CyberData 011460 Operation Manual

Sip weatherproof keypad phone
Hide thumbs Also See for 011460:
Table of Contents

Advertisement

Quick Links

Download this manual
The IP Endpoint Company
SIP Weatherproof Keypad Phone
Operations Guide
Part #011460
Document Part #931475A
for Firmware Version 11.0.1
CyberData Corporation
3 Justin Court
Monterey, CA 93940
(831) 373-2601

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 011460 and is the answer not in the manual?

Questions and answers

Related Manuals for CyberData 011460

Summary of Contents for CyberData 011460

  • Page 1 The IP Endpoint Company SIP Weatherproof Keypad Phone Operations Guide Part #011460 Document Part #931475A for Firmware Version 11.0.1 CyberData Corporation 3 Justin Court Monterey, CA 93940 (831) 373-2601...
  • Page 2 CyberData Corporation. This manual, and the products, software, firmware, and/or hardware described in this manual are the property of CyberData Corporation, provided under the terms of an agreement between CyberData Corporation and recipient of this manual, and their use is subject to that agreement and its terms.
  • Page 3 Revision 931475A, which corresponds to firmware version 11.0.1, was released on May 7, 2018. Browsers Supported The following browsers have been tested against firmware version 11.0.1: • Internet Explorer (version: 10) • Firefox (also called Mozilla Firefox) (version: 33.0) • Chrome (version 48.0.2564.116) • Safari (version: 5.1.7) Operations Guide 931475A CyberData Corporation...
  • Page 4 Potential safety hazards are identified in this manual through the use of words Danger, Warning, and Caution, the specific hazard type, and pictorial alert icons. CyberData Corporation 931475A Operations Guide...

  • Page 5: Important Safety Instructions

    To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions. GENERAL ALERT Warning The PoE connector is intended for intra-building connections only and does not route to the outside plant. GENERAL ALERT CyberData Corporation 931475A Operations Guide...

  • Page 6: Table Of Contents

    B.1.2 In a Windows Environment ..................77 Appendix C Troubleshooting/Technical Support C.1 Frequently Asked Questions (FAQ) ..................78 C.2 Documentation ........................78 C.3 Contact Information ....................... 79 C.4 Warranty and RMA Information ..................... 79 Index Operations Guide 931475A CyberData Corporation...

  • Page 7: Chapter 1 Product Overview

    To identify the SIP Weatherproof Keypad Phone, look for a model number label similar to the one shown in Figure 1-1. Confirm the following: • The model number on the label should be 011460. • The serial number on the label should begin with 460. Figure 1-1. Model Number Label www.cyberdata.net...

  • Page 8: Typical System Installation

    The following figures illustrate how the SIP Weatherproof Keypad Phone can be installed as part of a VoIP phone system. Figure 1-2. Typical Installation Generic PoE Switch SIP Weatherproof Keypad Phone IP Phone IP PBX Server Operations Guide 931475A CyberData Corporation...

  • Page 9: Product Features

    Electronic ringer • Hearing aid compatible • Receiver volume adjustment • Electret noise reducing microphone for clear communication • Supports SRST (Survivable Remote Site Telephony) in a Cisco environment • Network web management and firmware download Operations Guide 931475A CyberData Corporation...

  • Page 10: Supported Protocols

    Audio Encodings PCMU (G.711 mu-law), PCMA (G.711 A-law) G.722, G.722.1 (SIREN7) G.729, G.729J, G.729EV 1.5 Supported SIP Servers The following link contains information on how to configure the device for the supported SIP servers: http://www.cyberdata.net/connecting-to-ip-pbx-servers/ Operations Guide 931475A CyberData Corporation...

  • Page 11: Specifications

    ICES-3 Class A, IEEE 802.3 Compliant Part Number 011460 a. Contacts 3 and 4 on the terminal block are only for powering the device from a non-PoE +24VDC power source as an alternative to Network PoE power. Use of these contacts for any other purpose will damage the device and void the product warranty.

  • Page 12: Compliance

    Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Operations Guide 931475A CyberData Corporation...

