2.048Mbps Wireless Modem
TECHNICAL:
(0118) 965 6000
SALES:
(0118) 965 5100
FAX:
(0118) 965 5001
ADDRESS:
464 Basingstoke Road, Reading, Berkshire RG2 0QN
WEB:
www.blackbox.co.uk
2.048Mbps Wireless Modem:
G703:
X.21:
V.35:
Directional Antennas with 10 m of cable:
12dBi Transmit/ 12dBi Receive:
12dBi Transmit/ 18dBi Receive:
12dBi Transmit/ 24dBi Receive:
MWU2000-G703
MWU2000-X21
MWU2000-V35
MWU2000-1212
MWU2000-1218
MWU2000-1224
