- Page 1 RMX 16: Digital Reverberation System 500 Series Module Installation Guide Issue 1...
- Page 2 Health & Safety Notice FOR YOUR OWN SAFETY AND FOR THE PROTECTION OF OTHERS PLEASE OBSERVE THE FOLLOWING HEALTH AND SAFETY INSTRUCTIONS READ THESE INSTRUCTIONS AND KEEP THEM HANDY • HEED ALL SAFETY WARNINGS • DO NOT USE NEAR WATER •...
-
Page 3: Table Of Contents
Warning symbols ..................... 5 Environmental Considerations ..................5 Cooling ........................5 Important Safety Instructions UK ................6 RMX 16 Front Plate ....................7 RMX 16 Rear Plate ....................8 RMX 16 Side Plate ..................... 9 Dimensions & Power requirements ................10 Audio Specification .................... -
Page 4: Important Safety Instructions U.s
For full operational instructions, please refer to the RMX 16 User Manual. Important Safety Instructions Read these instructions Keep these instructions Heed all warnings Follow all instructions Do not use this apparatus near water Clean only with a dry cloth Do not block any ventilation openings. -
Page 5: Warning Symbols
Warning Symbols Please refer to the manual before operating Environmental considerations Temperature Operating 5°C to 30°C (41°F to 86°F) Non-operating -20°C to 50°C (-2°F to 122°F) Max Gradient 15°C/Hour (59°F/Hour) Relative Humidity Operating 20% to 80% Non-operating 5% to 90% Max wet bulb 28°C non-condensing (or 57°F non-condensing) -
Page 6: Important Safety Instructions Uk
Important Safety Instructions READ THESE INSTRUCTIONS AND KEEP THEM HANDY HEED ALL SAFETY WARNINGS THE UNIT MUST BE EARTHED WHEN OPERATED DO NOT USE NEAR WATER CLEAN ONLY WITH A DRY CLOTH DO NOT INSTALL NEAR HEAT SOURCES ... - Page 7 500 Series Installation Diagram...
-
Page 8: Rmx 16 Front Plate
RMX 16 Front Plate... -
Page 9: Rmx 16 Rear Plate
RMX 16 Rear Plate... - Page 10 RMX 16 Side view...
-
Page 11: Dimensions & Power Requirements
Audio Connection The RMX16 500 series has a single MONO input and a STEREO output. The unit uses 3u of 500 series rack space with its MONO input on the first slot (Input 1). The stereo output is on the First and Third slots (Output 1 and Output 3). -
Page 12: Unit Connection Table
Unit Connection Tables Data USB Type C Unit 15-Way Pin Outs Slot 1 & 3 SLOT 1 SLOT 3 Chassis Ground Chassis Ground Left Output + Right Output + Left Output - Right Output - Input - Input + +16V +16V PSU Ground PSU Ground...
