electrical Diagram IMPORTANT NOTE! Take care not to invert polarities when connecting the unit to the power supply. If this were to happen, the plate would not come on and the unit would not work. Return air probe Centrifugal...
  • Page 13 SLIM COOL Air conditioning for vehicles...
  • Page 14 Merci de votre acquisition et de confier en notre gamme de produits. Slim Cool est un appareil de Climatisation conçu et fabriqué par Dirna Bergstrom pour être utilisé à moteur arrêté du véhicule pendant les périodes d’arrêt à l’ombre et/ou pendant la nuit.
  • Page 15: Panneau De Contrôle

    SLIM COOL Air conditioning for vehicles Panneau de contrôle ºC ºF ON/OFF TEMP 1.- On/off: allumer/étaindre l´unité et sélection des modes du fonctionnement. 2.- Indique le fonctionnement des compresseurs. 3.- Display: Écran ou se montre la fonction désirée et l´état de l´unité. 4.- Sélecteurs du tèmperature: selection de la température ambiant et la vittesse du souffleur (celui ci uniquement sur le mode manuel) programmation de la télécommande et dégrees Fahrenheit.
  • Page 16: Allumage De L'appareil

    SLIM COOL Air conditioning for vehicles Eliminer la télécommande: Pour éliminer la télécommande, il faut maintenir appuyée la touche du panneau de contrôle jusqu’à ce que , apparaisse à l’écran en clignotant ; lorsqu’il devient fixe, pousser la touche du panneau avant 30 sec. ou il faudra répéter l’opération. Allumage de l’Appareil Pour allumer Slim Cool pousser la touche On/off .
  • Page 17 SLIM COOL Air conditioning for vehicles Fonction F1 - Fonction thermomètre numérique En sélectionnant cette Fonction Slim Cool indique à l’écran la température intérieure de la cabine. Fonction F2 - Fonction Programmatrice de temps programme l’appareil pour sa déconnexion automatique sur une période entre 1 et 9 heures.
  • Page 18: Schéma Électrique

    SLIM COOL Air conditioning for vehicles Schéma électrique AVIS IMPORTANT ! Attention de ne pas inverser les polarités dans la connexion de l’alimentation à l’équipement. Si cela se produisait, la plaque ne s’allumerait pas et l’équipement ne fonctionnerait pas. Capteur air de retour Souffleur NTC 15KΩ...
  • Page 19 SLIM COOL Air conditioning for vehicles...
  • Page 20 Air conditioning for vehicles Wir danken Ihnen, dass Sie sich für unsere Produktreihe entschieden haben. Slim Cool ist eine von Dirna Bergstrom konstruierte und hergestellte Klimaanlage zum Einsatz in außer Betrieb befindlichen und im Schatten und/oder nachts abgestellten Motorfahrzeugen. Die Instandhaltung erfordert lediglich die gelegentliche Reinigung (mindestens 1 Mal jährlich) des Kondensators.
  • Page 21: Funktionen Der Fernbedienung

    SLIM COOL Air conditioning for vehicles Steuertafel ºC ºF ON/OFF TEMP 1.- On/off: Ein- und Ausschalten des Gerätes und Auswahl der Betriebsart (automatisch-manuell) 2.- Zeigt an, ob die Kompressoren in Betrieb sind 3.- Display: Zeigt die ausgewählte Funktion und den Zustand des Gerätes an. 4.- Temperaturauswahl: Auswahl der Anzeige der Raumtemperatur und der Lüftergeschwin- digkeit (nur bei manuellem Betrieb), Programmierung der Fernbedienung und Auswahl der Temperaturanzeige in Celsius oder Fahrenheit.
  • Page 22 SLIM COOL Air conditioning for vehicles Außerbetriebnahme der Fernbedienung: Zur Außerbetriebnahme der Fernbedienung Taste auf der Steuertafel gedrückt halten, bis auf dem Display blinkend , blinkend angezeigt wird. Sobald die Anzeige kontinuierlich leuchtet On/Off-Taste der Steuerung vor Ablauf von 30 Sek. drücken; sonst muss der gesamte Vorgang wiederholt werden. Einschaltung der Anlage Slim Cool wird durch Betätigen der On/Off-Taste eingeschaltet.
  • Page 23 SLIM COOL Air conditioning for vehicles Funktion F1 - Funktion Digitalthermometer Wird diese Funktion gewählt, dann zeigt Slim Cool auf dem Display die Innentemperatur des Fahrerhauses an. Funktion F2 - Funkion Zeitprogrammierer programmiert die Anlage zur automatischen Abschaltung für einen Zeitraum von 1 bis 9 Stunden.
  • Page 24 SLIM COOL Air conditioning for vehicles Elektroschaltplan WICHTIGER WARNHINWEIS! Darauf achten, dass die Polaritäten beim Anschluss der Stromversorgung an das Gerät nicht vertauscht werden. Ist dies der Fall, schaltet sich die Elektroniktafel nicht ein und das Gerät funktioniert nicht. Abluftsensor NTC 15KΩ...
  • Page 25 SLIM COOL Air conditioning for vehicles...
  • Page 26 è di nuovo in posizione orizzontale. (1) Per realizzare questa operazione bisogna smontare il coperchio superiore di plastica del dispositivo (9 viti da lamiera) e soffiare con aria a pressione. È consigliabile che questa operazione venga effettuata da un Servizio Autorizzato da Dirna Bergstrom...
  • Page 27: Pannello Di Controllo

