Predator Hybrid Installation Manual V2.1.25
General Settings Menu
Offers more camera options.
General 1
•
Digital Zoom - Use this option to enable or disable digital zoom.
•
White Balance - Change the camera white balance settings to suit the area.
•
Line Lock - Used to line lock the camera.
•
Line Phase - Can be used to manually adjust the line phase.
•
Video Gain - Used to adjust the video level to suit different lengths of coax cable.
•
Video Lift - Used to adjust the frequency of the video level to suit different lengths of coax cable.
•
Wide Dynamic - Enable WDR. Options available are ON, Auto and Off. Default is off.
•
Sunshield - Reduces tilt range of the camera for when a sunshield is fitted.
General 2
•
Auto Flip - Use this option to set how the camera behaves when full tilt down is reached.
Semi - Requires a second tilt down command when at full tilt down to spin camera 180°.
Full - Automatically spins the camera 180°.
•
Proportional - Automatically reduces/increases pan/tilt speed depending on zoom ratio.
•
Freeze Presets - This option freezes the image, when moving between presets.
•
Zoom Speed - Select zoom speed of the lens. Options are slow, medium, high and highest.
•
OSD Preset Six - Go into OSD using preset 95 and you can switch off OSD access using preset 6.
•
Upright Mount - Can be used to flip the image, so the camera can be used on a pole or a ceiling.
Default is pole.
•
Aperture(day) - Can be used to increase the picture detail. Default is 10.
•
Attack Detect - Camera will re-initialise camera motors so that camera looks back to the original
position, if the camera is physically forced/moved. Default is on.
General 3
•
Wiper Rest - Input a rest time for the wiper.
•
Wiper On Time (h, m, & s) - Input a time period for the wiper operation.
(See also Special Presets page 45).
•
Wiper Permanent - Enable or disable the permanent wiper time period.
•
FV Text Control - Used on systems using Forward Vision protocol. Will add ANPR text on screen
when camera is put into fast shutter mode.
•
AF AI When PTZ - Auto focus/iris will activate when PTZ is used, can be switched off. Default is on.
•
Noise Reduction (day) - Used to reduce noise. NR must be set to suit the environment. Default is off.
General 4
•
Define Preset - Option to enable/disable the setting of presets. Default is on.
•
Pelco D Response - Used on systems using Pelco D protocol where a response from the camera is
required.
!
control of the camera.
•
Ultrak CMD T/out - Disables Ultrak KD6 100mS command timeout.
•
Pelco Static Mode - Disables PTZ control.
•
NG IR Lens Option - Choice of wide or narrow IR lenses that will be used when activated. Requires
additional IR alarmcard.
•
Arms - Set if the Predator arms are CANTED or STRAIGHT.
Pelco
Used when using Pelco protocol auxiliary commands. Associate a function of the camera to a Pelco Aux
command.
Do not use if the system doesn't require a response as it will have an affect on the telemetry
© 360 Vision Technology Ltd.
(See also Special Presets page 45).
FOR PRODUCTION USE ONLY
Page 16
