- Page 1 M6-700, M6-705, M6-715, M7-700, M7-705 or M7-715 Managing devices REFERENCE 86 A1 76FG 03...
- Page 3 - Bull Escala E1-700 (Power 710 / 8231-E2B) - Bull Escala E1-705 (Power 710 / 8231-E1C) - Bull Escala E2-700 / E2-700T (Power 720 / 8202-E4B) - Bull Escala E2-705 / E2-705T (Power 720 / 8202-E4C) - Bull Escala E3-700 (Power 730 / 8231-E2B)
- Page 4 Quoting of brand and product names is for information purposes only and does not represent trademark misuse. The information in this document is subject to change without notice. Bull will not be liable for errors contained herein, or for incidental or consequential damages in connection with the use of this material.
-
Page 5: Table Of Contents
Contents Safety notices ....... . . v Managing devices ....... 1 Managing DVD drives . - Page 6 Managing devices...
-
Page 7: Safety Notices
Safety notices Safety notices may be printed throughout this guide. v DANGER notices call attention to a situation that is potentially lethal or extremely hazardous to people. v CAUTION notices call attention to a situation that is potentially hazardous to people because of some existing condition. - Page 8 DANGER When working on or around the system, observe the following precautions: Electrical voltage and current from power, telephone, and communication cables are hazardous. To avoid a shock hazard: v Connect power to this unit only with the provided power cord. Do not use the provided power cord for any other product.
- Page 9 Observe the following precautions when working on or around your IT rack system: v Heavy equipment–personal injury or equipment damage might result if mishandled. v Always lower the leveling pads on the rack cabinet. v Always install stabilizer brackets on the rack cabinet. v To avoid hazardous conditions due to uneven mechanical loading, always install the heaviest devices in the bottom of the rack cabinet.
- Page 10 CAUTION: Removing components from the upper positions in the rack cabinet improves rack stability during relocation. Follow these general guidelines whenever you relocate a populated rack cabinet within a room or building: v Reduce the weight of the rack cabinet by removing equipment starting at the top of the rack cabinet.
- Page 11 (L003) All lasers are certified in the U.S. to conform to the requirements of DHHS 21 CFR Subchapter J for class 1 laser products. Outside the U.S., they are certified to be in compliance with IEC 60825 as a class 1 laser product.
- Page 12 CAUTION: Data processing environments can contain equipment transmitting on system links with laser modules that operate at greater than Class 1 power levels. For this reason, never look into the end of an optical fiber cable or open receptacle. (C027) CAUTION: This product contains a Class 1M laser.
-
Page 13: Managing Devices
Managing devices Learn about managing media and communications devices. The topic collection contains reference information that information technology (IT) personnel and service representatives can use to learn about using and managing removable media devices and communications devices. You can also find specifications and installation notes for specific devices. The following listed features are electromagnetic compatibility (EMC) Class B features. - Page 14 Managing devices...
-
Page 15: Managing Dvd Drives
Managing DVD drives Learn about using and managing removable media devices. Find specifications and installation notes for specific drives. SATA Slimline DVD-RAM Drive (FC 5762) Learn about the specifications of this DVD-RAM drive. The serial advanced technology attachment (SATA) Slimline DVD-RAM Drive is an internal, low profile DVD-RAM drive that is capable of reading and writing 4.7 GB DVD-RAM discs, as well as reading a multitude of other optical media discs. -
Page 16: Handling And Storing The Dvd Media
Specifications v FRU part number: 74Y7341 v Custom card identification number (CCIN): 6331 model 004 v Media: – Reads CD-ROM, CD-R, CD-RW, DVD-ROM, and DVD-RAM discs – Writes 4.7 GB DVD-RAM discs v Interface: SATA v Connector: Slimline SATA v Connector: SATA v Loading tray: supports 12 cm and 8 cm discs v Operating positions: vertical or horizontal (8 cm discs require horizontal operation) v Form factor: 12.7 mm Slimline... -
Page 17: Opening A Dvd Tray Manually
Opening a DVD tray manually Under usual conditions, the tray automatically opens when you press the Load/Unload button. If it does not automatically open, you can use the emergency eject feature to open the tray manually. Follow these steps to manually open the tray: 1. - Page 18 drive. Only for playback in DVD-ROM drives compatible with DVD-RAM. drive. Only for playback in DVD-ROM drives compatible with DVD-RAM. The DVD-RAM T The DVD-RAM T Locking Pin Lock Button Cartridge Lid Returning a disc to the cartridge To return a disc to the cartridge, do the following steps: Notes: Both the disc label and the cartridge label should be facing up.