  • Page 13: Chapter 2 Installing The Sip Weatherproof Keypad Phone

    SIP Weatherproof Keypad Phone parts. Note Appendix A, "Mounting the SIP Weatherproof Keypad Phone" for physical mounting information. Table 2-1. Parts List Quantity Part Name Illustration SIP Weatherproof Keypad Phone Assembly Installation Quick Reference Guide Operations Guide 931475A CyberData Corporation...

  • Page 14: Sip Weatherproof Keypad Phone Components

    SIP Weatherproof Keypad Phone. Figure 2-1. SIP Weatherproof Keypad Phone Components MAGNETIC REED HOOK SWITCH FACEPLATE-14 GA STEEL, SATIN COAT PRIMED AND POWDER COATED HEAVY DUTY HANDSET WITH VOLUME CONTROL HANDSET RETAINERS ARMORED HANDSET CORD THERMOPLASTIC RESIN ENCLOSURE Operations Guide 931475A CyberData Corporation...

  • Page 15: Setting Up The Device

    Network PoE power. Use of Can accept wire range from these contacts for any other purpose will damage the device and void the product warranty. 16 AWG to 24 AWG Operations Guide 931475A CyberData Corporation...

  • Page 16: Using The On-Board Relay

    Warning Equipment Hazard: The relay circuitry contains a non-replaceable 250VAC 1A fuse. If the fuse blows, the board must be returned to CyberData or an approved service center for repair. GENERAL ALERT The device relay activation time is selectable through the web interface on the Device Configuration Page (see Section 2.3.11, "Configure the...
  • Page 17 Installing the SIP Weatherproof Keypad Phone Setting up the Device Figure 2-3. Auxiliary Relay Wiring Diagram Operations Guide 931475A CyberData Corporation...

  • Page 18: Sip Weatherproof Keypad Phone Connectors

    Opto-Isolated Inputs/Outputs JTAG Interface — Factory Only Handset/Reed Switch Interface Speaker Interface Keypad Interface Console Port — Factory Only Terminal Block (see Figure 2-2) — Users Interface LCD Interface — Not Used Handset Volume Control Interface Operations Guide 931475A CyberData Corporation...

  • Page 19: Wiring

    RX pins 3 and 4 460000001 00:20:F7:03:83:D2 RJ45 connector Reset switch Handset Handset Volume Control Keypad RX pins 1 and 2 1. This figure is just an example, and the information on the board and labels may be different. Operations Guide 931475A CyberData Corporation...

  • Page 20: Activity And Link Leds

    100 Mb connection (see Figure 2-6). • The square, GREEN Link/Activity LED indicates and Ethernet link and blinks when there is network activity (see Figure 2-6). Figure 2-6. Activity and Link LED 100 Mb Link LED Link/Activity Operations Guide 931475A CyberData Corporation...
  • Page 21 Section 2.3.5.3, "Announcing the IP Address"). During the IP address announcement, you will hear the IP address through the handset receiver. Note You must do these tests prior to final assembly. Figure 2-7. RESET Switch Operations Guide 931475A CyberData Corporation...
  • Page 22 The device will use DHCP to obtain the new IP address (DHCP-assigned address or default to 10.10.10.10 if a DHCP server is not present). Note Pressing and holding the RESET switch for longer than five seconds will restore the device to the factory default settings. Figure 2-8. RESET Switch Operations Guide 931475A CyberData Corporation...

  • Page 23: Restoring The Factory Default Settings

    (approximately 5 seconds). 2. Release the RESET switch. Note The device will use DHCP to obtain the new IP address (DHCP-assigned address or default to 10.10.10.10 if a DHCP server is not present). Figure 2-9. RESET Switch Operations Guide 931475A CyberData Corporation...

  • Page 24: Adjusting The Volume

    Page. The volume can be adjusted in-call by using the buttons on the handset. 2.3.7 Operation • The user will hear a dial tone when the handset is lifted. • Adjust the receiver volume with the switch in the handset. Operations Guide 931475A CyberData Corporation...

  • Page 25: Sip Weatherproof Keypad Phone Web

    Link to the Device page. Link to the Network page. Link to go to the SIP page. Link to the Audiofiles page. Link to the Events page. Link to the Autoprovisioning page. Link to the Firmware page. Operations Guide 931475A CyberData Corporation...

