C-2 Preparing Booster Seat For Use
NOTE: Separate the backrest/headrest from the base. If your pad
comes in a plastic bag, remove the pad from the plastic bag.
1.
2.
3.
To use the booster seat with backrest/headrest, follow
all of the instructions below to attach the seat back.
1.
A
B
11
4358-6864 Can Pronto ENG.indd 13-14 4358-6864 Can Pronto ENG.indd 13-14
Install Seat Pad
Slide seat pad onto the front
of the seat base. Doing
one side at a time, slide
the elastic strap over each
armrest.
Wrap Elastic Straps
Under the Seat Base
Pull Seat Pad Around Cup
Holder
Determine Style of
Headrest Pad
If back of headrest pad has a
sewn on plastic piece (image
A), follow steps 2-5 and
steps 10-12.
If the headrest pad does not
have plastic piece (image B),
skip to steps 6-12.
2. Attach Headrest to
Backrest
With the headrest and
backrest facing down, slide
the headrest into the track
on the back of the headrest.
a.
Lift headrest adjuster lock
up and pull headrest down
into a lock position.
3. Install Headrest Pad
Slide the pad over one side
of the head rest, then the
other.
4.
Attach the Elastic Straps
From the back of headrest,
attach the elastic straps
to the hooks above the
shoulder belt positioning
guides.
5.
Install Backrest Pad
Slide backrest pad onto one
side of the backrest. Pull pad
tight and slide the pad over
the other side of backrest.
Bottom of the headrest
pad should be behind the
backrest pad as shown.
continued on next page.
