DEMO MANUAL DC1745A
pArts list
QTY REFERENCE
1 R19
1 R20
1 R22
1 R23
2 R24,R25
1 TVS
1 TVS1
1 T1
1 U1
Additional Demo Board Circuit Components
0 R14
0 C19 (OPT)
0 C14, C18 (OPT)
Hardware/Components (For Demo Board Only)
4 STAND-OFF
4 J1,J2,J3,J4
1 J5
8
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
Resistor, 2.2Ω, 4W, 15%
Resistor, Chip, 34.0, 1%, 1206
Resistor, Chip, 22k, 5%, 1210
Resistor, Chip, 6.04, 1%, 0603
Resistor, Chip, 510, 5%, 1210
VDR Metal Oxide Varistor
TVS, 150V, SMCJ150, SMC
Transformer, CEFD2513B TYPE
IC LT3748, MSOP-16
Resistor, 1210 (OPT)
Capacitor, 1206 (OPT)
Capacitor, 1210
Stand-Off, Nylon 0.25", Snap On
Jack, Banana
Terminal Block, PCB Mount, 282836-3
MANUFACTURER/PART NUMBER
Murata, NTPA2R2LDNB0
Vishay, CRCW120634R0FKEA
Yageo, RC1210JR-0722KL
Yageo, RC0603FR-076R04L
NIC, NRC25J511TRF
Vishay, VDRS10P320BSE
Diodes, SMCJ150A-13-F
Sumida, 10393-T029
Linear Technology, LT3748#TRPBF
Option
Option
Option
Keystone, 8831
Keystone, 575-4
Tyco, 282836-3
dc1745afa
