2. SPECIFICATIONS

Power required
Output
Holding current
In-rush current capacity
Relay contacts
Battery backup
Battery monitoring
PIN code length
Open duration
Penalty function
Penalty time
Remote release
Keypad cable
Keypad
Annunciator
Supplied cable
Maximum length
Enclosure
Dimensions
Option available:
Narrative description:
Model CC-8521AN Crypto Lock single door access control system including control
unit, weather-proof 10-button keypad in stainless steel spy-proof housing with visitor
button and 20 ft. water-blocking cable, user code cannot be re-programmed, changed
or revealed in any way from keypad. Includes a penalty time adjustment (3-60 sec.),
open time adjustment (3-60 sec.), code length switch (3, 4 or 5 digits), five 10-
position DIP switches to set the PIN code, output voltage switch (12 or 24 Vdc, 2A
continuous, 16A in-rush current), holding current limit switch (2A or 300mA, fail-
safe and fail-secure lock outputs, external annunciator output, release input, and low-
battery, penalty, and power warning lamps. The metal enclosure includes a cam lock
and has provisions for a padlock. Input power is 115/230 Vac, 50/60Hz.
115/230 Vac, 50 or 60 Hz, 60 W
12Vdc, 0.8A or 24 Vdc, 2A continuous
Can be limited to 300mA (switch selectable)
16A
10A, SPDT (Form C)
12Vdc or 24Vdc, automatic transfer and charging
(batteries optional)
Warning lamp, beeper and output signal activate when
battery is low
3, 4 or 5 digits, switch selectable
Adjustable, 3 to 60 seconds
Invalid digits temporarily disable operation
Adjustable, 3 to 60 seconds
Dry contact closure input
14-conductor, #22
10 button
2-conductor, #22
20 ft., 14-cond., #22
200 ft.
19 gauge steel, powder painted, gray, knockouts for
conduit, and cam lock (included), holes to
accommodate padlock (not included)
12H x 9W x 4.5D in.
CC-BATT, 12Vdc, 7AH rechargeable battery (two
required) *enclousure does not accomodate