  • Page 26: Using The Toggle Help Button

    2. You will see a question mark ( ) appear next to each web page item that has been provided with a short description by the Help feature. See Figure 2-11. Figure 2-11. Toggle Help Button and Question Marks Question mark appears next to the web page items Toggle Help button Operations Guide 931475A CyberData Corporation...
  • Page 27 3. Move the mouse pointer to hover over the question mark ( ), and a short description of the web page item will appear. See Figure 2-12. Figure 2-12. Short Description Provided by the Help Feature A short description of the Question mark web page item will appear Operations Guide 931475A CyberData Corporation...

  • Page 28: Log In To The Configuration Home Page

    Make sure that the PC is on the same IP network as the SIP Weatherproof Keypad Phone. Note You may also download CyberData’s VoIP Discovery Utility program which allows you to easily find and configure the default web address of the CyberData VoIP products.
  • Page 29 Installing the SIP Weatherproof Keypad Phone Setting up the Device Figure 2-13. Home Page CyberData Industrial VoIP Phone 460100001 v11.0.1 Operations Guide 931475A CyberData Corporation...
  • Page 30 After selecting a configuration file, click Import to import the configuration from the selected file. Then, click Save and Reboot to store changes. Export Settings Click Export to export the current configuration to a file. Operations Guide 931475A CyberData Corporation...
  • Page 31 The user name and password will be saved immediately, but the user will not be prompted to enter them until there is a reboot. It is advisable to restart the web browser after this change. Operations Guide 931475A CyberData Corporation...

  • Page 32: Configure The Device

    Installing the SIP Weatherproof Keypad Phone Setting up the Device 2.3.11 Configure the Device 1. Click the Device menu button to open the Device page. See Figure 2-14. Figure 2-14. Device Configuration Page CyberData Industrial VoIP Phone Operations Guide 931475A CyberData Corporation...
  • Page 33 When Auto-Answer Incoming Calls is enabled, the device will not ring and this option does nothing. Activate Relay During Night Ring When selected, the relay will be activated as long as the Nightringer extension is ringing. Operations Guide 931475A CyberData Corporation...
  • Page 34 Note You must click on the Save button and then the Reboot button for the changes to take effect. Operations Guide 931475A CyberData Corporation...
  • Page 35 Time of day to change M11.1.0/2:00:00 The date and time when daylight savings ends. The eleventh month (November) The 1st occurrence of the day (next item) in the month Sunday /2:00:00 Time of day to change Operations Guide 931475A CyberData Corporation...
  • Page 36 CST, Central US GMT-5 EST, Eastern US GMT-4 Atlantic, Canada GMT-3 Brazilia, Buenos Aries GMT-2 Mid-Atlantic GMT-1 Cape Verdes Greenwich Mean Time, Dublin GMT+1 Berlin, Rome GMT+2 Israel, Cairo GMT+3 Moscow, Kuwait GMT+4 Abu Dhabi, Muscat Operations Guide 931475A CyberData Corporation...
  • Page 37 Time Zone City or Area Zone Crosses GMT+5 Islamabad, Karachi GMT+6 Almaty, Dhaka GMT+7 Bangkok, Jakarta GMT+8 Hong Kong, Beijing GMT+9 Tokyo, Osaka GMT+10 Sydney, Melbourne, Guam GMT+11 Magadan, Soloman Is. GMT+12 Fiji, Wellington, Auckland Operations Guide 931475A CyberData Corporation...

  • Page 38: Configure The Network Parameters

    Installing the SIP Weatherproof Keypad Phone Setting up the Device 2.3.12 Configure the Network Parameters 1. Click the Network menu button to open the Network page (Figure 2-16). Figure 2-16. Network Configuration Page CyberData Industrial VoIP Phone Operations Guide 931475A CyberData Corporation...
  • Page 39 Subnet Mask Shows the current Subnet Mask address. Default Gateway Shows the current Default Gateway address. DNS Server 1 Shows the current DNS Server 1 address. DNS Server 2 Shows the current DNS Server 2 address. Operations Guide 931475A CyberData Corporation...
  • Page 40 Move the mouse pointer to hover over a question mark to see a short description of a specific web page item. Note You must click on the Save button and then the Reboot button for the changes to take effect. Operations Guide 931475A CyberData Corporation...

