Spare Part List - Handicare SystemRoMedic MiniLift200 Service Manual

Spare part list

Art no. Product
80100045 Cable for charger US
80100046 Cable for charger Uk
80100047 Cable for charger AUS
80100048 Cable for charger EU
80100001 Front castor 100 mm
80100002 Rear castor 100 mm
80100074 Bumper kit
80100040 Actuator legspreading LA28
80100041 Actuator mast LA34
80100072 Actuator mast LA31-L4
80100161 Battery box CBJ Grey BAJ1
80100057 Battery CBJ
80100149 Control box CBJC
10
Unit Components
1 pce 1 x Charger cable
1 pce 1 x Charger cable
1 pce 1 x Charger cable
1 pce 1 x Charger cable
1 set 1 x Front castor
1 x Locking nut M10
1 set 1 x Rear castor
1 x Locking nut M10
1 set 4 x Bumper
1 set 1 x Actuator LA28 leg
spreading
2 x Locking nut
0,25 x Cardboard
1 set 1 x Actuator LA34 mast
2 x Locking nut M8
0,5 x Cardboard
1 pce
1 pce
1 pair 2 x Batteries
1 pce 1 x Control box
Parts
80100048
80100002
80100001
80100074
80100040
80100041
80100149
80100161
SystemRoMedic
TM
