PCI Adapter Placement for E2-700, E2-
700T, E2-705, E2-705T, E4-700, E4-
700T or E4-705
REFERENCE
86 A1 88FF 05

Advertisement

Table of Contents
loading

Related Manuals for Bull Escala Power E2-700

Summary of Contents for Bull Escala Power E2-700

  • Page 1 PCI Adapter Placement for E2-700, E2- 700T, E2-705, E2-705T, E4-700, E4- 700T or E4-705 REFERENCE 86 A1 88FF 05...
  • Page 3 - Bull Escala E1-700 (Power 710 / 8231-E2B) - Bull Escala E1-705 (Power 710 / 8231-E1C) - Bull Escala E2-700 / E2-700T (Power 720 / 8202-E4B) - Bull Escala E2-705 / E2-705T (Power 720 / 8202-E4C) - Bull Escala E3-700 (Power 730 / 8231-E2B)
  • Page 4 Quoting of brand and product names is for information purposes only and does not represent trademark misuse. The information in this document is subject to change without notice. Bull will not be liable for errors contained herein, or for incidental or consequential damages in connection with the use of this material.

  • Page 5: Table Of Contents

    Contents Safety notices ....... . . v PCI adapter placement for the 02E/4B, 02E/4C, 05F/6B, or 05E/6C ... 1 Supported PCI adapters for the 02E/4B, 02E/4C, 05F/6B, or 05E/6C PCI adapter placement rules and slot priorities for the 02E/4B, 02E/4C, 05F/6B, or 05E/6C .
  • Page 6 PCI adapter placement for the 02E/4B, 02E/4C, 05F/6B, or 05E/6C...

  • Page 7: Safety Notices

    Safety notices Safety notices may be printed throughout this guide. v DANGER notices call attention to a situation that is potentially lethal or extremely hazardous to people. v CAUTION notices call attention to a situation that is potentially hazardous to people because of some existing condition.
  • Page 8 DANGER When working on or around the system, observe the following precautions: Electrical voltage and current from power, telephone, and communication cables are hazardous. To avoid a shock hazard: v Connect power to this unit only with the provided power cord. Do not use the provided power cord for any other product.
  • Page 9 Observe the following precautions when working on or around your IT rack system: v Heavy equipment–personal injury or equipment damage might result if mishandled. v Always lower the leveling pads on the rack cabinet. v Always install stabilizer brackets on the rack cabinet. v To avoid hazardous conditions due to uneven mechanical loading, always install the heaviest devices in the bottom of the rack cabinet.
  • Page 10 CAUTION: Removing components from the upper positions in the rack cabinet improves rack stability during relocation. Follow these general guidelines whenever you relocate a populated rack cabinet within a room or building: v Reduce the weight of the rack cabinet by removing equipment starting at the top of the rack cabinet.
  • Page 11 (L003) All lasers are certified in the U.S. to conform to the requirements of DHHS 21 CFR Subchapter J for class 1 laser products. Outside the U.S., they are certified to be in compliance with IEC 60825 as a class 1 laser product.
  • Page 12 CAUTION: Data processing environments can contain equipment transmitting on system links with laser modules that operate at greater than Class 1 power levels. For this reason, never look into the end of an optical fiber cable or open receptacle. (C027) CAUTION: This product contains a Class 1M laser.

