Black Box MDS932AE-10BT User Manual

Black Box MDS932AE-10BT User Manual

G.shdsl modem
Hide thumbs Also See for MDS932AE-10BT:

Advertisement

Quick Links

MDS932AE-10BT
MDS932AE-FXO
MDS932AE-FXS
MDS933AE-10BT
MDS932C-10BT
MDS933C-10BT
G.SHDSL Modem
USER MANUAL
Version
Revision
Document name
User Manual
1.2
26 January 2004
MDS933AE-v1.2.doc
STANDALONE
STANDALONE
STANDALONE
STANDALONE
RACK-CARD
RACK-CARD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MDS932AE-10BT and is the answer not in the manual?

Questions and answers

Summary of Contents for Black Box MDS932AE-10BT

  • Page 1 MDS932AE-10BT MDS932AE-FXO MDS932AE-FXS MDS933AE-10BT MDS932C-10BT MDS933C-10BT G.SHDSL Modem USER MANUAL Version Revision 26 January 2004 Document name MDS933AE-v1.2.doc User Manual STANDALONE STANDALONE STANDALONE STANDALONE RACK-CARD RACK-CARD...
  • Page 3: Table Of Contents

    VERSION CONTROL... 5 GENERAL INFORMATION... 6 ORDER INFORMATION ... 7 DESCRIPTION OF THE DEVICE ... 8 Exterior design Desktop models ... 8 Exterior design Rack Cards models... 10 RULES OF SWITCHING... 12 The Desktop delivery set... 12 The Rack Card delivery set... 12 Connection rules ...
  • Page 4 Line1 and Line2 Connector ... 24 DESCRIPTION OF INTERFACE CABLES... 25 Ethernet cable ... 25 DSL cable... 25 Version: 1.2 User Manual Page. 4 of 25...
  • Page 5: Version Control

    VERSION CONTROL Version Date Major changes to previous version 31.12.2001 Initial version of the manual corresponding to version 1.2 of the device micro program 23.10.2003 New function description corresponding to software release V1.6 Corrected Connecter description 9.1 Changed DSL cable to twisted type 10.2 26.1.2004 Manual corresponding to software version 1.7 Implementation of rack card models...
  • Page 6: General Information

    1 GENERAL INFORMATION • High-speed symmetrical data transmission over one physical copper twisted pair with the 135 Ohm impedance according to ETSI TS 101 135. • ITU-T G.991.2 (G.shdsl) line encoding. • Line rate in the range from 72 Kbit/s to 2320 Kbit/s in 2 wire mode Line rate in the range from 144 Kbit/s to 4624 Kbit/s in 4 wire mode •...
  • Page 7: Order Information

    ORDER INFORMATION MDS932AE-10BT MDS933AE-10BT MDS932AE-FXS MDS932AE-FXO Version: 1.2 User Manual Modem AccessDSL Discovery, G.shdsl, 10/100Base-T Bridge, VLAN, Adapter 220 Vac Modem AccessDSL Discovery, G.shdsl, 1 or 2 pairs, up to 4.6Mbps, 10/100Base-T Bridge, VLAN, Adapter 220 Vac Modem AccessDSL Discovery, G.shdsl, 10/100Base-T Bridge, VLAN, Adapter 220 Vac, with FXS interfaces Modem AccessDSL Discovery, G.shdsl, 10/100Base-T Bridge,...
  • Page 8: Description Of The Device

    2 DESCRIPTION OF THE DEVICE 2.1 Exterior design Desktop models The front panel of the device has 3 LEDs: LOCAL informs the user about the status of the local device. The following four statuses are possible «blinking red» «red» «amber» «green»...
  • Page 9 The back panel of the MDS932AE-10BT and MDS933AE-10BT modem has: • The grounding bolt of the modem (option); • The “AC12V” power connector. The connection of the modem to the 220 V power supply is implemented using an external power supply unit;...
  • Page 10: Exterior Design Rack Cards Models

    User Manual 2.2 Exterior design rack card models Version: 172 Page. 10 of 25...
  • Page 11 Status(L) informs the user about the status of the local device. The following four statuses are possible «blinking red» «red» «amber» «green» Status(R) informs the user about the status of the remote device. At the time being the remote configuring of modems is not provided. Ethernet The LED is lit upon an incorrect connection to the LAN.
  • Page 12: Rules Of Switching

