Tennant 95 Instruction Bulletin

INSTRUCTION BULLETIN
NOTE: DO NOT DISCARD the Parts List from the Instruction Bulletin. Place the Parts
List in the appropriate place in your machine manual for future reference.
Retaining the Parts List will make it easier to reorder individual parts and will
save you the cost of ordering an entire kit.
NOTE: Numbers in parenthesis ( ) are reference numbers for parts listed in Bill of Materials.
Repair parts list for pump 373419 and Kit number 397689
SYNOPSIS / PROBLEM:
This kit contains the new hydraulic pump part # 373419, repair information bulletin, repair
parts list and parts breakdown for hydraulic pump part # 373419.
When repairing this pump, please follow the step-by-step instructions in the repair
information bulletin Tennant #373281 (Eaton #7--620).
Tennant
Ref.
Part No.
1 ISK
2 373218
3 373219
4 ISK
5 ISK
6 61891
7 373392
8 74230
o
Y
9 61882
10 61888
11 61890
12 61889
13 37454
14 37448
15 ISK
16 74240
17 74210
18 74261
19 74260
20 ISK
21 ISK
22 373220
23 373220
IB 340505 (8-01)

REPAIR PARTS LIST FOR PUMP PART # 373419

Machine
Description
Serial Number
(000000-- ) In seal kit #61881
(000000-- ) Pin, dowel
(000000-- ) Washer
(000000-- ) In seal kit #61881
(000000-- ) In seal kit #61881
(000000-- ) Screws
(000000-- ) Spring
(000000-- ) Plug S/A
(000000-- ) O--ring, 2.38 mm Dia. X 22.23 mm I.D.
(000000-- ) Rotating kit
(000000-- ) Cover seal
(000000-- ) Trunion cover
(000000-- ) O--ring cover
(000000-- ) Bearing race
(000000-- ) Bearing
(000000-- ) In seal kit #61881
(000000-- ) Race, bearing
(000000-- ) Bearing
(000000-- ) Cap screw
(000000-- ) Cap screw
(000000-- ) In seal kit #61881
(000000-- ) In seal kit #61881
(000000-- ) Rel vlv assembly 4500
(000000-- ) Rel vlv assembly 4500
No. 340505
Machine: 95, 550
Published: 8-01/00
