Page 1: Rack Mount
Patent(s) Pending Rack Mount Keyboard Tray Installation Instructions Kit P/N: 1UKYB-126... -
Page 2: Kit Contents
Kit Contents (1) Partially Assembled Shelf Rack Mount Hardware Kit: (1) Mini Black Keyboard (USB or PS2) 12-24 x 1/2” Pan Head Screws Zinc 10-32 x 1/2” Pan Head Screws (1) Cable (PS2 to USB) 12-24 Cage Nuts (2) Rear Brackets 12-24 Square Nuts (1) Cable Management Bracket (2) Cable Management Arms... - Page 3 Installation Instructions (4Post) Step 2. Adjust Depth: Adjust the rear brackets to fit your rack mounting depth and attach to slide rails using (4) 8-32 screws and (4) 8-32 nuts. Note: You must extend the slide rails to install the nuts. Rear Brackets Step 3.
- Page 4 Installation Instructions (2 Post Flush) Step 1. Set Up for 2Post Flush: Rotate rear brackets 90° and mount and attach cable management as shown below (see Cable Management step 3) to mount in 2post flush configuration. Proceed to Final Assembly below. Rear Brackets Final Assembly Velcro...
