Direct Connect; Hard Coupler Connection - SubSurface Instruments PL-TT Series User Manual

Direct Connection is the most reliable method of signal application. This method is relatively free of
interference. The greatest amount of signal strength can be achieved by this method. Low, mid, and
high frequency may be used. The far end of the utility must be grounded.
Connect the r
point or an exposed metallic section of the utility.
Place the G
from this point, at an angle of 90º to the buried
cable or pipe. Push the G
ground 8 to 10 inches. Connect the B
c
to the G
ord
Plug the r
o
utPut
Signal Output Indicator will flash once signal is
established.
The Hard Coupler is very easy to use, and services do not have to be interrupted. The operation range
is shorter than for Direct Connection methods. The tracing signal can be affected by neighboring cables
and pipes. The Red/Black Test Cord or the Ground Rod Prove (GPR) are not needed for this method.
Successful coupler operation requires an insulated conductor that is grounded on both near and far
ends.
Clamp the H
It is important to connect the coupler around
the cable needing to be traced. Connect the
coupler around the wire closer to the outgoing
cable not near the system ground. The result
will be a stronger signal. By connecting near
the grounding, the range will also be shorter,
and difficulty may arise determining one cable
from another.
Plug the Coupler into the tX o
Some couplers are frequency specific, others can operate on medium and high frequencies.
08
SERIES
CAUTION
DO NOT CONNECT TO LIVE OR
ENERGIZED POWER CABLES
t c
to an existing ground
ed est ord
r approximately 10 feet
round od
round
r .
round od
/B T c
ed lack esT ord
J
. Select the desired frequency. The
ack
h C
ard
c
around the cable.
ard ouPler
utPut
d C
ireCt onneCtion
r into the
od
t
lack est
into the tX
to transmitter ground rod
C
oupler onneCtion
J .
ack
Transmitter
Red cord connects to utility
(unbond this end for best results)
Buried Utility
to Locate
Black cord connects
Transmitter
Inductive Coupler
Wraps Utility
Buried Utility
to Locate
Near End of
Buried Utility
Must Be Bonded Must Be Bonded
Far end of
buried utility
must be bonded
Far End of
Buried Utility