  • Page 41: Configure The Sip (Session Initiation Protocol) Parameters

    Setting up the Device 2.3.13 Configure the SIP (Session Initiation Protocol) Parameters 1. Click on the SIP menu button to open the SIP page (Figure 2-17). Figure 2-17. SIP Configuration Page CyberData Industrial VoIP Phone Operations Guide 931475A CyberData Corporation...
  • Page 42 SIP registration authentication. Enter up to 64 alphanumeric characters. Backup SIP Auth Password 1 Specify the Authenticate Password for the first backup SIP server. This parameter is required for SIP registration authentication. Enter up to 64 alphanumeric characters. Operations Guide 931475A CyberData Corporation...
  • Page 43 SIP server. Any calls made to this extension will play a ringtone (corresponds to Night Ring on the Audiofiles page). By design, it is not possible to answer a call to the Nightringer extension. Operations Guide 931475A CyberData Corporation...
  • Page 44 When configured, this option will allow you to force the device to negotiate for the selected codec. Otherwise, the device will perform codec negotiation using the default list of supported codecs. Codec Select the desired codec (only one may be chosen). Operations Guide 931475A CyberData Corporation...
  • Page 45 Note You must click on the Save button and then the Reboot button for the changes to take effect. Note For specific server configurations, go to the following website address: http://www.cyberdata.net/connecting-to-ip-pbx-servers/ Operations Guide 931475A CyberData Corporation...
  • Page 46 DTMF tone '2', send out DTMF tone 5, wait 6 seconds, send out DTMF tone 4, wait 4 seconds, send out DTMF tone 1 Note The maximum number of total characters in the dial-out field is 64. Operations Guide 931475A CyberData Corporation...
  • Page 47 Point-to-Point calls. The delayed DTMF functionality is available in the Point-to-Point Mode. Note Receiving point-to-point SiP calls may not work with all phones. Figure 2-18. SIP Page Set to Point-to-Point Mode CyberData Industrial VoIP Phone Device is set to NOT register with a SiP server Operations Guide 931475A CyberData Corporation...
  • Page 48 DTMF tone '2', send out DTMF tone 5, wait 6 seconds, send out DTMF tone 4, wait 4 seconds, send out DTMF tone 1 Note The maximum number of total characters in the dial-out field is 25. Operations Guide 931475A CyberData Corporation...

  • Page 49: Configure The Audio Configuration Parameters

    The Audiofiles page is used to add custom audio to the board. User uploaded audio will take precedence over the audio files shipped with the device. 1. Click on the Audiofiles menu button to open the Audiofiles page (Figure 2-19). Figure 2-19. Audiofiles Configuration Page CyberData Industrial VoIP Phone Operations Guide 931475A CyberData Corporation...
  • Page 50 The Delete button will delete any user uploaded audio and restore the stock audio file. The Save button will download a new user audio file to the board once you've selected the file by using the Browse button. The Save button will delete any pre-existing user-uploaded audio files. Operations Guide 931475A CyberData Corporation...
  • Page 51 RIFF (little-endian) data, WAVE audio, Microsoft PCM, 16 bit, mono 8000 Hz You can use the free utility Audacity to convert audio files into this format. See Figure 2-20 through Figure 2-22. Figure 2-20. Audacity 1 Figure 2-21. Audacity 2 Operations Guide 931475A CyberData Corporation...
  • Page 52 Setting up the Device When you export an audio file with Audacity, save the output as: • WAV (Microsoft) signed 16 bit PCM. Figure 2-22. WAV (Microsoft) signed 16 bit PCM WAV (Microsoft) signed 16 bit PCM Operations Guide 931475A CyberData Corporation...