  • Page 13: Pci Adapter Placement For The 02E/4B, 02E/4C, 05F/6B, Or 05E/6C

    PCI adapter placement for the 02E/4B, 02E/4C, 05F/6B, or 05E/6C Find information about the Peripheral Component Interconnect (PCI), PCI-X, and PCI Express (PCIe) adapters that are supported for the 7/20 (02E/4B or 02E/4C) or the 7/40 (05F/6B or 05E/6C) systems ®...
  • Page 14 PCI and PCI-X adapters The following table lists PCI and PCI-X adapters supported for the 02E/4B, 02E/4C, 05F/6B, or 05E/6C. Table 2. PCI and PCI-X adapters supported on the AIX, , or Linux operating system System supported Feature CCIN Description code 02E/4B, 02E/4C, 05F/6B, 2943...
  • Page 15 Table 2. PCI and PCI-X adapters supported on the AIX, , or Linux operating system (continued) System supported Feature CCIN Description code 02E/4B, 02E/4C, 05F/6B, 5758 1910 4 Gb Single-Port Fibre Channel PCI-X 2.0 DDR Adapter (FC and 05E/6C 5758; CCIN 1910) v PCI-X 2.0a, PCI 3.0, PCI-X Mode 2 - 266 MHz, PCI-X Mode 1 - 133 MHz, PCI - 66 MHz v High-speed data networking...
  • Page 16 Table 2. PCI and PCI-X adapters supported on the AIX, , or Linux operating system (continued) System supported Feature CCIN Description code 02E/4B and 02E/4C 1984 5707 IBM 2-Port Gigabit Ethernet-SX PCI-X Adapter (FC 1984; CCIN 5707) v Two full-duplex 10/100/1000Base-TX optical connections to Gigabit Ethernet LANs v High bandwidth 02E/4B, 02E/4C, 05F/6B,...
  • Page 17 Table 2. PCI and PCI-X adapters supported on the AIX, , or Linux operating system (continued) System supported Feature CCIN Description code 02E/4B and 02E/4C 5719 5719 10 Gigabit Ethernet-LR PCI-X Adapter (FC 5719; CCIN 5719) v Short, x4 v Extra-high bandwidth v OS support: AIX and Linux operating systems 02E/4B, 02E/4C, 05F/6B, 5721...
  • Page 18 Table 2. PCI and PCI-X adapters supported on the AIX, , or Linux operating system (continued) System supported Feature CCIN Description code 02E/4B, 02E/4C, 05F/6B, 5902 572B PCI-X DDR Ext Dual-x4 3 Gb SAS RAID Adapter (FC 5902; and 05E/6C CCIN 572B) v Long, 64-bit, 3.3 V v Extra-high bandwidth...
  • Page 19 Table 2. PCI and PCI-X adapters supported on the AIX, , or Linux operating system (continued) System supported Feature CCIN Description code 02E/4B and 02E/4C 2749 2749 PCI Ultra Magnetic Media Controller (FC 2749; CCIN 2749) v Short, 32-bit, 33 MHz v IOP controlled v This adapter might encounter performance limitations in PCI-X expansion units and systems.
  • Page 20 Table 2. PCI and PCI-X adapters supported on the AIX, , or Linux operating system (continued) System supported Feature CCIN Description code 02E/4B and 02E/4C 5776 571B PCI-X Disk Controller (FC 5776; CCIN 571B) v Long, 64-bit, 266 MHz v Extra-high bandwidth v Dual-mode capable adapter v The controller must be mirrored to be supported v OS support: AIX, , and Linux operating systems...
