- Page 1 ® Bookwalter Retractor System Assembly Instructions symmetry surgical confidential...
-
Page 2: Instructions For Use
• The retractor system can exert a great amount of force on the wound edges and on tissue. Release the retractor for short periods of time or shift the blades to relieve the pressure on any one point. symmetry surgical confidential... - Page 3 Electrosurgical Precautions • If using monopolar electrosurgical equipment while using a BOOKWALTER Retractor, consult the basic rules of usage concerning electrosurgery, (see EN 60 601-2-2), as well as the manufacturer’s instructions for use regarding specific warnings and conditions. • Be sure to electrically isolate the patient from (high frequency...
- Page 4 It may be necessary to pad the table post or reposition the patient to prevent pressure related necrosis. • Pull up the handle at the top of the table post and turn it clockwise to tighten onto the OR table rail symmetry surgical confidential...
- Page 5 • In this orientation the horizontal bar is further from the surgeon and creates slightly more space to work in • Do not tighten the post coupling without table post or horizontal bars inserted symmetry surgical confidential...
- Page 6 • Tighten by rotating the lock clockwise • If using a horizontal flex bar adjust the position of the ring to the desired location and turn the locking handle clockwise to lock it in place Tighten Here symmetry surgical confidential...
- Page 7 So the gear rack faces the blade release lever Release Lever • Slide ratchet onto outside of ring • Retract as required • Periodically release blades to prevent Slide Onto pressure necrosis of retracted tissue Ring Here symmetry surgical confidential...
