Danfoss PVE Series Installation Manual page 2

AMP-version on/off
AMP-version
proportional
AMP-stik til PVE serie 4
AMP connector for PVE series 4
AMP-Stecker für PVE Serie 4
Kit AMP pour PVE serie 4
Kabel med stik
Cable with connector
Kabel mit Stecker
Câble avec connecteur
2
Signal voltage (A or B)
Function
A (pin 1)
Neutral 0
Q: P -> A U
DC
Q: P -> B 0
Function Signal voltage (US)
Neutral U (pin 1) = 0.5 • U
S
U (pin 1) = (0.5 -> 0.25) • U
S
Q: P -> A
Q: P -> B U (pin 1) = (0.5 -> 0.75) • U
S
PVE function (grey)
Pos. Description
1 Wire sealing (blue)
2 Blind plug (transparent)
3 JPT contact (loose piece)
4 JPT housing keying B (gray)
JPT = AMP Junior Power Timer
PVE-funktion (gråt stik)
PVE-function (grey connector)
PVE-Funktion (Grauer Stecker)
PVE-Fonction (Support gris)
Code: 157B4994
(min. 5 pcs.)
520L0403 • Rev CB • Mar 2014
B (pin 2)
0
0
U
DC
DC
DC
DC
Qty. AMP Code no.
4* 828904-1
1 828922-1
4* 929930-1
1 2-967059-1
Pin 4 F
Pin 3 U-
Pin 2 U+
Pin 1 Us
Pin 1
Pin 2
Pin 3
Pin 4
Danfoss
Danfoss
Code no with
Code no.
4 mm cable
157B4992 157B4994
min. 5 pcs min. 5 pcs.
Hvid, White, Weiß, Blance
Blå, Blue, Blau, Bleu
Gul, Yellow, Gelb, Jaune
Rød, Red, Rot, Rouge
© Danfoss A/S, 2014-03