  • Page 21 Table 2. PCI and PCI-X adapters supported on the AIX, , or Linux operating system (continued) System supported Feature CCIN Description code 02E/4B, 02E/4C, 05F/6B, 6808 2805 PCI Quad Modem IOA (FC 6808; CCIN 2805) and 05E/6C v Long, 32-bit, 66 MHz v Non-CIM v OS support: operating system 02E/4B, 02E/4C, 05F/6B,...
  • Page 22 Table 3. PCIe adapters supported on the AIX, , or Linux operating system (continued) System supported Feature CCIN Description code 02E/4B, 02E/4C, 05F/6B, 5290 57D4 PCIe LP 2-port Async EIA-232 Adapter (FC 5290; CCIN 57D4) and 05E/6C v Low-profile adapter v PCIe 1.1 v Short, x8 v 2 Ports through RJ45 by using the DB9 connector...
  • Page 23 Table 3. PCIe adapters supported on the AIX, , or Linux operating system (continued) System supported Feature CCIN Description code 02E/4B, 02E/4C, 05F/6B, EN0Y EN0Y PCIe2 LP 8Gb 4-port Fibre Channel Adapter (FC EN0Y; CCIN and 05E/6C EN0Y) v Short, low-profile v PCIe generation-2, x8 v Short form factor plus (SFF+) Host Bus Adapter (HBA) v Extra-high bandwidth...
  • Page 24 Table 3. PCIe adapters supported on the AIX, , or Linux operating system (continued) System supported Feature CCIN Description code 02E/4B, 02E/4C, 05F/6B, 5275 2B54 10 Gigabit Ethernet-SR PCI Express Adapter (FC 5275; CCIN and 05E/6C 2B54) v Low-profile adapter v Short, x8 v OS support: AIX and Linux operating systems 02E/4B, 02E/4C, 05F/6B,...
  • Page 25 Table 3. PCIe adapters supported on the AIX, , or Linux operating system (continued) System supported Feature CCIN Description code 02E/4C and 05E/6C 5288 5288 PCIe2 LP 2-Port 10 GbE SFP+ Copper Adapter (FC 5288; CCIN 5288) v Generation-2, full-height adapter v Two 10 Gb Ethernet ports v Requires available PCIe generation-2 slot v OS support: AIX and Linux operating systems...
  • Page 26 Table 3. PCIe adapters supported on the AIX, , or Linux operating system (continued) System supported Feature CCIN Description code 02E/4B, 02E/4C, 05F/6B, 5769 2B44 10 Gigabit Ethernet-SR PCI Express Adapter (FC 5769; CCIN and 05E/6C 2B44) v Short, full-high, x8 v Low-profile capable v Extra-high bandwidth v OS support: AIX and Linux operating systems...
  • Page 27 Table 3. PCIe adapters supported on the AIX, , or Linux operating system (continued) System supported Feature CCIN Description code 02E/4C and 05E/6C EC30 EC29 PCIe2 2-Port 10 GbE RoCE SR adapter (FC EC30; CCIN EC29) v Regular-height adapter v PCIe generation-2, x8 v Extra-high bandwidth, low latency 10 Gb Ethernet v OS support: AIX and Linux operating systems v Firmware level 7.6 or later...
  • Page 28 Table 3. PCIe adapters supported on the AIX, , or Linux operating system (continued) System supported Feature CCIN Description code 02E/4B, 02E/4C, 05F/6B, 2055 57CD PCIe RAID and SSD SAS Adapter 3 Gb with Blind-Swap and 05E/6C Cassette (FC 2055; CCIN 57CD) v Low-profile adapter, requires two slots v Short, x8 v OS support: AIX, , and Linux operating systems...

