- Page 1 SHINE BAR 18Q User Manual Please read the instructions carefully...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions 2. Technical Specifications 3. Installation 4. How to set the unit 5. How to control the unit 6. DMX512 Configuration 7. DMX512 Connections 8. Troubleshooting 9. Fixture Cleaning... - Page 3 1. Safety Introductions Please read the instructions carefully which includes important information about the installation, operation and maintenance. WARNING Please keep this User Manual for future consultation. If you sell the fixture to another user, be sure that they also receive this instruction booklet. ...
-
Page 4: Technical Specifications
2. Technical Specifications Voltage：AC100-240V, 50/60Hz; Power consumption：200W Light source: 18pcs*10W RGBW 4 in 1 LED; Control mode：DMX ,Master-slave，Sound DMX Channel:9/23/72CH Dimmer:0-100% Linear dimming IP:IP65 Net weight：6.7KG Colors: RGBW color Mixing 3. Installation The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating. - Page 5 or the speed, the parameters. Press B or C to change its parameter value. Press the D key to confirm 2. LED display window function table, (all the features selected by pressing the D key to confirm) Display Function A001 DMX512 Address 23ch/-9ch- Channel selection (23 channels, 9 channels, 72 channels)B, C...
-
Page 6: How To Control The Unit
5. How To Control The Unit You can operate the unit in three ways: 1. By master/slave built-in preprogram function 2. By easy controller 3. By DMX controller 6. DMX512 Configuration DMX512 Function Description Total dimmer Total dimmer, linear dimming, dark to bright Total strobe Total strobe, from slow to fast 0--25：... - Page 7 Function selection1 Function speed, from slow to fast R Dimmer R Dimmer, linear dimming, from dark to bright G Dimmer G Dimmer, linear dimming, from dark to bright B Dimmer B Dimmer, linear dimming, from dark to bright W Dimmer W Dimmer, linear dimming, from dark to bright DMX512 23CH...
- Page 8 3 Dimmer R、G、B、W Dimmer 4 Dimmer R、G、B、W Dimmer CH10 5 Dimmer R、G、B、W Dimmer CH11 6 Dimmer R、G、B、W Dimmer CH12 7 Dimmer R、G、B、W Dimmer CH13 8 Dimmer R、G、B、W Dimmer CH14 9 Dimmer R、G、B、W Dimmer CH15 10 Dimmer R、G、B、W Dimmer CH16 11 Dimmer R、G、B、W Dimmer CH17 12 Dimmer...
- Page 9 CH14 G4 Dimmer G4 Dimmer, linear dimming, from dark to bright CH15 B4 Dimmer B4 Dimmer, linear dimming, from dark to bright CH16 W4 Dimmer W4 Dimmer, linear dimming, from dark to bright CH17 R5 Dimmer R5 Dimmer, linear dimming, from dark to bright CH18 R5 Dimmer R5 Dimmer, linear dimming, from dark to bright...
-
Page 10: Dmx512 Connections
CH 47 B12 Dimmer B12 Dimmer, linear dimming, from dark to bright CH 48 W12 Dimmer W12 Dimmer, linear dimming, from dark to bright CH 49 R13 Dimmer R13 Dimmer, linear dimming, from dark to bright CH 50 G13 Dimmer G13 Dimmer, linear dimming, from dark to bright CH 51 B13 Dimmer... -
Page 11: Troubleshooting
Connect the fixture together in a “daisy chain” by XLR plug cable from the output of the fixture to the input of the next fixture. The cable cannot be branched or split to a “Y” cable. Inadequate or damaged cables, soldered joints or corroded connectors can easily distort the signal and shut down the system. -
Page 12: Fixture Cleaning
DMX polarity. 3. If you have intermittent DMX signal problems, check the pins on connectors or on PCB of the fixture or the previous one. 4. Try to use another DMX controller. 5. Check if the DMX cables run near or run alongside to high voltage cables that may cause damage or interference to DMX interface circuit.