  • Page 53: Configure The Events Parameters

    The Events page specifies a remote server that can be used to receive HTTP POST events when actions take place on the board. 1. Click on the Events menu button to open the Events page (Figure 2-23). Figure 2-23. Event Configuration Page CyberData Industrial VoIP Phone Operations Guide 931475A CyberData Corporation...
  • Page 54 HTTP POST events. Enter up to 127 characters. Click the Save button to save your configuration settings. Note: You need to reboot for changes to take effect. Click on the Reboot button to reboot the system. Operations Guide 931475A CyberData Corporation...
  • Page 55 Note You must click on the Save button for the changes to take effect. Note Selecting particular events, Check All, or Uncheck All does not require a reboot for the changes to take effect. Operations Guide 931475A CyberData Corporation...
  • Page 56 Here are example packets for every event: POST xmlparse_engine HTTP/1.1 Host: 10.0.3.79 User-Agent: CyberData/1.0.0 Content-Length: 197 Content-Type: application/x-www-form-urlencoded <?xml version="1.0" encoding="ISO-8859-1"?> <cyberdata NAME='CyberData VoIP Device' MAC='0020f70015b6'> <event>POWERON</event> </cyberdata> POST xmlparse_engine HTTP/1.1 Host: 10.0.3.79 User-Agent: CyberData/1.0.0 Content-Length: 199 Content-Type: application/x-www-form-urlencoded <?xml version="1.0"...
  • Page 57 Installing the SIP Weatherproof Keypad Phone Setting up the Device User-Agent: CyberData/1.0.0 Content-Length: 205 Content-Type: application/x-www-form-urlencoded <?xml version="1.0" encoding="ISO-8859-1"?> <cyberdata NAME='CyberData VoIP Device' MAC='0020f70015b6'> <event>CALL_TERMINATED</event> </cyberdata> POST xmlparse_engine HTTP/1.1 Host: 10.0.3.79 User-Agent: CyberData/1.0.0 Content-Length: 197 Content-Type: application/x-www-form-urlencoded <?xml version="1.0" encoding="ISO-8859-1"?>...
  • Page 58 Installing the SIP Weatherproof Keypad Phone Setting up the Device User-Agent: CyberData/1.0.0 Content-Length: 234 Content-Type: application/x-www-form-urlencoded <?xml version="1.0" encoding="ISO-8859-1"?> <cyberdata NAME='CyberData VoIP Device' MAC='0020f70015b6'> <event>RELAY_DEACTIVATED</event> </cyberdata> POST xmlparse_engine HTTP/1.1 Host: 10.0.3.79 User-Agent: CyberData/1.0.0 Content-Length: 234 Content-Type: application/x-www-form-urlencoded <?xml version="1.0" encoding="ISO-8859-1"?>...

