Sanus Systems TVS Assembly Instructions

Thank you for choosing the TVS. If you do not understand these directions, or have any doubts about the safety of the installation,
please contact Sanus at 800.359.5520 or www.sanus.com. Check carefully to make sure that there are no missing or defective parts. Our
customer service representatives can quickly assist you with installation questions and missing or damaged parts. Replacement parts
for products purchased through authorized dealers will be shipped directly to you. Never use defective parts. Improper installation may
cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified by Sanus Systems. Sanus Systems
can not be liable for damage or injury caused by incorrect mounting, incorrect assembly, or incorrect use. Please call Sanus Systems
before returning products to the point of purchase.
Caution:
•Not suitable for use with all TVs.
•For use only on TVs with a perfectly flat and level top
and this shelf must be level after installation.
•Not suitable for use with flat panel or rear projection
TVs.
•Do not use at a height more than 48" above floor.
Parts and Hardware: *Some parts not shown at same scale
(2) Adjustable Foot - c
Assembly Instructions for TVS
(1) Shelf - a*
(2) Plastic Safety Pegs - d
Sanus Systems 2221 Hwy 36 West Saint Paul MN 55113
800.359.5520 www.sanus.com
•Shelf foot angle not to exceed 45 degrees.
•Total weight on shelf not to exceed 15 lbs.
•Depth of items placed on this shelf not to exceed 15" and
under no circumstance should any item overhang the back of
the shelf.
(2) Bolts - e
(2) Plastic Legs - b*
(3) Hook and Loop Tape Pads - f
6.27.05