    SLIM COOL Air conditioning for vehicles Pannello di controllo ºC ºF ON/OFF TEMP 1.- On/Off: accensione e spegnimento dell’impianto e selezione delle modalità di funzionamento. 2.- Indica il funzionamento dei compressori. 3.- Display: Schermo sul quale sono indicati la funzione selezionata e lo stato dell’impianto. 4.- Selettori della temperatura: selezione della temperatura ambiente e della velocità...
  • Page 28: Accensione Del Dispositivo

    SLIM COOL Air conditioning for vehicles Disattivare il telecomando: Per disattivare il telecomando, bisogna mantenere premuto il tasto del pannello di controllo fino a quando appare nel display lampeggiante; quando rimane fisso premere il tasto del pannello prima di 30 sec., altrimenti bisognerà ripetere tutta l’operazione. Accensione del Dispositivo Per accendere Slim Cool premere il tasto On/off .
  • Page 29 SLIM COOL Air conditioning for vehicles Funzione F1 - Funzione termometro digitale Selezionando questa funzione Slim Cool indica nel suo display la temperatura interna della cabina. Funzione F2 - Funzione Programmazione tempo programma il dispositivo per lo scollegamento automatico in una fascia tra 1 e 9 ore. Per programmare mantenere premuto il tasto On/off fino a quando si vede nel display e confermare premendo On/...
  • Page 30: Schema Elettrico

    SLIM COOL Air conditioning for vehicles Schema elettrico AVVERTENZA IMPORTANTE! Fare attenzione a non invertire le polarità effettuando la connessione dell’alimentazione all’impianto, altrimenti il quadro comandi non si accende e l’impianto non funziona. Sensore aria ritorno Ventilatore NTC 15KΩ a 25º centrifugo Consumo 2,6 Amp.
  • Page 31 SLIM COOL Air conditioning for vehicles...
  • Page 32 Air conditioning for vehicles Dziękujemy za dokonanie zakupu i zaufanie do naszej gamy produktów. Slim Cool jest urządzeniem klimatyzacyjnym zaprojektowanym i wykonanym przez Dirna Bergstrom, do wykorzystania w pojazdach przy wyłączonym silniku podczas odpoczynku w cieniu i/ lub w nocy. Jedyna wymagana konserwacja obejmuje okresowe czyszczenie sprężarki przynajmniej 1 raz w roku (1).
  • Page 33: Panel Kontrolny

    SLIM COOL Air conditioning for vehicles Panel kontrolny ºC ºF ON/OFF TEMP 1.- On/Off: włącznik i wyłącznik urządzenia y wybór trybu funkcjonowania 2.- Wskazuje funkcjonowanie kompresorów. 3.- Wyświetlacz: ekran na którym wyświetlona zostaje wybrana funkcja i tryb urządzenia. 4.- Przyciski ustawiania temperatury – Przeznaczone do ustawienia temperatury zadanej i prędkości nadmuchu (w trybie ręcznym), programowania pilota i zmiany jednostek na stopnie Fahrenheita.
  • Page 34: Włączanie Urządzenia

    SLIM COOL Air conditioning for vehicles Wyłączenie pilota zdalnego sterowania: Aby wyłączyć pilot zdalnego sterowania, należy naciskać przycisk dna panelu kontrolnymi, aż na wyświetlaczu pojawi się migoczący , kiedy przestanie migać, nacisnąć przycisk na panelu przed upływem 30 sekund, bądź w innym przypadku trzeba będzie powtórzyć całą operację.
  • Page 35 SLIM COOL Air conditioning for vehicles Funkcja F1 - Funkcja cyfrowego termometru Po wybraniu tej funkcji Slim Cool pokazuje na wyświetlaczu temperaturę wewnątrz kabiny. Funkcja F2 - Funkcja programatora czasu programuje urządzenie w celu jego automatycznego wyłączenia się w okresie od 1 do 9 godzin.
  • Page 36: Schemat Elektryczny