  • Page 59: Configure The Autoprovisioning Parameters

    By default, the device will try to set up its configuration with autoprovisioning. 1. Click the Autoprov menu button to open the Autoprovisioning page. See Figure 2-24. Figure 2-24. Autoprovisioning Page CyberData Industrial VoIP Phone Operations Guide 931475A CyberData Corporation...
  • Page 60 Set Time with NTP Server on boot setting on the Device Configuration Page page (see Table 2-5). Click the Save button to save your configuration settings. Note: You need to reboot for changes to take effect. Operations Guide 931475A CyberData Corporation...
  • Page 61 3. Option 150 - an IP address to a tftp server 4. Option 66 - an IP address to a tftp server or if the entry starts with 'http', a FQDN to a http server. Operations Guide 931475A CyberData Corporation...
  • Page 62 Autoprovisioning files can contain the whole configuration or a subset of this file. The first autoprovisioning file can also contain links to other autoprovisioning files. The <MiscSettings> section contains some examples of additional autoprovisioning files: <MiscSettings> <DeviceName>CyberData VoIP Device</DeviceName> <!-- <AutoprovFile>common.xml</AutoprovFile>--> <!-- <AutoprovFile>sip_reg[macaddress].xml</AutoprovFile>-->...
  • Page 63 When one of these options is set, the Files after Boot device will download its autoprovisioning files again, and if it finds any differences from the files it downloaded on boot, it will force a reboot and reconfigure. Operations Guide 931475A CyberData Corporation...
  • Page 64 The autoprovisioning filename is set to “cyberdata/” On boot, the device will try to download: https://www.example.com/cyberdata/0020f7123456.xml ...and if this fails: https://www.example.com/cyberdata/000000cd.xml Audio files and firmware files will also add “cyberdata” to the URL before downloading. Operations Guide 931475A CyberData Corporation...
  • Page 65 In this way, a generic autoprovisioning file can specify unique firmware for a range of products. The list of valid product strings: <ProductString>CallButton31</ProductString> <ProductString>EmergencyIntercom31</ProductString> <ProductString>EmergencyIntercom31SW</ProductString> <ProductString>IndoorIntercom31</ProductString> <ProductString>IndoorIntercom31SW</ProductString> <ProductString>IndoorKeypad31</ProductString> <ProductString>IndoorKeypad31SW</ProductString> <ProductString>OfficeRinger31</ProductString> <ProductString>OfficeRinger31SW</ProductString> <ProductString>OutdoorIntercom31</ProductString> <ProductString>OutdoorIntercom31SW</ProductString> <ProductString>OutdoorKeypad31</ProductString> <ProductString>OutdoorKeypad31SW</ProductString> <ProductString>Strobe31</ProductString> <ProductString>Strobe31SW</ProductString> Operations Guide 931475A CyberData Corporation...
  • Page 66 000000cd.xml. This file exists, and Device1 parses the three elements. 1. Device1 changes its device name to CyberData Autoprovisioned. 2. Device1 finds an AutoprovFile element containing the filename sip_common.xml. The device downloads sip_common.xml from “https://autoprovtest.server.net,”...
  • Page 67 TFTP server at 10.0.1.3. and imports these settings. The device name is set to CyberData Autoprovisioned, the SIP server is set to 10.0.0.253, and the port is set to 5060. Device2 does the same except it downloads 0020f7020002.xml on boot and imports these values instead.
  • Page 68 You can force a change to the audio files on the board by clicking Restore Default on the Audio Configuration page or by changing the autoprovisioning file with “default” set as the file name. Operations Guide 931475A CyberData Corporation...
  • Page 69 "http://test.cyberdata.net"; # OPTION 66 option option-150 10.0.0.252; # OPTION 150 # These two lines are needed for option 43 vendor-option-space VendorInfo; # OPTION 43 option VendorInfo.text "http://test.cyberdata.net"; # OPTION 43 range 10.10.0.1 10.10.2.1; } Operations Guide 931475A CyberData Corporation...
  • Page 70 4. At this point, you can open and edit the autoprovisioning template to change the configuration settings in the template for the unit. 5. You can then upload the autoprovisioning file to a TFTP or HTTP server where the file can be loaded onto other devices. Operations Guide 931475A CyberData Corporation...

  • Page 71: Upgrade The Firmware And Reboot The Sip Weatherproof Keypad Phone

    4. Click on the Firmware menu button to open the Firmware page. See Figure 2-26. Caution Equipment Hazard: CyberData strongly recommends that you first reboot the device before attempting to upgrade the firmware of the device. See Section 2.4.2, "Reboot the Device".
  • Page 72 Shows the current firmware version. Use the Browse button to navigate to the location of the firmware file that you want to upload. Click on the Upload button to automatically upload the selected firmware and reboot the system. Operations Guide 931475A CyberData Corporation...

  • Page 73: Reboot The Device

    "Log in to the Configuration Home Page". 1. Click on the Reboot button on the Home page (Figure 2-27). A normal restart will occur. Figure 2-27. Home Page CyberData Industrial VoIP Phone 460100001 v11.0.1 Reboot button Operations Guide 931475A CyberData Corporation...

  • Page 74: Command Interface

    --user admin --password admin --auth-no-challenge --no- check-certificate --quiet -O /dev/null "https://10.0.3.71/cgi-bin/ audiofiles.cgi" --post-data "play_2=yes" Play the "3" audio file wget --user admin --password admin --auth-no-challenge --no- check-certificate --quiet -O /dev/null "https://10.0.3.71/cgi-bin/ audiofiles.cgi" --post-data "play_3=yes" Operations Guide 931475A CyberData Corporation...
  • Page 75 --user admin --password admin --auth-no-challenge --no- check-certificate --quiet -O /dev/null "https://10.0.3.71/cgi-bin/ audiofiles.cgi" --post-data "play_intrusionsensortriggered=yes" Play the "Door Ajar" audio file wget --user admin --password admin --auth-no-challenge --no- check-certificate --quiet -O /dev/null "https://10.0.3.71/cgi-bin/ audiofiles.cgi" --post-data "play_doorajar=yes" Operations Guide 931475A CyberData Corporation...
  • Page 76 --user admin --password admin --auth-no-challenge --no- check-certificate --quiet -O /dev/null "https://10.0.3.71/cgi-bin/ audiofiles.cgi" --post-data "delete_rebooting=yes" Delete the "Restoring Default" audio file wget --user admin --password admin --auth-no-challenge --no- check-certificate --quiet -O /dev/null "https://10.0.3.71/cgi-bin/ audiofiles.cgi" --post-data "delete_restoringdefault=yes" Operations Guide 931475A CyberData Corporation...
  • Page 77 --user admin --password admin --auth-no-challenge --no- check-certificate --quiet -O /dev/null "https://10.0.3.71/cgi-bin/ sensor.cgi" --post-data "intrusiontest=yes" a.Type and enter all of each http POST command on one line. b. Must be in point-to-point mode see Section 2.3.13.2, "Point-to-Point Configuration" Operations Guide 931475A CyberData Corporation...