-
Page 19: Managing Diskette Drives
Managing diskette drives Learn about the features of specific diskette drives. External USB 1.44 MB diskette drive (FC 2591) Learn about the features of this media device. The following provides information about the external USB 1.44 MB diskette drive. Installation To install this external USB 1.44 MB diskette drive, complete the following steps: 1. - Page 20 Managing devices...
-
Page 21: Managing Removable Disk Drives
Managing removable disk drives Learn about using and managing removable disk drives. Find specifications and installation notes for specific drives. RDX USB External Dock (1104 and EU04) and RDX Removable Disk Drives (1106, 1107, EU01, and EU08) Learn about the features of this drive. Description The USB removable disk drive consists of a docking station, which holds a removable disk drive. - Page 22 Power connector USB connector Feature codes and part numbers Learn about the feature codes (FCs) and part numbers for the USB Removable Disk Drive. FC 1104 - USB External Docking Station for Removable Disk Drive FC 1104 uses an external USB cable to connect to an external USB port. The 1104 feature code includes a USB cable, an external power supply, and a power cord as part of the feature code.
-
Page 23: Specifications
Storing removable disk drives Store removable disk drives in their protective containers, on a flat surface with the top side up. The storage area must be clean and dry, must have normal room temperature, and must be away from any magnetic fields. - Page 24 Using the USB Removable Disk Drive for backup and restore The disk drive is a backup and restore device that can be used as an alternative to tape drives. The removable disk drive is not a replacement for regular disk drives and cannot be used as part of a disk array.
-
Page 25: Status Lights
3. When the drive has been ejected by the docking station, grasp the exposed sides of the drive and pull the drive straight out. 4. Restart your system to reset the docking station. If you are using the external docking station, reconnect the power cable for the docking station and then restart the system. - Page 26 Managing devices...
-
Page 27: Notices
Notices This information was developed for products and services offered in the U.S.A. The manufacturer may not offer the products, services, or features discussed in this document in other countries. Consult the manufacturer's representative for information on the products and services currently available in your area. -
Page 28: Trademarks
This information is for planning purposes only. The information herein is subject to change before the products described become available. This information contains examples of data and reports used in daily business operations. To illustrate them as completely as possible, the examples include the names of individuals, companies, brands, and products. - Page 29 harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his own expense.
- Page 30 This is a Class A product based on the standard of the VCCI Council. If this equipment is used in a domestic environment, radio interference may occur, in which case, the user may be required to take corrective actions. Japanese Electronics and Information Technology Industries Association (JEITA) Confirmed Harmonics Guideline (products less than or equal to 20 A per phase) Japanese Electronics and Information Technology Industries Association (JEITA) Confirmed Harmonics Guideline with Modifications (products greater than 20 A per...
- Page 31 Electromagnetic Interference (EMI) Statement - Korea Germany Compliance Statement Deutschsprachiger EU Hinweis: Hinweis für Geräte der Klasse A EU-Richtlinie zur Elektromagnetischen Verträglichkeit Dieses Produkt entspricht den Schutzanforderungen der EU-Richtlinie 2004/108/EG zur Angleichung der Rechtsvorschriften über die elektromagnetische Verträglichkeit in den EU-Mitgliedsstaaten und hält die Grenzwerte der EN 55022 Klasse A ein.
-
Page 32: Class B Notices
Generelle Informationen: Das Gerät erfüllt die Schutzanforderungen nach EN 55024 und EN 55022 Klasse A. Electromagnetic Interference (EMI) Statement - Russia Class B Notices The following Class B statements apply to features designated as electromagnetic compatibility (EMC) Class B in the feature installation information. Federal Communications Commission (FCC) statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 33 European Community Compliance Statement This product is in conformity with the protection requirements of EU Council Directive 2004/108/EC on the approximation of the laws of the Member States relating to electromagnetic compatibility. IBM cannot accept responsibility for any failure to satisfy the protection requirements resulting from a non-recommended modification of the product, including the fitting of non-IBM option cards.
-
Page 34: Terms And Conditions
Germany Compliance Statement Deutschsprachiger EU Hinweis: Hinweis für Geräte der Klasse B EU-Richtlinie zur Elektromagnetischen Verträglichkeit Dieses Produkt entspricht den Schutzanforderungen der EU-Richtlinie 2004/108/EG zur Angleichung der Rechtsvorschriften über die elektromagnetische Verträglichkeit in den EU-Mitgliedsstaaten und hält die Grenzwerte der EN 55022 Klasse B ein. Um dieses sicherzustellen, sind die Geräte wie in den Handbüchern beschrieben zu installieren und zu betreiben. - Page 35 these publications, or reproduce, distribute or display these publications or any portion thereof outside your enterprise, without the express consent of the manufacturer. Rights: Except as expressly granted in this permission, no other permissions, licenses or rights are granted, either express or implied, to the Publications or any information, data, software or other intellectual property contained therein.