  • Page 29: Pci Adapter Placement Rules And Slot Priorities For The 02E/4B, 02E/4C, 05F/6B, Or 05E/6C

    Table 3. PCIe adapters supported on the AIX, , or Linux operating system (continued) System supported Feature CCIN Description code 02E/4B, 02E/4C, 05F/6B, 2893 576C PCI Express 2-Line WAN with Modem (FC 2893; CCIN 576C) and 05E/6C v Short, x4 v Non-CIM v OS support: AIX, , and Linux operating systems 02E/4B, 02E/4C, 05F/6B,...
  • Page 30 Figure 2. Rear view of the 02E/4B and the 05F/6B system, showing the PCI riser expansion with location codes Table 4. PCI slot locations and descriptions for the 02E/4B and the 05F/6B Slot Location code Description Adapter size Slot 1 P1-C4 PCIe x8 PCIe PHB0 module A...
  • Page 31 full-height half-length slot. All slots support enhanced error handling (EEH), but are not hot pluggable. The PCIe slot 1 and slot 4 have an x16 connector, and the other slots have x8 connector. Table 5 lists the adapter slot locations and details for the 02E/4C and 05E/6C. Figure 3.
  • Page 32 Restriction: A GX channel adapter that has one or two of 58/77 or 58/02 expansion units, or one of each 58/77 and 58/02 expansion unit connected cannot have any other devices connected to that adapter. Note: For optimum performance, you might want to limit the total number of expansion units containing high bandwidth and extra-high bandwidth adapters.
  • Page 33 Table 6. Adapter slot priorities and maximum PCI, PCI-X, and PCIe adapters supported (continued) Feature Description 02E/4B and 05F/6B 02E/4C and 05E/6C code Slot priorities Maximum Slot priorities Maximum number of number of adapters adapters supported supported 5723 2-Port Asynchronous EIA-232 PCI All slots have the 24 and 48 All slots have the...
  • Page 34 Table 6. Adapter slot priorities and maximum PCI, PCI-X, and PCIe adapters supported (continued) Feature Description 02E/4B and 05F/6B 02E/4C and 05E/6C code Slot priorities Maximum Slot priorities Maximum number of number of adapters adapters supported supported 5716 2 Gigabit Fibre Channel PCI-X Adapter All slots have the All slots have the (FC 5716;...
  • Page 35 Table 6. Adapter slot priorities and maximum PCI, PCI-X, and PCIe adapters supported (continued) Feature Description 02E/4B and 05F/6B 02E/4C and 05E/6C code Slot priorities Maximum Slot priorities Maximum number of number of adapters adapters supported supported 1954 4-Port 10/100/1000 Base-TX PCI-X All slots have the 24 and 48 All slots have the...
  • Page 36 Table 6. Adapter slot priorities and maximum PCI, PCI-X, and PCIe adapters supported (continued) Feature Description 02E/4B and 05F/6B 02E/4C and 05E/6C code Slot priorities Maximum Slot priorities Maximum number of number of adapters adapters supported supported 1987 1-Gigabit iSCSI TOE PCI-X Adapter (FC All slots have the 24 and 48 All slots have the...
  • Page 37 Table 6. Adapter slot priorities and maximum PCI, PCI-X, and PCIe adapters supported (continued) Feature Description 02E/4B and 05F/6B 02E/4C and 05E/6C code Slot priorities Maximum Slot priorities Maximum number of number of adapters adapters supported supported 5718 10 Gigabit Ethernet-SR PCI-X Adapter All slots have the All slots have the (FC 5718;...
  • Page 38 Table 6. Adapter slot priorities and maximum PCI, PCI-X, and PCIe adapters supported (continued) Feature Description 02E/4B and 05F/6B 02E/4C and 05E/6C code Slot priorities Maximum Slot priorities Maximum number of number of adapters adapters supported supported 4801 PCI Cryptographic Coprocessor (FC 4801; All slots have the All slots have the CCIN 4758)
  • Page 39 Table 6. Adapter slot priorities and maximum PCI, PCI-X, and PCIe adapters supported (continued) Feature Description 02E/4B and 05F/6B 02E/4C and 05E/6C code Slot priorities Maximum Slot priorities Maximum number of number of adapters adapters supported supported 5904 PCI-X DDR 1.5 GB cache SAS RAID All slots have the All slots have the Adapter (FC 5904;...
  • Page 40 Table 6. Adapter slot priorities and maximum PCI, PCI-X, and PCIe adapters supported (continued) Feature Description 02E/4B and 05F/6B 02E/4C and 05E/6C code Slot priorities Maximum Slot priorities Maximum number of number of adapters adapters supported supported 2749 PCI Ultra Magnetic Media Controller (FC All slots have the All slots have the 2749;...
  • Page 41 Table 6. Adapter slot priorities and maximum PCI, PCI-X, and PCIe adapters supported (continued) Feature Description 02E/4B and 05F/6B 02E/4C and 05E/6C code Slot priorities Maximum Slot priorities Maximum number of number of adapters adapters supported supported 5581 PCI Ultra RAID Disk Controller with All slots have the All slots have the Auxiliary-write cache IOA (FC 5581;...