    3 RULES OF SWITCHING 3.1 The standalone delivery set The delivery set includes: • the subscriber access device (a modem) • the power supply source (an AC adapter) • the cables for the line connections 3.2 The rack-card delivery set The delivery set includes: •...
  • Page 13 To update the information on the screen use the “Enter” key. The following menu will appear on the screen. Input Password: Please enter your programmed password. The unit will be delivered with the default password “admin” After entering the password the following menu will appear. Discovery G.SHDSL Ethernet Monitor V1.7 +-----------------------+...
  • Page 14: The Command System

    4 THE COMMAND SYSTEM 4.1 Basic rules After the command is typed, press <enter>. The <Backspace> key is used to edit commands. It is necessary to input item number, for choising menu item, You can use “PageUP”, “PageDown” and “Space” keys, for scrolling list of available value of parameters, The “Esc”...
  • Page 15: Performance Management Submenu

    4.3 Performance management submenu Upon activation of the performance management submenu the following message will be displayed. 1.Loop Status... 4.EtherNet Status... Select item number or ESC to Upper level menu>> 4.3.1 Loop Status submenu Upon activation of the performance management submenu the following message will be displayed.
  • Page 16: Ethernet Status Submenu

    4.3.2 Ethernet Status submenu Upon activation of the performance management submenu the following message will be displayed. Performance Management->EtherNet Status Link:Link down Used Entries:0 Fwd Packets:0 Speed:Auto 1.Clear Counters Select item number or ESC to Upper level menu>> 4.4 Configuration management submenu Upon activation of the configuration management submenu the following message will be displayed.
  • Page 17: Dsl Setup

    4.4.1 DSL Setup In this menu you can setup the DSL link. When you have selected that menu, the following will appear: Configuration Management->DSL Setup 1.[Loop 1 Operation Mode]:Slave 2.[Loop 1 Auto/Fixed]:Fixed 5.[Loop 1 Fixed Connection Speed]:2312K(36N) 6.[Loop 1 Annex]:A/B 7.[Loop 1 Tx Level Adjustment]:0 dB 18.[2W/4W]:2W Select item number or ESC to Upper level menu>>...
  • Page 18 4.4.1.4 Fixed Connection Speed (only if Fixed is selected) • In the Fixed Connection Speed menu, you can specify your desired speed in the range of 72 kbps to 2312 kbps for 2wire units and 144 kbps to 4624 kbps for 4wire models 4.4.1.5 Annex •...
  • Page 19: Ethernet Setup Submenu

    4.4.2 Ethernet Setup submenu Configuration Management->EtherNet Setup 1.[Speed]:Auto 2.[Duplex Mode]:Auto 3.[Disable Mac Filter]:No 4.IP Address>>192.168.5.105 5.Subnet Mask>>255.255.255.0 6.Gateway Address>>192.168.5.1 Select item number or ESC to Upper level menu>> • In the Speed menu, you can setup the Ethernet speed to the following states: 10M, 100M or Auto •...
  • Page 20: Technical Specifications

    5 TECHNICAL SPECIFICATIONS The main technical specifications of modems of the Black Box family are presented below in the table. Standard Number of pairs Line rate 2 wire models 4 wire models Communication range for cables with the wire diameter of...
  • Page 21: Storage Conditions

    С. The equipment can also withstand air-transport at a low air pressure of о 12 kPa (90 Torr) at -50 С. The packed equipment of the Black Box family can be stored within 12 months (from the date of transshipment including transporting time) in storage rooms without heating о о...
  • Page 22: Terms To Transport

    -50 С to +50 • relative air humidity up to 100% at 25 The equipment of the Black Box family should be packed and withstand transportation by: • motor transport with the number of transshipments no more than four: •...
  • Page 23: Connector's Description

    8 CONNECTOR’S DESCRIPTION 8.1 DSL Connector Type: RJ-45, 8 pin RJ-45 8.2 Monitor Connector Type: Sub-D9, female female Version: 1.2 User Manual Number Signal Assignment LB,a Ttp (4W model only) LA,a LA,b ring LB,b ring (4W model only) Number Signal Assignment Transmit data Receive data...
  • Page 24: Pc And Hub Connectors

    8.3 PC and Hub Connectors Type: RJ-45 RJ-45 8.4 Line1 and Line2 Connector Type: RJ-11, 4 pin RJ-11 Version: 1.2 User Manual Number PC assignment Number Signal Assignment LA,a LA,b ring HUB assignment Page. 24 of 25...
  • Page 25: Description Of Interface Cables

    9 DESCRIPTION OF INTERFACE CABLES 9.1 Ethernet cable Side А 9.2 DSL cable Side А Version: 1.2 User Manual Color of wire white/green green/white white/orange blue/white white/blue orange/white white/brown. brown/white Color of wire white/green green/white white/orange blue/white white/blue orange/white white/brown. brown/white Side B Side B...
