2.2 SIP Weatherproof Keypad Phone Components
Figure 2-1
Operations Guide
shows the components of the SIP Weatherproof Keypad Phone.
Figure 2-1. SIP Weatherproof Keypad Phone Components
931475A
Installing the SIP Weatherproof Keypad Phone
SIP Weatherproof Keypad Phone Components
HEAVY DUTY
HANDSET WITH
1
2
3
HANDSET RETAINERS
4
5
6
7
8
9
*
#
0
THERMOPLASTIC
RESIN ENCLOSURE
CyberData Corporation
MAGNETIC REED
HOOK SWITCH
FACEPLATE-14 GA
STEEL, SATIN COAT
PRIMED AND
POWDER COATED
VOLUME CONTROL
ARMORED HANDSET
CORD