  • Page 42 Table 6. Adapter slot priorities and maximum PCI, PCI-X, and PCIe adapters supported (continued) Feature Description 02E/4B and 05F/6B 02E/4C and 05E/6C code Slot priorities Maximum Slot priorities Maximum number of number of adapters adapters supported supported 5778 PCI-X Dual Channel Ultra320 SCSI RAID All slots have the All slots have the Adapter with Auxiliary Write Cache...
  • Page 43 Table 6. Adapter slot priorities and maximum PCI, PCI-X, and PCIe adapters supported (continued) Feature Description 02E/4B and 05F/6B 02E/4C and 05E/6C code Slot priorities Maximum Slot priorities Maximum number of number of adapters adapters supported supported 6805 ARTIC960Hx 4-Port Multiprotocol PCI All slots have the 24 and 48 All slots have the...
  • Page 44 Table 6. Adapter slot priorities and maximum PCI, PCI-X, and PCIe adapters supported (continued) Feature Description 02E/4B and 05F/6B 02E/4C and 05E/6C code Slot priorities Maximum Slot priorities Maximum number of number of adapters adapters supported supported 5289 PCIe 2-port Async EIA-232 PCIe 1X LPC 1, 3, 2, 4 6, 5, 4, 3, 2, 1 Adapter (FC 5289;...
  • Page 45 Table 6. Adapter slot priorities and maximum PCI, PCI-X, and PCIe adapters supported (continued) Feature Description 02E/4B and 05F/6B 02E/4C and 05E/6C code Slot priorities Maximum Slot priorities Maximum number of number of adapters adapters supported supported 5735 8 Gigabit PCI Express Dual Port Fibre 1, 3, 2, 4 24 and 44 6, 5, 4, 3, 2, 1...
  • Page 46 Table 6. Adapter slot priorities and maximum PCI, PCI-X, and PCIe adapters supported (continued) Feature Description 02E/4B and 05F/6B 02E/4C and 05E/6C code Slot priorities Maximum Slot priorities Maximum number of number of adapters adapters supported supported 5260 PCIe2 LP 4-port 1 GbE Adapter (FC 5260; 5, 7, 6, 8 7, 9, 8, 10 CCIN 576F)
  • Page 47 Table 6. Adapter slot priorities and maximum PCI, PCI-X, and PCIe adapters supported (continued) Feature Description 02E/4B and 05F/6B 02E/4C and 05E/6C code Slot priorities Maximum Slot priorities Maximum number of number of adapters adapters supported supported 5278 PCIe Dual-x4 SAS Adapter (FC 5278; 1, 3, 2, 4 7, 9, 8, 10 CCIN 57B3)
  • Page 48 Table 6. Adapter slot priorities and maximum PCI, PCI-X, and PCIe adapters supported (continued) Feature Description 02E/4B and 05F/6B 02E/4C and 05E/6C code Slot priorities Maximum Slot priorities Maximum number of number of adapters adapters supported supported 5287 PCIe2 2-port 10 GbE SR Adapter (FC Not supported 1, 2, 3, 4, 5, 6 5287;...
  • Page 49 Table 6. Adapter slot priorities and maximum PCI, PCI-X, and PCIe adapters supported (continued) Feature Description 02E/4B and 05F/6B 02E/4C and 05E/6C code Slot priorities Maximum Slot priorities Maximum number of number of adapters adapters supported supported 5744 PCIe2 2x10 GbE SR 2x1 GbE UTP Not supported 1, 2, 3, 4, 5, 6 Adapter (FC 5744;...
  • Page 50 Table 6. Adapter slot priorities and maximum PCI, PCI-X, and PCIe adapters supported (continued) Feature Description 02E/4B and 05F/6B 02E/4C and 05E/6C code Slot priorities Maximum Slot priorities Maximum number of number of adapters adapters supported supported 5899 PCIe2 4-port 1 GbE Adapter (FC 5899; 4,1,2,3 24 and 44 6, 1, 2, 3, 4, 5...
  • Page 51 Table 6. Adapter slot priorities and maximum PCI, PCI-X, and PCIe adapters supported (continued) Feature Description 02E/4B and 05F/6B 02E/4C and 05E/6C code Slot priorities Maximum Slot priorities Maximum number of number of adapters adapters supported supported EC30 PCIe2 2-Port 10 GbE RoCE SR adapter Not supported 1, 2, 3, 4, 5, 6 (FC EC30;...
  • Page 52 Table 6. Adapter slot priorities and maximum PCI, PCI-X, and PCIe adapters supported (continued) Feature Description 02E/4B and 05F/6B 02E/4C and 05E/6C code Slot priorities Maximum Slot priorities Maximum number of number of adapters adapters supported supported 2053 PCIe RAID and SSD SAS Adapter 3 Gb 02E/4B: 5 and 6 02E/4C: 7 and 8 Low-profile (FC 2053;...
  • Page 53 Table 6. Adapter slot priorities and maximum PCI, PCI-X, and PCIe adapters supported (continued) Feature Description 02E/4B and 05F/6B 02E/4C and 05E/6C code Slot priorities Maximum Slot priorities Maximum number of number of adapters adapters supported supported 5913 PCIe2 1.8-GB Cache RAID SAS Tri-port 6 1, 3, 2, 4 18 and 24 1, 2, 3, 4, 5, 6...
  • Page 54 Performance notes Use the information in this section to determine the maximum number of adapters that can be placed in a system while still maintaining optimum performance. Performance notes regarding GX++ channel adapters and I/O expansion units The I/O expansion units must be limited to one expansion unit per GX++ channel controller (FC 5615) Do not connect multiple expansion units to the same GX++ channel controller.