  • Page 78: Appendix A Mounting The Sip Weatherproof Keypad Phone

    Appendix A: Mounting the SIP Weatherproof Keypad Phone A.1 Parts List Table A-1 illustrates the SIP Weatherproof Keypad Phone parts. Table A-1. Parts List Quantity Part Name Illustration SIP Weatherproof Keypad Phone Assembly Door Faceplate Installation Quick Reference Guide Operations Guide 931475A CyberData Corporation...

  • Page 79: Installation

    14. Set up and configure if changes are required to the default settings. 15. Test the unit by calling to and from another device, preferably a VoIP device. See the Operations Guide for LED details. Operations Guide 931475A CyberData Corporation...

  • Page 80: Dimensions

    Mounting the SIP Weatherproof Keypad Phone Dimensions A.3 Dimensions Figure A-1. Dimensions 11.6" [296mm] 7.9" [200mm] 7.9” [200 mm] 11.6” [296 mm] 8.0” [202 mm] 8.00" [203mm] Ø0.41" [Ø10.4mm] 0.41” [ 10.4 mm] Operations Guide 931475A CyberData Corporation...

  • Page 81: Drilling Holes On The Outside Of The Chassis

    Note The size of the hole depends on the installer’s conduit size and location is based on the routing. Figure A-2. Back of Chassis—Can be used for routing cable Operations Guide 931475A CyberData Corporation...
  • Page 82 Mounting the SIP Weatherproof Keypad Phone Drilling Holes on the Outside of the Chassis Figure A-3. Bottom of Chassis Figure A-4. Top of Chassis Operations Guide 931475A CyberData Corporation...

  • Page 83: Appendix B Setting Up A Tftp Server

    1. Install and start the software. 2. Select File Configure Security tab Transmit Only. 3. Make a note of the default directory name, and then move the firmware files to be uploaded to that directory. Operations Guide 931475A CyberData Corporation...

  • Page 84: Appendix C Troubleshooting/Technical Support

    To see a list of frequently asked questions for your product, click on the FAQs tab at the following webpage: http://www.cyberdata.net/voip/011460/ C.2 Documentation The documentation for this product is released in an English language version only. To download PDF copies of CyberData product documentation, click on the Downloads tab at the following webpage: http://www.cyberdata.net/voip/011460/ Operations Guide 931475A...

  • Page 85: Contact Information

    Support form at the following website: http://support.cyberdata.net/ The Support Form initiates a ticket which CyberData uses for tracking customer requests. Most importantly, the Support Form tells us which PBX system and software version that you are using, the make and model of the switch, and other important information. This information is essential for troubleshooting.

  • Page 86: Index

    65 SIP 35 configuration home page 22 configuration page configurable parameters 27, 33 contact information 79 contact information for CyberData 79 get autoprovisioning template 55 current network settings 33 GMT table 30 CyberData contact information 79 GMT time 30...
  • Page 87 9 settings, default 17 enable SIP operation 36 local SIP port 37 on-board relay 5, 10 user ID 36 overview of installation types 74, 75, 76 SIP configuration 35 SIP configuration parameters Operations Guide 931475A CyberData Corporation...
  • Page 88 22 VLAN ID 33 VLAN Priority 33 VLAN tagging support 33 VLAN tags 33 warranty policy at CyberData 79 web configuration log in address 22 web page navigation 19 web page navigation 19 wget, free unix utility 68...
