ArtFox Pixel Beam K7 User Manual

7x15w 4in1 infinity rotation led pixel bar
Hide thumbs

Advertisement

Quick Links

Download this manual
Pixel Beam K7
7x15W 4IN1 Infinity Rotation LED Pixel Bar
This product manual contains important information about the safe
installation and use of this projector. Please read and follow these instructions
carefully and keep this manual in a safe place for future reference.

User manual

Please read the instructions carefully before use

Advertisement

loading
Need help?

Need help?

Do you have a question about the Pixel Beam K7 and is the answer not in the manual?

Questions and answers

Related Manuals for ArtFox Pixel Beam K7

Summary of Contents for ArtFox Pixel Beam K7

  • Page 1: User Manual

    Pixel Beam K7 7x15W 4IN1 Infinity Rotation LED Pixel Bar This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1.Safety Instruction .................. 2 2.Technical Specification ................4 3.How to Control The Devicee ..............5 4.Diagram ..................... 12 5.Trouble Shooting ................. 13 6.Fixture Cleaning .................. 14 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &...
  • Page 3 The unit is for indoor use only. Use only in a dry location. The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent surfaces. Be sure that no ventilation slots are blocked. Disconnect main power before replacement or servicing. Make sure there are no flammable materials close to the unit while operating as it is fire hazard.

  • Page 4: Technical Specification

    CAUTION: There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact your nearest dealer. INSTALLATION: The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating.

  • Page 5: How To Control The Devicee

    Features 85% optic efficiency High-efficiency 67 mm PMMA optics Continuous PAN and TILT rotation Flicker free sources management, suitable for TV applications and all video High-resolution stepper motors operated via microprocessors ensure extreme accuracy and smooth movements. Variable strobe effects Size Dimension: 58*17*25cm Packing Size:640*320*245MM...
  • Page 6 Display: MENU To select the programming functions DOWN To go backward in the selected functions To go forward in the selected functions ENTER To confirm the selected functions Set DMX Address Code Press "Menu" to "Set DMX Address",and press "ENTER" keys to enter into Show "Set DMX Address DMX Address:001",Press the "UP and DOWN"...
  • Page 7 Stand 39CH DMX Extend Auto Alone Auto Master Music Alone Music Master Display DelayOff Option Display Option Always Option Lost DMX Option =Clear Lost DMX Lost DMX =Hold Advanced Code Password Code =000 =008 Adjust =+000 Advanced Advanced Adjust Adjust Tilt Tilt =+000...
  • Page 8 View CH=001 DmxValue DMX=000 View =1.00F Version YYYY.MM Load Def Default Load Def =YES 12/15/39 DMX channels mode: Mode/Channel Value Function Base Standard Extend PAN Movement 8bit : 0-255 Pan Movement Pan Fine 16bit : 0-255 Fine control of Pan movement TILT Movement 8bit : 0-255 Tilt Movement...
  • Page 9 No Function 10-129 Forward fast to slow 130-135 Stop 136-255 Backward slow to fast Dimmer : Closed 10-255 Dimmer from 0%~100% Strobe : 0-31 Closed 32-63 Open 64-95 Strobe from slow to fast 96-127 Open 128-159 Raiden strobe from slow to fast 160-191 Open 192-223 Random strobe from slow to fast 224-255 Open...
  • Page 10 All Green : [LED Macro Valid] 0-255 Green Color ( 0%~100% ) All Blue : [LED Macro Valid] 0-255 Blue Color ( 0%~100% ) All White : [LED Macro Valid] 0-255 White Color ( 0%~100% ) Red LED-array 1: [CH10 Invalid] 0-255 Red Color ( 0%~100% ) Green LED-array 1: [CH10 Invalid]...
  • Page 11 Red LED - array 4 : 0-255 Red Color ( 0%~100% ) Green LED - array 4 : 0-255 Green Color ( 0%~100% ) Blue LED - array 4 : 0-255 Blue Color ( 0%~100% ) White LED - array 4 : 0-255 White Color ( 0%~100% ) Red LED - array 5 :...

  • Page 12: Diagram

    White LED - array 7 : 0-255 White Color ( 0%~100% ) Function : 0-24 No function 25-49 Reset (5 second) 50-74 No function 75-99 No function 100-124 No function 125-149 No function 150-174 Auto run 175-255 Music Control 4.Diagram...

  • Page 13: Trouble Shooting

    5.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: The unit does not work, no light and the fan does not work Check the connection of power and main fuse. Measure the mains voltage on the main connector.

  • Page 14: Fixture Cleaning

    6.Fixture Cleaning The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics. Clean with soft cloth using normal glass cleaning fluid.