  • Page 55: I/O Expansion Units

    Table 8. Maximum number of extra-high bandwidth Ethernet adapters for best performance Low profile adapters in system slots Adapters per Adapters in C1-C1 to C1-C4 if Adapters per 5615 with one or System system slots C4 - FC 5610 or FC 5615 with one or two 58/02 or System...
  • Page 56 Figure 4. Rear view Table 9. Location code descriptions. This table describes the location codes that are shown in Figure 4. Location code Description C1, C2, C3, C4, C5, and C6 PCI-X DDR slots. See also “PCI slot descriptions.” C7-T1 and C7-T2 12X Channel remote I/O ports.

  • Page 57: Pci Adapters Slot Priorities For The 58/02 And 58/77 Expansion Units

    PCI adapters slot priorities for the 58/02 and 58/77 expansion units Learn about the PCI Express (PCIe) slots in the 58/02 and 58/77 expansion units. System description The 58/02 and 58/77 expansion units are 19-inch, rack-mountable, I/O expansion drawers that are designed to be attached to the system using 12X double data rate (DDR) cables.
  • Page 58 v A second I/O chip controls slots P1-C4, P1-C5, and P1-C6. v A third I/O chips controls slots P1-C7, P1-C8, P1-C9, and P1-C10. For best performance, fill P1-C1, P1-C4, P1-C2, P1-C5, P1-C3, and P1-C6 first with the highest bandwidth adapters. Then fill the remaining slots. PCI adapter placement for the 02E/4B, 02E/4C, 05F/6B, or 05E/6C...

  • Page 59: Notices

    Notices This information was developed for products and services offered in the U.S.A. The manufacturer may not offer the products, services, or features discussed in this document in other countries. Consult the manufacturer's representative for information on the products and services currently available in your area.

  • Page 60: Trademarks

    This information is for planning purposes only. The information herein is subject to change before the products described become available. This information contains examples of data and reports used in daily business operations. To illustrate them as completely as possible, the examples include the names of individuals, companies, brands, and products.
  • Page 61 harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his own expense.
  • Page 62 This is a Class A product based on the standard of the VCCI Council. If this equipment is used in a domestic environment, radio interference may occur, in which case, the user may be required to take corrective actions. Japanese Electronics and Information Technology Industries Association (JEITA) Confirmed Harmonics Guideline (products less than or equal to 20 A per phase) Japanese Electronics and Information Technology Industries Association (JEITA) Confirmed Harmonics Guideline with Modifications (products greater than 20 A per...
  • Page 63 Electromagnetic Interference (EMI) Statement - Korea Germany Compliance Statement Deutschsprachiger EU Hinweis: Hinweis für Geräte der Klasse A EU-Richtlinie zur Elektromagnetischen Verträglichkeit Dieses Produkt entspricht den Schutzanforderungen der EU-Richtlinie 2004/108/EG zur Angleichung der Rechtsvorschriften über die elektromagnetische Verträglichkeit in den EU-Mitgliedsstaaten und hält die Grenzwerte der EN 55022 Klasse A ein.

  • Page 64: Class B Notices

    Generelle Informationen: Das Gerät erfüllt die Schutzanforderungen nach EN 55024 und EN 55022 Klasse A. Electromagnetic Interference (EMI) Statement - Russia Class B Notices The following Class B statements apply to features designated as electromagnetic compatibility (EMC) Class B in the feature installation information. Federal Communications Commission (FCC) statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 65 European Community Compliance Statement This product is in conformity with the protection requirements of EU Council Directive 2004/108/EC on the approximation of the laws of the Member States relating to electromagnetic compatibility. IBM cannot accept responsibility for any failure to satisfy the protection requirements resulting from a non-recommended modification of the product, including the fitting of non-IBM option cards.

  • Page 66: Terms And Conditions

    Germany Compliance Statement Deutschsprachiger EU Hinweis: Hinweis für Geräte der Klasse B EU-Richtlinie zur Elektromagnetischen Verträglichkeit Dieses Produkt entspricht den Schutzanforderungen der EU-Richtlinie 2004/108/EG zur Angleichung der Rechtsvorschriften über die elektromagnetische Verträglichkeit in den EU-Mitgliedsstaaten und hält die Grenzwerte der EN 55022 Klasse B ein. Um dieses sicherzustellen, sind die Geräte wie in den Handbüchern beschrieben zu installieren und zu betreiben.
  • Page 67 these publications, or reproduce, distribute or display these publications or any portion thereof outside your enterprise, without the express consent of the manufacturer. Rights: Except as expressly granted in this permission, no other permissions, licenses or rights are granted, either express or implied, to the Publications or any information, data, software or other intellectual property contained therein.
  • Page 68 PCI adapter placement for the 02E/4B, 02E/4C, 05F/6B, or 05E/6C...
  • Page 70 Printed in USA...