    SLIM COOL Air conditioning for vehicles Schemat elektryczny WAŻNA UWAGA! Należy uważać, aby nie zamienić biegunów przy podłączaniu zasilania do urządzenia. Grozi to awarią elektroniki urządzenia uniemożliwiającą jego uruchomienie i działanie. Czujnik powietrza powrotnego Dmuchawa NTC 15KΩ a 25º odśrodkowa Zużycie energii 30 mAmp.
  • Page 37 SLIM COOL Air conditioning for vehicles...
  • Page 38 Děkujeme Vám za koupi a za důvěru v naši paletu výrobků. Slim Cool je klimatizační zařízení, které konstrukčně vypracovala a vyrobila firma Dirna Bergstrom k použití ve vozidlech s vypnutým motorem během zastávek, ve stínu a/nebo v noci. Jediná nutná...
  • Page 39: Ovládací Panel

    SLIM COOL Air conditioning for vehicles Ovládací panel ºC ºF ON/OFF TEMP 1.- ON/OFF: Zapnout – vypnout zařízení a výběr režimu. 2.- Zobrazuje fungování kompresorů. 3.- Displej: Displej, na kterém se zobrazí vybraná funkce a stav zařízení. 4.- Voliče teploty: Volba požadované teploty a rychlosti ventilátoru (pouze v ručním režimu), programování...
  • Page 40: Zapnutí Přístroje

    SLIM COOL Air conditioning for vehicles Uvedení mimo provoz dálkového ovladače: Compact za zapíná stisknutím tlačítka On/Off . Zařízení se spouští vždy ve funkci (automatický způsob provozu). Ke změně funkce držet stisknuté tlačítko On/Off , přičemž se na displeji postupně ukáží jednotlivé funkce; pustit tlačítko, když se objeví žádaná funkce. Při prvním uvedení...
  • Page 41 SLIM COOL Air conditioning for vehicles Funkce F1 - Funkce digitální teploměr Při zvolení této funkce Slim Cool ukáže na displeji vnitřní teplotu kabiny řidiče. Funkce F2 - Funkce programovací časovací zařízení programuje přístroj k automatickému vypnutí v rozpětí 1 až 9 hodin. K naprogramování doby držet stisknuté...
  • Page 42: Důležité Upozornění

    SLIM COOL Air conditioning for vehicles Elektrické schéma DŮLEŽITÉ UPOZORNĚNÍ! Dejte pozor, abyste při zapojování zařízení neobrátili polaritu. Pokud by se tak stalo, ovládací panel se nerozsvítí a zařízení nebude fungovat. Senzor pro zpětný přívod vzduchu Odstředivé NTC 15KΩ a 25º dmychadlo 30 mAmp spotřeba.
  • Page 43 SLIM COOL Air conditioning for vehicles...
  • Page 44 (1) Om deze handeling uit te voeren, is het noodzakelijk om de bovenste plastic kap van de appa- ratuur te demonteren (9 zelftappende schroeven) en vervolgens aan te blazen met druklucht. Het wordt aanbevolen om deze handeling door een Dienst die door Dirna Bergstrom is erkend, uit te laten voeren.
  • Page 45: Functies Van De Afstandsbediening

    SLIM COOL Air conditioning for vehicles Besturingspaneel ºC ºF ON/OFF TEMP 1.- On/off: in- en uitschakelen van het apparaat en keuze van de stand. 2.- Geeft aan dat de compressor werkt. 3.- Display: Scherm waar de gekozen functie getoond wordt, evenals de status van het apparaat. 4.- Temperatuurkeuzeschakelaars: Instellen van de gewenste temperatuur en de blaassnelheid (alleen in handmatig bedrijf), programmeren van de afstandsbediening en graden Fahrenheit.
  • Page 46 SLIM COOL Air conditioning for vehicles Het uitschakelen van de afstandsbediening: Om de afstandsbediening uit te schakelen, dient de toets van het bedieningspaneel ingedrukt te worden gehouden totdat in de display , begint te knipperen, en wanneer deze niet meer knippert, dient binnen 30 sec. op de toets van de bediening te worden gedrukt, anderzijds dient de gehele handeling te worden herhaald.
  • Page 47 SLIM COOL Air conditioning for vehicles Functie F1 - Werking van de digitale thermometer Bij het kiezen van deze functie, geeft de Slim Cool de binnentemperatuur aan van de cabine, in de display. Functie F2 - Werking van de Tijdsprogrammeur programmeert de apparatuur voor een automatische uitschakeling binnen een periode van 1 tot 9 uur.
  • Page 48: Elektrisch Schema

    SLIM COOL Air conditioning for vehicles Elektrisch schema ¡BELANGRIJK BERICHT! Let op dat bij het aansluiten van de voeding op het apparaat de polen niet verwisseld worden. Indien dit het geval is zal het paneel niet oplichten en zal het apparaat niet werken. Sensor aire de retorno Soplador...
  • Page 49 SLIM COOL Air conditioning for vehicles...
  • Page 50 SLIM COOL Air conditioning for vehicles...
  • Page 52 Bergstrom, s.l. Esta información ha de ser utilizada única y exclusivamente para el fin para el que fue creada, no siendo dirna Bergstrom, s.l. responsable de los posibles daños que se pudiera causar al cliente y/o a terceras partes por un incorrecto y/o inadecuado uso de la misma.
