Hunter Wobble
Game Trailer
Setup and Operating Instructions
Failure to read and understand these instruc-
tions before using this Clay Target Launcher
can result in death, bodily injury or property
damage.
If you have any questions regarding setup or
operation after reading this manual, call
Promatic for assistance at 888.767.2529 be-
fore proceeding.
